Genius I-LOOK 325T Manual de usuario

English

Table of Contents

i-Look 325T Features 1

Installing the i-Look 325T 2-3

About Genius Application-WebCAM Mate 3

1. Main Menu 4-8

2. Picture Mode 9-11

3. Video Mode 12-13

4. Security Mode 13-16

Using MSN Messenger,Yahoo Messenger,AOL 16-18

CrazyTalk Avatar Creator 18-40

CrazyTalk CamSuite 41-68

Trouble shooting for web camera 69

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in charge

of waste management.

Add live video to your instant messaging!

Turn your PC into a live broadcast hub with i-Look 325T. Works with

windows Vista, XP, 2000, Me and 98SE. Whether you are creating video

emails or hosting one-to-one video chats, this easy to use webcam adds a

personal touch to your online communication. Connect with loved ones

easily today with live video chats!

1. LED Indicator

i-Look 325T is connected to the computer's USB port and the LED will light

up when performing video application.

2. Manual Focus

Adjust the focus by twisting the lens.

3. IR Receiver

4. USB port

i-Look 325T Features

English

-2-

button : Zoom In

button : Zoom Out

button : Press up button to turn the camera's view

to up direction.

button : Press down button to turn the camera's

view to down direction.

button : Press right button to turn the camera's view

to right direction.

button: Press left button to turn the camera's view

to left direction

H button : Home / Reset

Auto-pan stop Button: Press it to stop Auto-pan

function.

Picture Shutter Button: Press it to take picture.

Auto-pan Button: Press it to start Auto-pan function.

Pan range: 350 degree

English

-3-

You need to install device drivers and applications before using your

webcam.

Do not connect your webcam to your computer before

installing the drivers.

1. Installing the i-Look 325T driver Windows Vista/XP/2000/Me/98SE

Environment

a. Insert the i-Look 325T Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install DirectX from the CD if your pc didn’t have it on your system or

the version was older.

NOTE

If the Autorun screen doesn’t start, please follow these steps

zClick on “Start Menu”

zType D:\SETUP.EXE, then click the Enter key.

(Assume your CD-ROM is in Drive D)

2. Follow the instructions on the screen to complete the installation.

3. Insert the i-Look 325T’s USB cable to your desktop or laptop USB

port.

4. Restart your computer after all the applications have been

installed.

Installing the i-Look 325T

English

-4-

5. The software and hardware installation is now complete. You can

install the software you would like to use for video conferencing

or chat with your friends.

NOTE

The web camera can work properly with any video chat software that supports a

video feature.

To remove the driver installation in Windows 98SE/Me/2000/XP/Vista Environment:

Please go to the taskbar and follow “Start ÆProgram Æi-Look 325T

ÆClick “Uninstall”, then follow the on-screen instructions to remove the driver.

You can use Genius WebCAM Mate software to capture the

real-time image, record or execute the simple security function.

NOTE

After installing the Genius Application software, the system will

automatically create a file (C:\WINDOWS\Album or

C:\WINNT\Album)to save the images you take using the Genius

Application.

Genius application available in windows Vista/XP/2000/Me/98SE

About Genius Application-WebCAM Mate

English

-5-

1. Main Menu

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

English

-6-

Item Mode Description

Resolution

Selection

Resolution selections according to

device.

RGB24: 2688x2016(*),1280x960(*),

1024x768(*), 800x600(*), 640x480,

352x288, 320x240, 176x144, 160x120

I240: 640x480, 352x288, 320x240,

176x144, 160x120

Property page Preference setting to view your setting

and properties.

Exit Exit the Genius UI.

Remark:

* This resolution is by software interpolation.

English

-7-

-Property page

Settings

Item Description

-You can flip the image horizontally or vertically by choosing

“Image Mirror” or “Image Flip”.

-When the light is not sufficient, you may click on “Low Light” to

get a clear image.

English

-8-

Item Description

You can adjust different values for different circumstances and

environment.

You may adjust values toward image appearance. Before

adjusting values, you have to unclick “Auto” to unlock.

-Press “Default” to return to the manufacturer’s settings.

-Press “Save” to save the values you set up.

-Press “Load” to return to the previous settings.

Select the correct frequency according to the country where you

are using the web camera. (Before doing this, you will need to

select “Indoor”.)

-If your web camera is located in backlight position, you may click

“Backlight compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on “B/W

Mode”.

English

-9-

Effects

Item Description

There will be 26 different kinds of video effects/frames for you to

select. The effects can also be applied to the video chat software,

like MSN Messenger.

You can directly connect to this effect page from the web camera

settings in the video chat software.
