Genius LOOK 313 MEDIA Manual de usuario
English
-1-
1 SnapShot Button
You can press the snapshot button to take the images.
2 Lens
-Adjust the focus by twisting the lens.
-Move upward or downward to adjust the view angle
3 Speaker
Play the music through this delicate speaker
4 USB to PC/NB
Connect the mini-B USB cable to the computer in order to
activate the Look 313 Media
5 USB2.0 Hub
Connect to the USB device
6 2-Channel Audio
Connect to the Microphone and headset
Look 313 Media Features
English
-2-
1. Please install the driver first and then connect Look 313
Media to the USB port.
2. Installing the Look 313 Media driver
Windows Environment
a. Insert the Look 313 Media Installation CD into the CD-ROM drive.
b. The Autorun screen will bring up the installation screen. Click on
“Driver” then simply follow the on-screen instructions.
c. Install “DirectX” from the CD.
Notice: If the Autorun screen doesn’t start, please follow these
steps:
zClick on “Start Menu”.
zType D：\SETUP.EXE , then click “Enter” key.
(Assume your CD-ROM is in Drive D)
Mac Environment
a. Insert the Look 313 Media Installation CD into the CD-ROM
drive.
b. Double click on the CD-ROM drive.
c. Click on the file folder of “Look 313 Media Driver OSX 1.0”.
d. Click on “Look 313 Media Driver Install” then simply
follow the on-screen instructions.
e. Restart the computer
Notice:
zThe Look 313 Media can work properly with any video chat
software supported video feature and USB web camera.
The iChat can’t be supported because it only support the
Apple’s web cameras or the IEEE 1394 web camera.
3. Insert the Look 313 Media’s USB cable to your desktop’s or
laptop’s USB port. Please follow the instructions to connect
the USB cable properly.
Installing the Look 313 Media
English
-3-
a. Mini-B Connector
Please connect the mini-B connector to the Look 313
Media
b. Connect the USB connector as for the power supply
Please connect to the USB connector to the computer’s USB
port.
c. Connect the USB connector as for providing more power
and being another USB port.
If you connect the high power consumption USB devices to
the Look 313 Media’s USB ports, like scanner, digital camera,
etc., you will need to connect the USB connector to your
computer’s USB port. Meanwhile, this USB connector has the
hub feature. So, you can connect the USB device to it as long
as it is connected to the computer.
4. Complete software and hardware installation. You can
install the software you would like to use for video
conferencing or chat with your friends.
5. SpeakerAdjustment
For getting the best quality, we will suggest you to clockwise
or counterclockwise from the side to the front.
English
-4-
NOTE
To remove the driver installation:
Windows Environment:
Please go to the taskbar and follow “Start” Æ“Program” Æ“Look 313
Media”ÆClick “Uninstall”, then follow the on-screen instructions to
remove the driver.
MacOSXEnvironment:
Please go to the HDD of the operation systemÆ“Application”Æ“Look 313
Media”ÆClick “Uninstall”, then follow the on-screen instructions to
remove the driver.
You can use our software to capture the real-time image, record or
execute the simply security function.
To run the software, please go to the task bar and follow “Start”Æ
Click “Program”ÆChoose “Look 313 Media”ÆClick “Look 313
Media”. Or you may execute the software by simply clicking the
shortcut of “Look 313 Media”.
NOTE
After installing the driver of Look 313 Media, the system will automatically
create a file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images
you take using the GeniusApplication.
1. Description for the major icon
Preview mode
Genius Application (Windows Only)
English
-5-
Snapshot mode
Video Clip Mode
Security monitoring system
Exit the Genius UI
Camera Control
NOTE
In the “camera control section”, you can personalize your camera
settings for different circumstances.
English
-6-
1-You can flip the image horizontally or vertically by choosing “Image Mirror” or
“Image Flip”.
-When the light is not sufficient, you may click on “Low Light” to get a clear
image.
2You can adjust different values for different circumstances and environment
3When you want a still image capture, you can drag the bar to select a resolution
size you want.
-VGA: 640 x 480;
-SVGA: 800 x 600
-XGA: 1024 x 768
-SXGA1280 x 960
4You may adjust values toward image appearance. Before adjusting values, you
have to unclick “Auto” to unlock.
5-Press “Reset” to return to the manufacturer’s settings.
-Press “Restore” to return to the previous settings.
-Press “Save” to save the values you set up.
English
-7-
6Select the correct frequency according to the country where you are using the
web camera. (Before doing this, you will need to select “Indoor”.)
7-If your web camera is located in backlight position, you may click “Backlight
compensation” to get a sharper image.
-You can have a black-and-white photo effect by clicking on “B/W Mode”.
English
-8-
1There will be 27 different kinds of video effects/frames for you to select. The
effects can also be applied to the video chat software, like MSN Messenger.
You can directly connect to this effect page from the web camera settings in the
video chat software.
2Besides the 27 kinds of video effects/frames in section 1, you also can bring in
your customized frame. Please note that, in the customized frame, you must have
the color in Pantone 255 in the area, where you want your image show up.
English
-9-
3Auto Change: Once you choose this, the 27 kinds of video effects will take turns
from the first one to the last one.
No effects & frame: Once you choose this, the video effects will be determinate.
In this section, you can enable the “Zoom” function. Please select “Enable
Zoom” before zooming.
-Scroll the bar to zoom in or zoom out
-Press the 4-direction button to move the image upward, downward,
leftward, and rightward.
English
-10-
2. Preview Mode
You can use the function buttons on the control panel to zoom in/out and
move upward/downward/left/right.
Zoom in the image
Zoom out the image
Move the image upward
Move the image downward
Move the image to the left
