Genius NS O Instrucciones de montaje

Hardware Installation

Note: Before installing or removing the mouse to or from your computer, always re-

member to turn off your computer. Installing or removing the mouse when your com-

puter is running will cause permanent damage to the mouse or your computer.

1. For PS/2 model, you can connect the mouse to the PS/2 port.

2. For the USB model, connect your mouse to the USB port on your computer.

3. For the USB & PS/2 model, you need to use the 6-pin PS/2 adapter.

4. Turn on your computer.

Warning: Please do not use this optical mouse on a desk which is made of glass, mir-

ror, iron, or black velvet. Also, a flat surface is necessary or the Optical Sensor will

not work properly.

Software Installation

Installing the MouseMate software

1. For PCs, start Windows, insert the software CD into the computer’s CD-ROM

drive, then follow the on-screen instructions. (If Autorun is not enabled, select

Run from the Start Menu on the Taskbar. Next, type D:\Setup.exe, where D: is

the designation of the CD-ROM drive.)

2. For the Macintosh, start the Macintosh operating system, insert the software CD

into the computer’s CD-ROM drive, find the Installer icon in the appropriate

language folder, double-click the icon, then follow the on-screen instructions.

Factory Settings

Hardware Installation

ENGLISH

Magic-Roller Press the “Magic-Roller” to surf the Internet and Windows docu-

ments

Left Button Provides traditional mouse functions such as click, double click

and drag.

Right Button You can assign this button frequently used keyboard and mouse

functions in addition to features like EasyJump, Auto-Panning,

Zoom, etc.

Roller Button You can assign this button frequently used keyboard and mouse

functions in addition to features like EasyJump, Auto-Panning,

Zoom, etc.

Side Buttons You can assign certain functions to the upper or lower side button

with the roller.

Horizontal

Scrolling

Hold the Shift key while pressing the Magic-Roller in the direc-

tion you want to go or move the cursor over the horizontal scroll

bar and press the Magic-Roller.

Button Assignments

The Button Assignment feature

lets you work in a more efficient

way because you can assign the

most frequently used commands

in Windows to the mouse but-

tons.

Side Buttons: You can assign the

following functions (Applica-

tion/Document, Horizontal

Scroll, Last/Next Page, and

Zoom In/Out) to the upper or

lower side button with the roller.

MouseMate Software Features

Browsing Speed You can adjust the browsing speed when you surf the

Internet or Windows documents.

Browsing

Direction

Move the “Magic-Roller” forward and the screen will

browse to the top of the document. Move it in reverse and

the document will go in the opposite direction

MouseMate Software Features

Button Find Automatically positions the cursor on the default button,

usually the OK button, when the dialog box appears on

your screen.

Trails This option makes it easier to find the cursor when using

an LCD monitor. This option cannot be used if your

monitor does not support it.

Loop When you move the cursor to the top (or bottom) of the

screen, it will automatically move the cursor to the bot-

tom (or top) of the screen.

Mouse Speed This function lets you adjust the speed at which the

pointer moves across the screen.

Double Click

Speed

Use this function to set the double click speed of the

mouse.

Swap Left/

Right

Select this option if you want to have the mouse operate

with the right mouse button as the primary button.

Pointers Folders This lets you change the shape of the cursor.

Office 97 Mode Only supports Microsoft Office 97 along with some new

applications. Features include zoom, scrolling and Auto-

scrolling features. It’s similar to Microsoft’s

IntelliMouse.

Genius Mode Supports all applications that use scrollbars, including Of-

fice97, with zoom, Auto-panning, and scrolling functions.

About Click here to open the Genius website “www.genius-

net.com.tw”

Orientation This function lets you set the angle when you move the

mouse upward. It gives you a more comfortable angle

when holding the mouse. This function works best with a

portable trackball.

EasyJump

“EasyJump” now has two working modes: Office EasyJump

mode and Traditional EasyJump mode.

“Office EasyJump” lets you use eight commonly used appli-

cations and 16 Cyber functions more easily and quickly.

MouseMate Software Features

ENGLISH

Once you press the button you assigned, “Office EasyJump” will be displayed on a

Frisbee. Note that the functions are only available in the applications they belong to.

Click this application button to show the mouse control panel. You can check

or modify the mouse properties.

Click this function and the pan icon appears. You can move the mouse

in any direction in a document or a spreadsheet. The farther you move

the pointer from the pan icon, the faster you can pan in that direction.

Click this function and Office EasyJump Frisbee will always be on the

screen and the button will change to . Click it again to cancel this

effect.

This is a programmable application button. Press the right button on this icon

and a dialog box will display for you to select an executable program. Click

on this button to launch your specific application.

Click this function to implement the “replace” function in the current

application.

Click on this application to launch Microsoft Word.

Click this function to perform the “cut” function in Word.

Click this function to implement the “paste” function in Word.

Click on this application to launch Microsoft Excel.

Click this function to implement the “select all” function in Excel.

Click this function to perform the “undo” function in Excel.

Click on this application to launch Microsoft PowerPoint.

Click this function to implement the “zoom in” function in PowerPoint.

Click this function to implement the “zoom out” function in Power-

Point.

MouseMate Software Features

Click on this application to launch Outlook Express or any other email client

application installed in your system.

Click this function to open a new email.

Click this function to forward a selected email in your mailbox.

Click on this application to open Microsoft Internet Explore or any other

Internet browser installed in your system.

Click this function to return to the previous web page in your open

Internet browser.

Click this function to more forward to the next web page in your open

Internet browser.

Click on this application to launch Windows media player or any other multi-

media player installed in your system.

Click this function to play/pause the current running media player.

Click this function to stop the current running media player.

Note: All the functions related to Office applications are

programmable. Place the cursor on the function icon you

want to change, and click the right button to select or reset

the unit from the popup menu. From the dialog box, you

can choose another function to use in the EasyJump Fris-

bee.

To change from Office EasyJump mode to Traditional

EasyJump mode, just click the right button on the Genius

logo in the center of the EasyJump Frisbee.

MouseMate Software Features

ENGLISH

The “Traditional EasyJump” lets you use eight Cyber functions more easily and

quickly.

Once you press the button you assigned, the “EasyJump” Frisbee will pop up and

eight functions will be displayed on Frisbee.

Click this button to close the current window.

Click this button and the cursor will jump to the horizontal scrollbar. When

you move your mouse, the open document or spreadsheet will scroll horizon-

tally.

Click this button and the cursor will jump to the vertical scrollbar. When you

move your mouse, the open document or spreadsheet will scroll vertically.

Click this button to open the Start Menu.

Click this button to open the Help button.

Click this button to open the Genius Mouse Control Panel.

Click the button and you can move the mouse in any direction in a document

or a spreadsheet. The farther you move the pointer from the pan icon, the

faster you can pan in that direction.

The buttons in “EasyJump Options” are especially used for Internet. The default func-

tion is “Open Browser” (button like ). You can select other functions from “Easy-

Jump Options” in the “Settings” folder of the Genius Mouse Control Panel.

The functions in “EasyJump Options” are:

“Add to Favorite [IE] ” “Organize Favorite [IE] ”

“Add Bookmark [NetScape] ” “Edit Bookmark [NetScape] ”

“Go Next [Forward] ” “Go Previous [Back] ”

“Run Application”

Switch Applications

When the right-button or Magic-Roller is set to “Switch AP”, you can quickly switch

from one open application to another without moving the mouse. To switch to a spe-

cific application, press the right button or the Magic-Roller to select the application.

MouseMate Software Features

Zoom function for Office 97 and IE Applications

Press the “Ctrl” key and move the “Magic-Roller” forward (or backward) to set the

Zoom In/Out function. You can also use just one hand to Zoom In/Out: set the right

button to be the “Ctrl” function, press the right button and move the “Magic-Roller”

forward (or backward) to enlarge (or decrease) the document window.

Auto-Panning

You can set this function in the Button Assignment menu. Move the mouse, and the

document moves in the direction you just moved.

Uninstall the Software

Follow these instructions to remove the software from your hard disk. In Windows,

click on the Start button, select Programs and move to the mouse software. Then click

on Uninstall software.

Customize the Software

This section shows you how to customize the software. To open the software control

panel, you can double-click on the icon in the task bar or select the “Software” icon

from the program group.

Close the Software

Click the right button on the taskbar, and select “Close Software” to close the soft-

ware.

MouseMate Software Features

ENGLISH
