Genesis single line Manual de usuario
1
GENESIS
TM
SINGLE LINE
SMALL CHARACTER INK - JET PRINTER
OPERATION AND MAINTENANCE MANUAL
2 96622 Issue 4.0 Jan. 01
GENESIS
TM
SINGLELINE SMALL CHARACTER
INK JET PRINTER
DECLARATION OF CONFORMITY
We, the manufacturer,
Digital Design, Inc., Cedar Grove, NJ
declare under our sole responsibility that the product,
Genesis SingleLine Ink Jet Printer
to which this declaration relates, is in conformity with the following standards:
EN60950 1992 : Safety of Information Technology Equipment, including
Electrical Business Machines
EN50082-1 1992 : Electromagnetic Compatibility, General Immunity
Standard
EN50081-1 1992 : Electromagnetic Compatibility (Conducted),
EN55022-1 1987 : Electromagnetic Compatibility (Radiated)
following the provisions of:
73/23/EEC : Low Voltage Directive
89/336/EEC : EMC Directive.
Cedar Grove
New Jersey
January, 1999 Edward Gerri
3 96622 Issue 4.0 Jan. 01
GENESIS
TM
SINGLELINE SMALL CHARACTER
INK JET PRINTER
OPERATION AND MAINTENANCE MANUAL
This manual is for use in operating and maintaining the SINGLELINE Small
Character Ink Jet Printer.
WARNING: PRINTING INKS SHOULD BE HANDLED WITH CARE.
ODo not allow ink onto the skin, or into the eyes or mouth.
OSome dried inks are highly inflammable. Clean up all ink spillage
immediately. Do not allow the ink to dry.
ODo not use the printer in wet or explosive environments.
For basic start-up and maintenance instructions, please refer to the Quick Start
Card.
The print station has been designed, tested and certified in accordance with
NEMA 4 and IP66 standards. For those users who require it, this means the
printer can be subjected to washdowns. However, opening the cabinet will void
both the ratings.
For sales, service and inks, please contact your local representative.
4 96622 Issue 4.0 Jan. 01
All rights reserved. No part of this publication may be reproduced, stored on a
retrieval system, or transmitted in any form, or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior permission
of Digital Design, Inc.
Digital Design has a policy of continuous product improvement. The Company,
therefore, reserves the right to modify the specification contained in this manual
without notice.
5 96622 Issue 4.0 Jan. 01
GENESIS
TM
SINGLELINE SMALL CHARACTER
INK JET PRINTER
OPERATION AND MAINTENANCE MANUAL
TABLE OF CONTENTS
Description Part 1
Installation Procedures Part 2
Operation Procedures Part 3
Maintenance Procedures Part 4
Troubleshooting Part 5
Options Part 6
Parts List Part 7
Communications Protocol Part 8
6 96622 Issue 4.0 Jan. 01
AMENDMENT RECORD
Amendment Date
All Parts at Issue 2.0 October 95
All Parts at Issue 3.0 October 96
All Parts at Issue 3.1 January 99
New Bracket at Issue 4.0 January 01
1 - 1 96622 Issue 4.0 Jan
PART 1: DESCRIPTION
CONTENTS
INTRODUCTION Page 1–3
PRINTER SPECIFICATIONS 1–4
Print Characteristics 1–4
Print Head 1–5
Print Station 1–5
Data Input 1–5
Environmental Conditions 1–5
Electrical Supply 1–5
General 1–5
PRINT HEAD 1–6
PRINT STATION 1–6
INK SYSTEM 1–7
EXTERNAL CONNECTIONS 1–7
Product Sensor 1–7
Bracketry 1–7
DESCRIPTION
1 - 2 96622 Issue 4.0 Jan 01
DESCRIPTION
1 - 3 96622 Issue 4.0 Jan 01
INTRODUCTION
The GENESIS SINGLELINE Small Character Ink Jet Printer consists of:
OThe print head
OThe print station
OThe universal controller
OThe bracketry and external connections.
The print head is a small square assembly which, when supplied with an
electrical pulse, ejects ink. Ink is supplied from an ink cartridge through tubing.
The print head is adjustable for proper ink control.
The print station is made of a plastic-based material and contains the electronics
and a control panel. The control panel is the top of the print station; it consists
of a small LCD and six touch activated keys. External connections are made
from the top of the print station.
The controller is universal to all GENESIS Small Character ink jet systems.
Communication between the print station and the controller is achieved by a
remote control, infra-red data transmission link.
The bracketry is supplied complete for mounting the print head, print station and
product sensor to your conveyor. The product sensor is a photoelectric device
that detects each item as it approaches the print head. The printer uses two fluids
in its operation:
OInk, for printing
OSolvent, for print head flushing and general cleaning purposes
DESCRIPTION
1 - 4 96622 Issue 4.0 Jan 01
PRINTER SPECIFICATIONS
PRINT CHARACTERISTICS
Character Set: Full alphanumeric and 24 special symbols
Fonts Available: 5 x 5, 7 x 5 , 9 x 7 and 7 x 5 Bold dot matrices
Line Speeds: From 1 to 255 fpm
From 0.3 to 75 mpm
Character Height:
5 x 5 1/16” 1.5 mm
7 x 5 3/32” 2.5 mm
9 x 7 1/8” 3.2 mm
Message Length: 32 characters
Print Head to Product Distance: Up to 1/4”
Up to 6.35 mm
Optional Features:
OOperations kit
OFloor stand
ODairy bracket and photoelectric device for gable top applications
OM400 transport for bottom coding
OHost (personal) computer-to- printer interface kit
Optional Software Features:
OAuto repeat
O96 character message length
OProgrammable solid bar
OExpanded memory
OSequential numbering with two counters
