Genesis Technologies GT-3.0 Manual de usuario
TM
GT-3.0
Operation Manual
AM/FM/WB/CD/DVD/MP3/MP4
Digital 5.1 Surround Sound - Optical / SPDIF Audio Input - High Definition Video Out
Bluetooth®
2
Contents
Safety Guidlines
Important safety instructions
Safety compliance 2
Warnings 2
Warranty Information 3
At a glance 4
GT-3.0 Features 6
Radio Operation 10
Weather Band 13
DVD/CD/MP3/MP4 Operation 14
Bluetooth® Syncing 17
Placing a Call - GT-3.0 18
Placing a Call - Remote 19
Remote Control Guide 20
System Setup 25
Lanugage 26
Audio 27
Viudeo 28
Speaker 29
Digital 30
Troubleshooting 31
Remote Memorization 32
Wiring Diagram 34
Accessories 36
GT-3.0 Specifications 37
FCC Compliance 37
WARNING - To reduce the risk of electrical shock, do not
remove cover (or open unit). NO USER SERVICEABLE parts are
inside. Refer servicing to QUALIFIED SERVICE PERSONNEL.
The design and manufacture of this player takes personal safety
into consideration. However, any improper operation may result
in electric shock, fire, or other hazard.
DO NOT open the cabinet by yourself to prevent electric shock.
Please contact a professional technician to preform any service
needed. Please use only components recommended by factory
when replacement is necessary.
Please turn unit off when not in use. Use a dry, soft cloth to clean
face with the system turned off.
PRECAUTION - Moisture may cause the lens on loader in this
unit to malfunction. To remedy the problem, turn unit on, eject
disc and run 1-2 hours to vaporize moisture inside the unit. Do
not repeatedly turn unit off and on. After turning unit off wait 10
seconds before turning on again. Do not use broken, scratched,
or twisted discs in player. This could result in damage to the unit.
Use only 5”, 12cm discs in this unit.
CAUTION: To reduce the risk of electric shock, do not
remove cover (or back). No User-serviceable parts
inside. Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock, do not
remove cover (or back). No User-serviceable parts
inside. Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
3
WARRANTY
This warranty extends only to the original purchaser of the unit
and is not transferable. Some states do not allow limitations on
how long an implied warranty lasts, and some states do not allow
the exclusion or limitation on incide tal or consequential dam-
ages, so the above limitation of exclusions may not apply to you.
This warranty gives you specific legal rights. To obtain repair
or replacement within the terms of this warranty, the radio is
to be delivered with proof of purchase and a discription of the
defect(s), freight prepaid to the original dealer or to:
QAV – Quest Audio Video
1930 W. Lusher Ave.
Elkhart, IN 46517
574-970-8349
TM
ONE (1) YEAR LIMITED WARRANTY
The Manufacture warrants to the original retail purchaser of this
unit that is or any part therein, under normal use and condition,
be proven defective in material or workmanship within 1 year
from the date of original purchase, such defect’s will be repaired
or replaced at the manufactures option without charge for parts
and repair labor.
This warranty does not extend to the elimination of externally
generated static or noise, to the correction as antenna gener-
ated noise or to the cost incurred to correct this noise. The war-
ranty does not cover the removal or the reinstallation of this unit
or damage to any CD’s, Speakers, accessories, or the vehicle’s
electrical system.
This warranty does not the cabinet appearance or apply to
the unit or any part of the unit which, in the opinion of the
manufacture, has been damaged through alterations, improper
installation, mishandling, misuse, neglect, or accident, THE
EXTENT OF THE MANUFACTURE’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE , AND IN NO EVENT SHALL THE MANU-
FACTURE’S LIABILITY EXCEED THE PURCHASE PRICE PAID
BY THE ORIGINAL BUYER FOR THE UNIT.
4
CD/MP3/MP4/DVD Disc Player
Compatible with standard size CD, MP3, MP4 and DVD discs
(4.75” or 12cm). The GT-3.0 is designed to read standard CD,
MP3, MP4, DVD, DVD+R, DVD-R Disc. Because of variations
in recording methods some discs may not play on this unit.
This unit will play region 1 DVD’s (USA and Canada).
USB / SD Card
This unit allows users to play files stored on both USB and SD
cards including MP3 music, MP4 short video clips and JPEG
photo files.The USB port will also charge many devices like
iPods and MP3 players.
Built-In AM/FM Tuner
27 preset FM stations and 18 AM stations available to select.
Built-In Weather Band Tuner
This unit can receive the latest National Oceanic Atmospheric
Administration (NOAA) weather forecast reports broadcast on
7 different frequencies - with strongest station automatically
selected.
TM
GT-3.0
A
m
p
l
i
f
i
e
r
P
o
w
e
r
S
t
a
n
d
a
r
d
C
E
A
-
2
0
0
6
C
o
m
p
l
i
a
n
t
TM
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Genesis Technologies is under license.
Bluetooth®
5
Bluetooth®Link
This unit contains Bluetooth® wireless technology enabling
secure, wireless connections between portable and fixed
devices. This unit, when enabled can place and receive
cellular phone calls through the GT-3.0s keypad and built in
microphone.
The GT-3.0 Bluetooth® link also enables handheld control of
streaming music from users wireless device play list.
High Definition Video Out
This unit has 1 High Definition Video Out for High Definition
Video (up to 1080p) and 5.1 / 2.0 Audio.
3 Audio and 3 Video Output locations
This unit supplies quality high power audio and video outputs
to three different rooms. Room A receives 5.1 full digital sur-
round sound. Room B and C receive standard stereo audio.
Sound Equalization Control
Allows control of the Bass, Treble, Balance and four preset EQ
settings.
Low Level Output
Low level output allows connections to external amplifiers.
5 Inputs (2 Audio/Video, 2 Audio and 1 Digital
Audio - optical or coaxial)
This unit has 2 Audio/Video inputs and 2 Audio inputs to allow
users to enjoy entertainment from other sources such as Sat-
ellite Radio, Cable and Satellite TV, VCR’s Digital Cameras,
Video Game players and a convenient 3.5mm Audio Input
on the front panel for iPods and MP3 Players. These sources
must be connected through the four inputs on the unit or
through additional accessory wall plates. (See pages 20-23 for
accessories.) The Digital Optical input is used to enable digital
audio from A/V components with digital optical output.
Clock
This unit has a built in clock that can display the time when
any button is pressed and a sleep timer that turns off the radio
for you.
6
GT-3.0 FEATURES
F FWDF RWD
RWD FWD NEXTPREVIOUS
VOLUME
AM/FM/WB CLOCK/SLEEP
AUDIO SETUP
MUTE
EJECT
A
SPEAKERS
B
C
CHAPTER SEARCH
VIDEO SETUP
MODE
1456
90
100+
#
*
IR
GT-3.0
AUXILIARY INPUT
AU 1 SD USB
MIC
23
8
7
B
C
D
F
G
H
J
K
L
EP
O
I
U
Y
T
R
M
N
V
XZ
S
Q
W
8
AM/FM/WB/CD/DVD/MP3/MP4
Digital 5.1 Surround Sound - Optical / SPDIF Audio Input - High Definition Video Out
PLAY / PAUSE STOP
TM
7
POWER
Turns the power on and off.
0-9
Radio Mode: Use for preset stations (frequencies), 27 FM
stations and 18 AM stations available.
Disc Mode: Selects different tracks on CD and different
chapters on DVD.
Phone: When paired with a Bluetooth® enabled cell phone the
number keys become a touch tone keypad allowing you to dial
phone calls from the GT-3.0
MODE
Select between AU1, AU2, AU3, AV1,AV2, BT, Radio
Note: Pressing and Holding the MODE button for 10 seconds
will re-boot the radio and reset all defaults. It will leave the radio
off. Press the on button to continue operation.
AM/FM/WB
Allows you to select FM1, FM2, FM3, AM1, AM2 or Weather
Band. Weather Band Tuner can receive the National Oceanic
Atmospheric Administration (NOAA) weather forecast reports
broadcast on 7 different channels.
B
C
D
E
F
G
J
H
I
VIDEO SETUP
Press for DVD setup menu. Menu navigation screens will
appear on Video Monitor.
IR
Infrared remote sensor.
EJECT
Press to eject a Disc from your GT-3.0 built in player.
RWD and FWD buttons
Radio Mode: Press to select next frequency, higher of lower.
DVD Mode: Moves menu selection.
F. RWD
Radio Mode: Scan through all lower preset stations.
Disc Mode: Select different levels of fast reverse.
VOLUME
Increase or decrease the volume in all rooms where sound is
being played.
Bluetooth®
Press this to enable Bluetooth® connectivity.
K
L
B
C
D
E
F
G
J
H
I
K
L
8
CD/MP3/MP4/DVD Disc loading slot
Insert a disc to play. Compatible with standard size CD, MP3,
MP4 and DVD discs (4.75” or 12cm). The GT-3 is designed
to read standard CD, MP3, MP4, DVD, DVD+R, DVD-R Disc.
Because of variations in recording methods some discs may not
play on this unit. This unit will play region 1 DVD’s (USA and
Canada).
PREVIOUS / NEXT Double Arrows
Radio Mode: Press these buttons for station seek.
F. FWD
Radio Mode: Scan through all higher preset stations.
Disc Mode: Select different levels of fast forward.
MUTE/HOLD
Press to turn off the sound. To turn on the sound, press again.
While talking on the phone, press to put the call on hold. Works
on all rooms where the sound is being played.
STOP
Press to stop playback of disc. Press Play to continue the
playback
SPEAKERS A-B- C
Turns sound on or off in corresponding rooms A, B or C.
100+
Disc Only
Press the 100+ area on the “0” button to select tracks
numbered higher than 100 on MP3’s
CLOCK
Press this to see time. This function works in all modes and
even when the unit is turned off. Press to change to the clock
display. Press and hold to turn the display indication and but-
ton illumination off or on.
AUDIO SETUP
Controls under this menu include Volume, Bass, Treble,
Balance and EQ controls.
Volume: 39 different levels
Bass: 14 different levels
Treble: 14 different levels
Balance: 14 different levels
EQ: Pop, Class, Rock, Flat
MIC
Microphone for Bluetooth® cell phone communications.
M
N
O
P
Q
R
U
T
V
S
GT-3.0 FEATURES
M
N
O
P
Q
R
U
T
V
S
9
PLAY / PAUSE
Press to play disc or pause playback of disc.
JTAG port
Used for firmware upgrades by authorized Genesis
Technologies technicians only.
AU1 Port
Audio Input from MP3 or iPod player. This is a 3.5 MM input.
SD Card slot
Reads media stored on SD cards. The GT-3.0 supports SD
cards with up to 8GB capacity. The SD card must be formatted
to be FAT or FAT32.
USB port
The USB port will also charge many devices like iPods, MP3
players and cameras. Plus, allows users to play files stored on
USB and USB attached media devices, including music, video
and photo files.The GT-3.0 supports USB flash drives with up
to 8GB capacity. The USB drive must be formatted to be FAT
or FAT32.
X
W
Y
Z
8
STEREO
BAND INDICATOR
LIGHTS
FREQUENCY INDICATOR
VOLUME
EQ SETTINGS
REMOVABLE MEDIA
PRESET NUMERAL INDICATOR
B
C
D
E
F
G
H
I
B
C
D
E
F
G
H
I
X
W
Y
Z
8
10
AM/FM/WB
POWER
Turns the power on and off.
Radio Reception Mode
Press to access the radio, press to activate desired band: AM1,
AM2, FM1, FM2, FM3 or WB (Weather Band Chanel 1-7)
AM/FM/WB
Activate radio Press for
desired Band
Manual Tuning
Chanel Down Chanel Up
Select Band, Select single arrowed button to move the chanels
down or up.
AM/FM/WB
Select Band
RADIO OPERATION
FM1 89.9
C
D
CH
1
Band Indicator
Frequency Indicator
Preset Numeral Indicator
Press for power “On or Off”
B
RWD FWD
Tabla de contenidos
