Generac Portable Products 7000EXL Manual de usuario

Owner’s Manual / Manuel de l'Utilisateur

Questions? Help is just a moment away!

Vous avez des questions? Vous n'avez pas besoin d'aller loin pour trouver de l'aide!

Call: Generac Generator Helpline / Appelez la ligne d'assistance de Generac Motor - 1-800-270-1408 M-F 8-5 CT

Web: www.generac-portables.com or www.briggsandstratton.com

Model No. 1657-0 (7,000 Watt AC Generator) Manual No. 189702GS Revision 0 (10/12/2001)

Safety Rules / Règles de Sécurité . . . . . . . . . . . . . . . . . . . 2-3 / 20-21

Assembly / Assemblage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 / 22

Know Your Generator / Connaissez Votre Générateur . . . . . . 5 / 23

Operation / Opération . . . . . . . . . . . . . . . . . . . . . . . . . 6-10 / 24-28

Product Specifications / Caractéristiques du Produit . . . . . . . 11 / 29

Maintenance / Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 / 29

Storage / Rangement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 / 30

Troubleshooting / Dépannage . . . . . . . . . . . . . . . . . . . . . . . . 13 / 32

Schematic / Schéma . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Wiring Diagram / Circuit de Câblage . . . . . . . . . . . . . . . . . . . . . . 15

Replacement Parts / Pièces de Rechange . . . . . . . . . . . . . . . . . 16-19

Notes / Remarques. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31, 33-34

Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Last Page

• Generator / Générateur

• Wheel kit / Ensemble de roulettes

• Storage cover / Couverture d'emmagasinage

• Battery / Batterie

• Battery charge cables / Câbles de charge de batterie

• Battery float charger / Chargeur de flotteur de batterie

• Locking 30 Amp plug / Prise de verrouillage 30 Ampères

• Two bottles of engine oil / Deux bouteilles d'huile moteur

• Three packets of fuel stabilizer / Trois paquets de stabilisateur

d'essence

• Owner's manual / Manuel de l'utilisateur

• Engine manual / Manuel du moteur

*If any parts are missing or damaged, call 1-800-270-1408.

*Si certaines pièces sont manquantes ou endommagées, appelez le

1-800-270-1408.

Parts Included* / Pièces Incluses* Table of Contents / Table des Matières

7000EXL Extended Life Generator

EQUIPMENT

DESCRIPTION

This generator is an engine–driven, revolving field,

alternating current (AC) generator. It was designed to

supply electrical power for operating compatible electrical

lighting, appliances, tools and motor loads.

This manual contains information for a generator that

operates 120 and/or 240 Volt, single phase, 60 Hz devices

that require up to 7,000 watts (7.0 kW) of power that pull

up to 58.3 Amps at 120 Volts or 29.2 Amps at 240 Volts.

CAUTION! Do Not exceed the generator’s

wattage/amperage capacity.Add up the rated watts of all

devices you are connecting to generator receptacles at one

time.This total should not be greater than 7,000 watts. See

“Don’t Overload the Generator” on page 10.

The generator’s revolving field is driven at about 3,600 rpm

by a single-cylinder engine.

Every effort has been made to ensure that information in

this manual is accurate and current. However, Generac

reserves the right to change, alter or otherwise improve the

product and this document at any time without prior

notice.

CAUTION! Do Not tamper with engine

governed speed. High operating speeds are

dangerous and increase risk of personal injury or

damage to equipment.The generator supplies

correct rated frequency and voltage only when

running at proper governed speed. Incorrect

frequency and/or voltage can damage some

connected electrical loads. Operating at excessively

low speeds imposes a heavy load.When adequate

engine power is not available engine life may be

shortened.

The Emission Control System for this generator is

warranted for standards set by the Environmental

Protection Agency. For warranty information refer to the

engine owner’s manual.

SAFETY RULES

This generator set was designed and manufactured for

specific applications. Do Not attempt to modify the unit or

use it for any application it was not designed for. If you have

any questions about your generator’s application, ask your

dealer or consult the factory.

The manufacturer could not possibly anticipate every

circumstance that might involve a hazard. For that reason

warnings in the manual and warnings on tags or decals

affixed to the unit are not all–inclusive. If you intend to

handle, operate or service the unit by a procedure or

method not specifically recommended by the manufacturer,

first make sure that such a procedure or method will not

render this equipment unsafe or pose a threat to you and

others.

Read this manual carefully and become familiar

with your generator set. Know its applications, its

limitations and any hazards involved.

WARNING! You must isolate the generator

from the electric utility using approved transfer

equipment if this unit is used for backup power.

Failure to isolate the generator from the

power utility may result in injury or death to

electric utility workers and damage to the

generator due to a backfeed of electrical energy.

Whenever the unit is providing backup power, the

electric utility must be notified.

DANGER! Generator exhaust gases contain

DEADLY carbon monoxide gas. If breathed in

sufficient concentrations, carbon monoxide

can cause unconsciousness or death. Operate

this equipment outdoors where adequate ventilation

is available.

The engine exhaust from this product contains

chemicals known to the State of California

to cause cancer, birth defects,

or other reproductive harm.

WARNING:

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

7000EXL Extended Life Generator

• The generator produces a very powerful voltage that can

cause serious injury or death by electrocution. Never

touch bare wires or receptacles. Never permit a child or

any unqualified person to operate the generator.

•Never handle any kind of electrical cord or device while

standing in water, while barefoot or while hands or feet

are wet. Death or serious injury from electrocution may

result.

• Use a ground fault circuit interrupter (GFCI) in any damp

or highly conductive area (such as metal decking or steel

work).

•Never use worn, bare, frayed or otherwise damaged

electrical cords with the generator. Death, serious injury

and property damage from electrical shock may result.

•Gasoline is highly FLAMMABLE and its vapors are

EXPLOSIVE. Never allow smoking, open flames,

sparks or heat in the vicinity while handling

gasoline. Avoid spilling gasoline on a hot engine. Comply

with all laws regulating storage and handling of gasoline.

•Do Not overfill the fuel tank.Always allow room for fuel

expansion. If tank is overfilled, fuel can overflow

onto a hot engine and cause a FIRE or an

EXPLOSION.

•Never store a generator with fuel in the tank where

gasoline vapors might reach an open flame, spark or pilot

light (as on a furnace, water heater, clothes dryer). FIRE

or an EXPLOSION may result.

• The unit requires an adequate flow of cooling air for its

continued proper operation. Never operate the unit

inside any room or enclosure where the free flow of

cooling air into and out of the unit might be obstructed.

Allow at least 2 feet of clearance on all sides of generator,

even while operating unit outdoors, or you could damage

the unit.

•Never start, or stop the unit with electrical loads

connected to receptacles with the connected devices

turned ON. Start the engine and let it stabilize before

connecting any electrical loads. Disconnect all electrical

loads before shutting down the generator.

•Do Not insert any object through cooling slots of the

engine.You could damage the unit or injure yourself.

•Never operate the generator:

in rain; in any enclosed compartment; when connected

electrical devices overheat; if electrical output is lost; if

engine or generator sparks; if flame or smoke is observed

while unit is running; if unit vibrates excessively.

GROUNDING THE

GENERATOR

The National Electrical Code requires that the frame and

external electrically conductive parts of this generator be

properly connected to an approved earth ground. Local

electrical codes may also require proper grounding of the

unit. For that purpose, a GROUNDING WING NUT is

provided on the generator end (Figure 1).

Generally, connecting a No. 12 AWG (American Wire

Gauge) stranded copper wire to the grounding wing nut

and to an earth–driven copper or brass grounding rod

(electrode) provides adequate protection against electrical

shock. Be careful to keep the grounding wire attached after

connecting the stranded copper wire. However, local codes

may vary widely. Consult with a local electrician for

grounding requirements in your area.

Properly grounding the generator helps prevent electrical

shock if a ground fault condition exists in the generator or

in connected electrical devices. Proper grounding also helps

dissipate static electricity, which often builds up in

ungrounded devices.

Figure 1 — Grounding Wing Nut

Grounding

Wing Nut

7000EXL Extended Life Generator

CHECK BATTERY / ATTACH

NEGATIVE BATTERY

WIRE

The sealed battery on the generator is fully charged and

pre–installed except for the negative (black) battery cable.

To install:

• Cut off tie wrap securing loose end of negative (black)

cable.

• Remove nut and washer on the negative battery

terminal.

• Slide the negative battery cable over the screw on the

negative terminal (Figure 2).

• Reattach washer and nut and tighten.

• Verify that the connections to the battery and generator

are correct and secure.

BEFORE STARTING THE

ENGINE

Add Oil

CAUTION! Any attempt to crank or start the engine

before it has been properly filled with the recommended

oil may result in an engine failure.

To fill your engine with oil:

• Place generator on a level surface.

• Follow the oil grade recommendations and oil fill

instructions given in the engine owner’s manual.

NOTE: The generator’s revolving field rides on a

prelubricated and sealed ball bearing that requires no

additional lubrication for the life of the bearing.

Add Gasoline

WARNING! Never fill fuel tank indoors. Never

fill fuel tank when engine is running or hot.Allow

unit to cool for two minutes before refueling. Do

Not light a cigarette or smoke when filling the fuel

tank.

WARNING! Do Not overfill the fuel tank.

Always allow room for fuel expansion.

• Use regular UNLEADED gasoline with the generator

engine. Do Not use premium gasoline. Do Not mix oil

with gasoline.

• Clean area around fuel fill cap, remove cap.

• Slowly add unleaded regular gasoline to fuel tank. Be

careful not to overfill.Allow about 1/2" of tank space for

fuel expansion (Figure 3).

• Install fuel cap and wipe up any spilled gasoline.

IMPORTANT: It is important to prevent gum deposits

from forming in essential fuel system parts, such as the

carburetor, fuel filter, fuel hose or tank during storage.Also,

experience indicates that alcohol–blended fuels (called

gasohol, ethanol or methanol) can attract moisture, which

leads to separation and formation of acids during storage.

Acidic fuel can damage the fuel system of an engine while

in storage. Be sure to review the precautions given in

“Storage” on page 12.

Never use engine or carburetor cleaner products in the

fuel tank or permanent damage may occur.

Figure 2 — Negative Battery Connection

Positive battery cable

Screw

Washer

Nut

Negative

battery

cable

Figure 3 — Typical Fuel Expansion Space

1/2” Air

Space

Tank

Fuel

7000EXL Extended Life Generator

KNOWYOUR GENERATOR

Read this owner’s manual and safety rules before operating your generator.

Compare the illustrations with your generator, to familiarize yourself with the locations of various controls and

adjustments. Save this manual for future reference.

12 Volt DC,10 Amp Receptacle — Recharge a

discharged 12 Volt automotive type battery through this

receptacle.

120 Volt AC, 20 Amp Duplex Receptacle — May be

used to supply electrical power for the operation of

120 Volt AC, 20 Amp, single phase, 60 Hz electrical lighting,

appliance, tool and motor loads.

120 Volt AC, 30 Amp Locking Receptacle — May be

used to supply electrical power for the operation of

120 Volt AC, 30 Amp, single phase, 60 Hz electrical lighting,

appliance, tool and motor loads.

120/240 Volt AC, 30 Amp Locking Receptacle — May

be used to supply electrical power for the operation of

120 and/or 240 Volt AC, 30 Amp, single phase, 60 Hz

electrical lighting, appliance, tool and motor loads.

Air Cleaner — Uses a dry type filter element and foam

pre–cleaner to limit the amount of dirt and dust sucked

into the engine.

Choke Lever — Used when starting a cold engine.

Circuit Breakers (AC) — Each receptacle is provided

with a "push to reset" circuit breaker to protect the

generator against electrical overload.

Fuel Tank — Capacity of seven (7) U.S. gallons.

Grounding Wing Nut — Used for proper grounding of

unit.

Idle Control Switch — With this switch set to ON,

generator automatically reduces engine speed when no

load is connected and increases engine to proper speed

when load is applied. However, be sure switch is OFF when

starting engine.

Oil Fill Cap — Add oil to engine here.

Recoil starter — Used to start the engine manually.

Run/Stop Switch — Set this switch to "Run" before

starting engine. Set switch to "Stop" to switch OFF engine.

Spark Arrester Muffler — Exhaust muffler lowers

engine noise and is equipped with a spark arrester screen.

Start Button — When pressed, cranks engine to start.

120 Volt AC, 20 Amp

Duplex Receptacle

Fuel Tank

Idle Control Switch

Choke Lever

Start Button

12 Volt DC, 10 Amp

Receptacle

Run/Stop Switch

120 Volt AC, 30 Amp

Receptacle

Circuit Breakers (AC)

120/240 Volt AC,

30 Amp Receptacle

Spark Arrester Muffler

Air Cleaner

Grounding Wing Nut

Oil Fill Cap

Recoil Starter

7000EXL Extended Life Generator

OPERATING THE

GENERATOR

CAUTION! Never start or stop unit with

electrical loads connected AND with the connected

devices turned ON.

IMPORTANT: Always unplug the battery float charger

before starting the generator.

Starting the Engine

Disconnect all electrical loads from the generator. Follow

these start instruction steps in numerical order:

1. Turn the fuel valve to the “On” position (Figure 4).

2. Make sure the Idle Control switch is in “Off” position

(Figure 5).

3. Set the Run/Stop switch to “Run” position (Figure 6).

4. Place the choke lever in the “Full” choke position

(Figure 7).

5A. For electric starting, press start switch on

generator cradle.To prolong the life of the starter

components, press the starter button for no more

than 15 seconds, and pause for 30 seconds.

5B. For manual starting, grasp the recoil handle and pull

slowly until slight resistance is felt.Then pull rapidly

one time only to start engine.

• If engine starts, proceed to step 7.

• If engine fails to start, proceed to step 6.

6. Move the choke lever to “Half” choke position, and

press start button or pull recoil handle twice.

• If engine fails to start, repeat steps 4 thru 6.

7. Move choke lever to “Run” position. If engine falters,

move choke lever to “Half” choke position until the

engine runs smoothly and then to “Run” position.

NOTE: If engine still fails to start after 3 pulls, check for

proper oil level in crankcase.This unit is equipped with a

Low Oil Shutdown System. See engine manual.

Refer to the engine owner’s manual for complete

starting instructions.

Connecting Electrical Loads

• Let engine stabilize and warm up for a few minutes after

starting.

• Plug in and turn on the desired 120 and/or 240 Volt AC,

single phase, 60 Hz electrical loads.

•Do Not connect 240 Volt loads to the 120 Volt

receptacles.

•Do Not connect 3–phase loads to the generator.

•Do Not connect 50 Hz loads to the generator.

•DO NOT OVERLOAD THE GENERATOR. See

“Don’t Overload the Generator” on page 10.

Figure 4 — Fuel Shut-offValve

Figure 5 — Idle Control Switch

Figure 6 — Run/Stop Switch

Figure 7 — Choke Positions

7000EXL Extended Life Generator

Stopping the Engine

• Unplug all electrical loads from generator panel

receptacles. Never start or stop engine with electrical

devices plugged in and turned on.

• Put the idle control switch in the “Off” position.

• Let engine run at no–load for 30 seconds to stabilize the

internal temperatures of engine and generator.

• Move run/stop switch to “Stop”.

• Close the fuel shut–off valve.

Operating Automatic Idle Control

This switch is designed to greatly improve fuel economy.

When this switch is turned ON, the engine will only

run at its normal high governed engine speed when an

electrical load is connected.When an electrical load is

removed, the engine will run at a reduced speed. With

the switch off, the engine will run at the normal high

engine speed. Always have the switch off when

starting and stopping the engine.

Charging a Battery

WARNING! Storage batteries give off explosive

hydrogen gas while recharging.An explosive mixture

will remain around the battery for a long time after

it has been charged.The slightest spark can ignite

the hydrogen and cause an explosion, resulting in

blindness or other serious injury.

WARNING! Do Not permit smoking, open

flame, sparks or any other source of heat around a

battery.Wear protective goggles, rubber apron and

rubber gloves when working around a battery.

Battery electrolyte fluid is an extremely caustic

sulfuric acid solution that can cause severe burns. If

spill occurs flush area with clear water immediately.

Your generator has the capability of recharging a

discharged 12 Volt automotive or utility style storage

battery. Do Not use the unit to charge any 6Volt

batteries. Do Not use the unit to crank an engine having a

discharged battery.

To recharge 12Volt batteries, proceed as follows:

• Check fluid level in all battery cells. If necessary, add

ONLY distilled water to cover separators in battery

cells. Do Not use tap water.

• If the battery is equipped with vent caps, make sure they

are installed and are tight.

• If necessary, clean battery terminals.

• Connect battery charge cable connector plug to panel

receptacle identified by the words “12-VOLTS D.C.”.

• Connect battery charge cable clamp with red handle to

the positive (+) battery terminal (Figure 8).

• Connect battery charge cable clamp with black handle

to the negative (–) battery terminal (Figure 8).

• Start engine. Let the engine run while battery recharges.

• When battery has charged, shut down engine.

NOTE: Use an automotive hydrometer to test battery

state of charge and condition. Follow the hydrometer

manufacturer’s instructions carefully. Generally, a battery is

considered to be at 100% state of charge when specific

gravity of its fluid (as measured by hydrometer) is 1.260 or

higher.

COLD WEATHER

OPERATION

Under certain weather conditions (temperatures below

40°F [4°C] and a high dew point), your generator may

experience icing of the carburetor and/or the crankcase

breather system.

Build a structure that will enclose three sides and the top

of the generator.

• Make sure entire muffler-side of generator is exposed.

Note that your generator may appear different from that

shown in Figure 9.

Figure 8 — Battery Connections

7000EXL Extended Life Generator

• Ensure a minimum of two feet clearance between open

side of box and nearest object.

• Face exposed end away from wind and elements.

• Enclosure should hold enough heat created by the

generator to prevent problems.

CAUTION!Neverrun unit indoors. Do Not

enclose generator any more than shown. Remove

generator from shelter when temperature is above

40°F [4°C].

How to Use the Battery Charger

Use battery float charger jack to keep the starting battery

charged and ready for use. Battery charging should be done

in a dry location, such as inside a garage.

• Plug the charger into the unit’s “Battery Float Charger”

jack, which is located on the starter switch (Figure 10).

Plug battery charger into a 120 Volt AC wall receptacle.

• Unplug the charger from the unit and the wall outlet

when generator is being started and while it is in

operation.

• Keep this charger plugged in when generator is not in

use to prolong battery life.The charger has a built in

float equalizer and will not overcharge the battery, even

when plugged in for an extended period of time.

IMPORTANT: See “Battery Maintenance” on page 11 for

additional information.

RECEPTACLES

120 Volt AC, 20 Amp Duplex

Receptacle

Each of these outlets is protected against overload by

20 Amp push-to-reset type circuit breakers (Figure 12).

Use each outlet to operate 120 Volt, 60 Hz, single phase

loads requiring 2,400 (2.4 kW) watts at 20 Amps of

current.

Figure 12 — 120Volt AC, 20 Amp Duplex Receptacle

Figure 10 — Battery Charger Jack

Figure 9 — Permanent Cold Weather Shelter

Wind

7000EXL Extended Life Generator

120/240 Volt AC, 30 Amp Locking

Receptacle

Use a NEMA L14-30 plug with this receptacle. Connect a

4-wire cord set rated for 250 Volts at 30 Amps (or greater)

(Figure 13).You can use the same 4-wire cord if you plan to

run a 120 Volt load.

This receptacle powers 120/240 Volt AC, 60 Hz, single

phase loads requiring up to 3,600 watts of power at

20 Amps for 120 Volts; 7,000 watts of power (7.0 kW) at

29.2 Amps for 240 Volts.The outlet is protected by a

30 Amp push-to-reset circuit breaker.

CAUTION! Although this outlet is rated for

240 Volt 30 Amp (up to 7.200 watts), the generator

is only rated for 7,000 watts. Powering loads that

exceed the wattage/amperage capacity of the

generator can damage it or cause serious injuries.

240 Volt loads powered through this outlet should

not exceed 29.2 Amps of current draw.

120 Volt AC, 30 Amp Locking

Receptacle

Use a NEMA L5-30 plug with this receptacle. Connect a

3-wire cord set rated for 125 Volts AC at 30 Amps to the

plug (Figure 14).

Use this receptacle to operate 120Volt AC, 60 Hz, single

phase loads requiring up to 3,600 watts (3.6 kW) of power

at 30 Amps.The outlet is protected by a 30 Amp

push-to-reset circuit breaker.

12 Volt DC, 10 Amp Receptacle

This connector (identified by the legend “12-VOLT D.C.”)

supplies 12 Volts DC at 10 Amps through battery charging

cables for recharging 12 Volt batteries (Figure 15). See

“Charging a Battery” on page 7.

Figure 14 — 120 Volt AC, 30 Amp, Locking Receptacle

3-Wire Cord Set

Neutral

120V

Hot

Ground (Green)

NEMA L5-30

Figure 15 — 12Volt DC, 10 Amp Receptacle

Figure 13 — 120/240 Volt AC, 30 Amp Receptacle

4-Wire Cord Set

240V

120V 120V W (Neutral)

X (Hot)

Y (Hot)

NEMA L14-30 Ground (Green)

7000EXL Extended Life Generator

DON'T OVERLOADYOUR

GENERATOR

Capacity

You must make sure your generator can supply enough

rated (running) and surge (starting) watts for the items you

will power at the same time. Follow these simple steps:

1. Select the items you will power at the same time.

2. Total the rated (running) watts of these items.This is

the amount of power your generator must produce to

keep your items running. See Figure 16.

3. Estimate how many surge (starting) watts you will

need. Surge wattage is the short burst of power

needed to start electric motor-driven tools or

appliances such as a circular saw or refrigerator.

Because not all motors start at the same time, total

surge watts can be estimated by adding only the

item(s) with the highest additional surge watts to the

total rated watts from step 2.

Example:

Total Rated (Running) Watts = 3075

Highest Additional Surge Watts = 1800

Total Generator Output Required = 4875

Power Management

To prolong the life of your generator and attached devices,

it is important to take care when adding electrical loads to

your generator.There should be nothing connected to the

generator outlets before starting it's engine.The correct

and safe way to manage generator power is to sequentially

add loads as follows:

1. With nothing connected to the generator, start the

engine as described in this manual.

2. Plug in and turn on the first load, preferably the largest

load you have.

3. Permit the generator output to stabilize (engine runs

smoothly and attached device operates properly.

4. Plug in and turn on the next load.

5. Again, permit the generator to stabilize.

6. Repeat steps 4 and 5 for each additional load.

Never add more loads than the generator capacity.Take

special care to consider surge loads in generator capacity,

as described above.

*Wattages listed are approximate only. Check tool or

appliance for actual wattage.

Tool or Appliance Rated (Running)

Watts Additional Surge

(Starting) Watts

Window Air

Conditioner 1200 1800

Refrigerator 800 1600

Deep Freezer 500 500

Television 500 -

Light (75 Watts) 75 -

3075 Total

Running Watts 1800 Highest

Surge Watts

Tool or Appliance Rated*

(Running)

Watts

Additional

Surge

(Starting)

Watts

Essentials

Light Bulb - 75 watt 75 -

Deep Freezer 500 500

Sump Pump 800 1200

Refrigerator/Freezer - 18 Cu. Ft. 800 1600

Water Well Pump - 1/3 HP 1000 2000

Heating/Cooling

Window AC - 10,000 BTU 1200 1800

Window Fan 300 600

Furnace Fan Blower - 1/2 HP 800 1300

Kitchen

Microwave Oven - 1000 Watt 1000 -

Coffee Maker 1500 -

Electric Stove - Single Element 1500 -

Hot Plate 2500 -

Family Room

DVD/CD Player 100 -

VCR 100 -

Stereo Receiver 450 -

Color Television - 27” 500 -

Personal Computer w/17” monitor 800 -

Other

Security System 180 -

AM/FM Clock Radio 300 -

Garage Door Opener - 1/2 HP 480 520

Electric Water Heater - 40 Gallon 4000 -

DIY/Job Site

Quartz Halogen Work Light 1000 -

Airless Sprayer - 1/3 HP 600 1200

Reciprocating Saw 960 960

Electric Drill - 1/2 HP 1000 1000

Circular Saw - 7 1/4” 1500 1500

Miter Saw - 10” 1800 1800

Table Planer - 6” 1800 1800

Table Saw/Radial Arm Saw - 10” 2000 2000

Air Compressor - 1-1/2 HP 2500 2500

Figure 16 - Wattage Reference Chart

Otros manuales para 7000EXL

Tabla de contenidos

Idiomas:

Otros manuales de Generador portátil de Generac Portable Products

Generac Portable Products

Generac Portable Products 8kW Manual de usuario

Generac Portable Products

Generac Portable Products 6250ES Manual de usuario

Generac Portable Products

Generac Portable Products XG SERIES Manual de usuario

Generac Portable Products

Generac Portable Products 4000XL 9777-2 Manual de usuario

Generac Portable Products

Generac Portable Products 4000EXL Manual de usuario

Generac Portable Products

Generac Portable Products 9719-3 Manual de usuario

Generac Portable Products

Generac Portable Products PowerBoss 5500 Watt Storm Plus Manual de usuario

Generac Portable Products

Generac Portable Products 9777-3 Manual de usuario

Generac Portable Products

Generac Portable Products 5500 XL 9778-7 Manual de usuario

Generac Portable Products

Generac Portable Products 6500EXL Manual de usuario

Generac Portable Products

Generac Portable Products 4000EXL Manual de usuario

Generac Portable Products

Generac Portable Products 1305-0 Manual de usuario

Generac Portable Products

Generac Portable Products XG SERIES Manual de usuario

Generac Portable Products

Generac Portable Products 005698-0 Manual de usuario

Generac Portable Products

Generac Portable Products 6500XL Manual de usuario

Generac Portable Products

Generac Portable Products GP Series Manual de usuario

Generac Portable Products

Generac Portable Products PowerBOSS Storm-Plus 5500 Manual de usuario

Generac Portable Products

Generac Portable Products 1576-0 Manual de usuario

Generac Portable Products

Generac Portable Products Handyman-Plus PowerBOSS 3250 Manual de usuario

Generac Portable Products

Generac Portable Products 5500XL Manual de usuario

Generac Portable Products

Generac Portable Products 1575-0 Manual de usuario

Generac Portable Products

Generac Portable Products GP Series Manual de usuario

Generac Portable Products

Generac Portable Products 1313-1 Manual de usuario

Generac Portable Products

Generac Portable Products 006000-0 Manual de usuario

Manuales populares de Generador portátil de otras marcas

Kohler

Kohler 20EORZ Manual de instrucciones

Powerhorse

Powerhorse 83171 Manual de usuario

HURST

HURST ML-630-SI Manual de usuario

ETQ

ETQ TG4000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 40265 Guía de configuración

ConMed

ConMed 7550 Manual de usuario

Owon

Owon Waveform Generator Manual de usuario

evertz

evertz 7700 Series Manual de usuario

Power Stroke

Power Stroke PS906025 Manual de usuario

Firefly

Firefly Cygnus CYG2400/460/24 Manual de usuario

Draper

Draper PG950S Actualización de firmware

PowerBoss

PowerBoss PowerBoss Manual de usuario

SDMO

SDMO SH 4000 Manual de usuario

EINHELL

EINHELL STE 5500 Manual de usuario

Wanco

Wanco WI3000P Manual de usuario

Full Boar

Full Boar FBT-3300 Manual de usuario

Dwyer Instruments

Dwyer Instruments ASG Manual de usuario

Westinghouse

Westinghouse WH1000i Series Manual de usuario
