Geemarc MyDECT Manual de usuario

MyDECT

Digital Cordless Telephone with

Large Buttons

CONTENTS 1

INTRODUCTION 3

Unpacking the Telephone 4

DESCRIPTION 5

General Description 5

INSTALLATION 11

Location 11

SettingUp 12

BatteryUse 12

Using the Belt Clip 13

HANDSET SETTINGS 14

On/Off Settings 14

Ringer Settings 15

Key Tone Settings 18

Dialling Mode (T/P) 19

TimeSettings 20

Personal Identification Number Settings 21

Access Code Settings 22

Smart Dialling Settings 23

Caller Display Settings 24

USING THE TELEPHONE 25

Making a Call 25

Receiving a Call 26

Mute Function 26

Receiving Volume 27

Last Number Redial 27

Recalling Recent Numbers 27

Deleting Recent Numbers 28

Registered Recall 29

Tone Dialling Switchover 29

Paging the Handset 29

CallTimer 29

KeyLock 30

Smart Dialling 30

The WEEE (Waste Electrical and Electronic Equipment) has been put in

place for the products at the end of their useful life are recycled in the best

way.

When this product is finished with, please do not put it in your domestic

waste bin.

Please use one of the following disposal options:

- Remove the batteries and deposit them in an appropriate WEEE skip.

Deposit the product in an appropriate WEEE skip.

- Or, hand the old product to the retailer. If you purchase a new one, they

should accept it.

Thus if you respect these instructions you ensure human health and

environmental protection.

For product support and help visit our website at www.geemarc.com

Telephone 01707 384438

Or fax 01707 372529

CONTENTS

15656

RECYCLING DIRECTIVES

Electrical connection: The apparatus is designed to operate from a 230V

50Hz supply only. (Classified as ‘hazardous voltage’ according to

EN60950 standard). The apparatus does not incorporate an integral

power on/off switch. To disconnect the power, either switch off supply at

the mains power socket or unplug the AC adaptor. When installing the

apparatus, ensure that the mains power socket is readily accessible.

Telephone connection: Voltages present on the telecommunication

network are classified TNV-3 (Telecommunication Network Voltage)

according to the EN60950 standard.

CallBarring 31

CALLER DISPLAY 33

View Caller Display List 33

Dial a Number from the Caller Display List 34

Delete an Entry from the Caller Display List 35

Delete all Entries from the Caller Display List 35

PHONEBOOK 36

Create a Phone Book Entry 36

View Phone Book Entries 37

Dialing using the Phone Book 37

Modify a Phone Book Entry 38

Delete a Phone Book Entry 38

CALL BY CALL 39

Create a Call by Call Entry 39

Dialling using Call by Call 40

Modify a Call by Call Entry 41

Delete a Call by Call Entry 42

ADDITIONAL HANDSETS & BASES 43

SelectaBase 45

Release a Handset 46

InternalCalls 47

Call Transfer between Handsets 48

Other Optional Accessories 49

RESTORE FACTORY SETTINGS 50

TROUBLESHOOTING 51

SAFETY INFORMATION 53

GUARANTEE 54

RECYCLING DIRECTIVES 56

GUARANTEE

CONTENTS

Congratulations on purchasing your Geemarc MyDECT telephone. This

telephone offers all the advantages of cordless technology (compliant with

Digitally Enhanced Cordless Telecommunications-DECT standard)

together with large buttons which are helpful if you are partially sighted.

This telephone is also hearing aid compatible.

Its is important that you read the instructions below in order to use your

Geemarc telephone to its full potential. Keep this user guide in a safe

place for future reference.

This guide explains how to use the following telephone:

MyDECT

This guide applies to single and multiple handset systems.

From the moment your Geemarc product is purchased, Geemarc

guarantee it for the period of one year. During this time, all repairs or

replacements (at our discretion) are free of charge. Should you experience

a problem then contact our help line or visit our website at

www.geemarc.com. The guarantee does not cover accidents, negligence

or breakages to any parts. The product must not be tampered with or

taken apart by anyone who is not an authorized Geemarc representative.

The Geemarc guarantee in no way limits your legal rights.

IMPORTANT: YOUR RECEIPT IS PART OF YOUR GUARANTEE AND

MUST BE RETAINED AND PRODUCED IN THE EVENT OF

AWARRANTY CLAIM.

DECLARATION: Geemarc Telecom SA hereby declares that this

product is in compliance with the essential requirements and other

relevant provisions of the Radio and Telecommunications Terminal

Equipment Directive 1999/5/EEC and in particular article 3 section

1a, 1b and section 3. The telephone does not operate if the line

current is lower than 18 mA.

INTRODUCTION

Please note: The guarantee applies to

the United Kingdom only

GUARANTEE

General

Only use the power supply included with the product.

Only use the approved rechargeable batteries supplied.

Do not open the handset (except to replace the handset batteries) or base.

Contact the helpline for all repairs.

Never dispose of batteries in a fire. There is a serious risk of explosion

and/ or the release of toxic chemicals.

Cleaning

Clean the telephone with a soft cloth. Keep the base and handset charging

contacts clean. Never use polishes or cleaning agents - they could

damage the finish or the electrics inside.

Environmental

Do not expose to direct sunlight.

Always ensure there is a free flow of air over the surfaces of the

telephone.

Do not place any part of your product in water and do not use it in damp or

humid conditions e.g. bathrooms.

Do not expose your product to fire or other hazardous conditions.

Unplug your phone from the telephone socket during thunderstorms

because it could damage your telephone. Your guarantee does not cover

thunderstorm damage.

The telephone is designed for working within a temperature range of 5°C

to 45°C.

Unpacking the Telephone

When unpacking the telephone, you should find the following in the box:

• 1 MyDECT handset

• 1 MyDECT base

• ✑Mains power adaptor

• ✑Telephone line cord

• ✑Belt clip

• 3 x AAA rechargeable batteries

• 1 Battery compartment cover

For product support and help visit our website at www.geemarc.com

Telephone 01707 384438

Or fax 01707 372529

SAFETY INFORMATION

INTRODUCTION

General Description

Handset Description

Consistently short battery life

• Clean the charge contacts

• Replace the batteries

Nothing happens when you press any button

• Check the the keylock is switched off

DESCRIPTION

Speaker

Receive and End

Call Key

Cancel Ke

Numerical

Keypad

Microphone

Menu Ke

Confirm Ke

LCD Dis

Intercom Ke

Scroll Ke

Redial Ke

On/Off Key

Scroll Ke

TROUBLESHOOTING

General Checks

• Make sure that the telephone line cord and adaptor are correctly

plugged in and they are not damaged.

• Make sure the batteries are inserted correctly.

• Make sure that the batteries are fully charged.

• Connect another telephone to the telephone PTT socket or move

your telephone to another socket to track if the failure is coming

from your telephone or your PTT socket.

• Make sure the power adaptor is properly connected

Handset not registering

• See general checks.

No display

• See general checks

No connection between handset and base

• You may be out of range of the base. Move closer to the base

Handset on the base does not charge

• Make sure the handset is placed properly on the base. When

charging, the battery symbol should be shown filling up.

Handset does not ring

• See general checks

No tone when you press

• See general checks.

• Check for the handset number on the LCD display e.g. HS1. If

this is not present you must register the handset (see Handset

Registration section)

A warning tone is heard during a call:

• The batteries are empty. The handset needs to be replaced in the

base in order to recharge.

• You are out of the base coverage area.

No number is displayed when the telephone rings:

• Please contact your telephone network provider to get the caller

display service.

• Even if you have subscribed to a caller display service, if the caller

does not want to show their number (private number), the display

will show ******.

• Even if you have subscribed to a caller display service, try

changing the Caller Display Settings (see page 24)

• It could be a call from a PBX. Caller display may not work

properly if the telephone is connected to a PBX.

Base Description

TROUBLESHOOTING

Page Key

Charge Contacts

in Handset Cradle

DESCRIPTION

Incoming

Call/Charging

Indicator

(*) Classified “hazardous voltage” according to EN60950 standard

(**) Classified TNV-3 according to EN60950 standard

The factory settings can be restored to the telephone.

Press to activate the menu

Use Sand Tto scroll through the menu to select

‘HS RESET’

Press OK

Use the keypad to type in your PIN (default 0000)

Press OK

Press OK to confirm the reset

*Power Adaptor Socket ** Line Socket

DESCRIPTION

RESTORE FACTORY SETTINGS

Other Optional Accessories

The headset socket is located on the right side of the handset. It is a

standard 2.5mm plug. Simply plug the headset into the socket. The

headset will be activated whilst the microphone on the handset will be

deactivated.

LCD Screen Description

The LCD screen is split into two distinct areas:

The icon area. This is found at the top of the screen. This displays the

various system icons which help you to use the telephone.

The main area. This is found across the centre of the screen. It displays

the following:

• number being dialled

• call display information

• phonebook

• menu information

• in standby mode, handset number and current time

Signal Strength icon

This is always displayed when your telephone is switched

on. It shows the current signal strength. More bars indicate

more signal strength

Line icon

This indicates that the line is engaged

Key Lock icon

This indicates the keys are locked

New Call icon

This indicates that there has been a new call

Mute icon

This indicates mute is activated. The microphone is turned

off temporarily

Battery Status icon

This is always displayed when your telephone is switched

on. It shows the level of battery charge. More bars indicate

more battery charge

DDITIONAL HANDSETS & BASES

Main Area

Icon Area

DESCRIPTION

LCD Screen Navigation

The key is used to activate the menu. The key is also used to

deactivate the menu and return to standby mode from any menu.

The Sand Tkeys are used to scroll through the menu.

S: move backward through the menu

T: move forward through the menu

The OK key is used to confirm an action or choice on a screen.

The C/R key is used to cancel an action/entry.

If you press C/R from any menu (except whilst in number input mode), the

telephone returns to the previous screen.

If you press and hold C/R from any menu (except whilst in number input

mode), the telephone returns to standby mode.

The telephone will automatically return to standby mode from any menu if

no button is pressed for 30 seconds.

Call Transfer between Handsets

An externall call can be transferred from one handset to another.

During a telephone conversation, when you wish to transfer the call.

press . Your external caller will be placed on hold

Enter the handset number you wish to transfer to (1-6)

The paged handset will ring. The calling handset number will be

dsiplayed on the LCD display

To answer the paged handset, press any button

If required, you may now speak to the paged user.

To transfer the external call to the paged handset, press

To cancel the call transfer and talk to the exteranl caller again, press

Notes:

On transferring a call, you may hang up before the paged handset

answers. The connection between the external caller and the paged

handset is complete once you hang up.

If the paged handset does not answer a call within a predetermined time,

the call will be transferred back to your handset.

DESCRIPTION

DDITIONAL HANDSETS & BASES

Otros manuales de Teléfono inalámbrico de Geemarc

Geemarc

Geemarc Photophone 110 Manual de usuario

Geemarc

Geemarc ClearSound CC40 Manual de usuario

Geemarc

Geemarc MyDECT 100 Manual de usuario

Geemarc

Geemarc VT05EEU06045 Manual de instrucciones

Geemarc

Geemarc Clearsound AmpliDECT230 Manual de usuario

Geemarc

Geemarc PhotoDECT Manual de usuario

Geemarc

Geemarc Amplidect350 Manual de usuario

Geemarc

Geemarc CC10 Manual de usuario

Geemarc

Geemarc AmpliDECT400BT Manual de usuario

Geemarc

Geemarc Ampli250 Manual de usuario

Geemarc

Geemarc ClearSound MyDECT 100 Manual de usuario

Geemarc

Geemarc AMPLIDECT 350 Manual de usuario

Geemarc

Geemarc Amplidect Combi 295 Manual de instrucciones

Geemarc

Geemarc AmpliDECT 595 Photo Manual de usuario

Geemarc

Geemarc Amplidect 295 SOS-Pro Manual de instrucciones

Geemarc

Geemarc Clear Sound Dect 150 Manual de usuario

Geemarc

Geemarc AMPLIVOICE50 Manual de usuario

Geemarc

Geemarc AmpliDECT 295 Manual de instrucciones

Geemarc

Geemarc AmpliDECT 295 Manual de usuario

Manuales populares de Teléfono inalámbrico de otras marcas

3Com

3Com NBX Manual de usuario

Panasonic

Panasonic KX-TGK210HK Manual de usuario

Panasonic

Panasonic KX-TCA181EX Manual de usuario

BT FREESTYLE 3200 Manual de usuario

AT&T

AT&T CL84102 Manual de usuario

BREZZICNI

BREZZICNI CL-3622 Manual de usuario

Panasonic

Panasonic KX-TG1831NZ Manual de usuario

Panasonic

Panasonic KX-TG7301E Manual de usuario

Furuno

Furuno FM-4721 Manual de usuario

Sanyo

Sanyo CLT-J70 Manual de usuario

Amplicomms

Amplicomms BigTel 201 Manual de usuario

GE 26992 Manual de usuario

AT&T

AT&T E1812B Manual de usuario

Sanyo

Sanyo CLT-670 Manual de usuario

GE 15432970 Manual de usuario

Curtis

Curtis TC595 Manual de usuario

Gigaset

Gigaset Gigaset 3000 Micro Manual de usuario

Poly

Poly VVX D230 Guía de configuración
