Geberit aquaclean sela Manual de usuario
971.173.00.0(00)
GEBERIT AQUACLEAN SELA
QUICK GUIDE
210414846091 © 05-2022
971.173.00.0(00)
Getting to know your device
The device at a glance
1 WC lid
2 Remote control with magnetic wall-mounted holder
3 WC seat ring
4 Spray arm with spray nozzle and Lady shower nozzle
5 Spray shield
6 Geberit AquaClean cleaning set (art. no. 242.547.00.1)
7 Geberit AquaClean descaling agent (art. no. 147.040.00.1)
10414846091 © 05-2022
971.173.00.0(00) 3
SVGW
DVGW
968.726.00.0 (00)
IPX4
Ta40 °C
230 V / 50 Hz 2000 W
0.1–1 MPa
EN 13077 / Typ AB DN3/8″
Geberit Int. AG, Schachenstr. 77, CH-8645 Jona
243.648.11.1
AquaClean Sela
1 Filling opening with plug for Geberit AquaClean descaling agent
2 Specification plate with serial number
3 Design cover
4 Power switch
410414846091 © 05-2022
971.173.00.0(00)
Operating concept
About the operating concept
The shower toilet can be operated via remote control or the GeberitHomeApp.
The remote control function of the Geberit AquaClean shower toilet is deactivated while the shower
toilet is connected to the GeberitHomeApp.
Front side of the remote control
All functions for daily use can be operated from the front side of the remote control.
1 <Shower> button: start and stop the spray functionality. Stop the Lady shower.
2 <–>/<+> buttons: decrease or increase the spray intensity.
3 <left>/<right> arrow keys: set the spray arm position.
4 <Lady shower> button: start and stop the Lady shower.
5 <Oscillating motion> button: start and stop the oscillating motion during the anal shower.
6 <Orientation light> button: Switch the orientation light on and off
7 <User profile> buttons: select the user profiles 1–4
10414846091 © 05-2022
971.173.00.0(00) 5
Rear side of the remote control
You can access system settings and additional functions from the rear side of the remote control.
1 Battery compartment
2 LCD display
3 <up>/<down>, <left>/<right> arrow keys
Downloading the Geberit Home
app
Download the free GeberitHomeapp for Android
and iOS smartphones directly from the respective
App Store:
1Open the App Store on your smartphone.
2Enter “GeberitHomeapp” in the search
field.
✓ The GeberitHomeapp is displayed.
3Download the app.
✓ The app is downloaded and displayed on
your smartphone.
Alternatively, you can scan the respective QR code
to download the GeberitHomeapp:
Android: iOS:
610414846091 © 05-2022
971.173.00.0(00)
Using the Geberit Home App
The GeberitHomeApp communicates via a Bluetooth® interface with the Geberit AquaClean shower toilet.
The remote control function of the Geberit AquaClean shower toilet is deactivated while the shower
toilet is connected to the GeberitHomeApp.
Please note that your device may not offer remote control or individual functions may not be
available. The functions and settings in the GeberitHomeApp vary from device to device and are
marked with (optional) where appropriate.
You can execute the following functions and settings via the GeberitHomeApp:
• Remote control
– Using remote control functions
– Adjusting and saving personal settings
• Device settings
– Adjusting and saving basic settings
• Geberit customer service
– Establishing contact with Geberit customer service
• Geberit services
– Registering the device
– Extending warranty services
• Software update
– Updating the firmware
You can access the following information via the GeberitHomeApp:
• Step-by-step instructions
– Cleaning the spray nozzle and dryer arm (optional)
– Replacing the ceramic honeycomb filter (optional)
– Displaying descaling
• Explanatory videos
– Playing function videos
– Playing maintenance and cleaning videos
• Troubleshooting
– Display error messages
• User manual
– Displaying the user manual
10414846091 © 05-2022
971.173.00.0(00) 7
How to use the device
Re-assigning the remote control
The device can only be operated with a
single, assigned remote control.
Prerequisite
– The device is switched off.
▶Switch the device on and press the <+>
button on the remote control for approx. 30
seconds until [Pairing ok] appears on the
display.
T
Result
✓ The shower toilet can be controlled by remote
control.
Using the anal shower
Prerequisite
– You are sitting down on the WC seat ring.
▶Briefly press the <Shower> button on the
remote control.
Result
✓ The shower procedure starts with the oscillating
motion.
You can stop the shower procedure early by
pressing the <Shower> button once again.
810414846091 © 05-2022
971.173.00.0(00)
Setting the spray intensity
Prerequisite
– The shower procedure is running.
▶Press the <+> button to increase the spray
intensity. Press the <–> button to decrease
the spray intensity.
Result
✓ The shower spray becomes stronger/weaker.
You can set the spray intensity in 5 stages.
Setting the spray arm position
Female users should set the spray arm
position of the spray functionality to their
ergonomic conditions so that it does not
compromise the natural protection of the
vaginal area.
Prerequisite
– The shower procedure is running.
▶Press the arrow keys on the remote control
to position the spray arm.
Result
✓ The spray arm is optimally positioned.
You can set the spray arm position in
5 stages.
10414846091 © 05-2022
971.173.00.0(00) 9
Switching the oscillating motion
of the anal shower on and off
The oscillating motion of the spray arm
increases the cleaning effect.
▶The oscillating motion can be switched on
and off during the shower procedure by
pressing the <Oscillating motion> button or
by pressing the <left> and <right> arrow
keys at the same time.
Using the Lady shower
The woman's intimate area is a very
sensitive zone and requires special and
prudent care. The Lady shower must be set
to your ergonomic conditions to achieve an
optimal cleaning result. The position of the
spray nozzle and the spray intensity must
be selected so that the shower spray cannot
penetrate the vagina.
Prerequisite
– You are sitting down on the WC seat ring.
▶Press the <Lady shower> button on the
remote control.
Result
✓ The shower procedure starts.
You can stop the shower procedure early by
pressing the <Lady shower> button once
again.
10 10414846091 © 05-2022
971.173.00.0(00)
Switching the orientation light off
and on
Prerequisite
– The device is switched on.
▶Press the <Orientation light> button on the
remote control.
Result
✓ The orientation light goes out/lights up.
Saving user profiles
4 different user profiles can be stored via the
<user profile> buttons on the remote control.
User profiles allow you to access your
personal settings directly. Select your user
profile as soon as you sit down.
▶Press one of the 4 <user profile> buttons for
more than 2 seconds.
T
Result
✓ The current settings are saved to this button.
