GE RM94903 Manual de usuario

Universal

Remote Control

RM94903

INSTRUCTION

MANUAL

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 1

Button Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Setting Up Your Universal Remote . . . . . . . . . . . . . . . .3

Programming Your Universal Remote For:

TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

VCR or DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Cable Box or Other Device . . . . . . . . . . . . . . . . . .7-8

Operating A TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Operating A Cable Box . . . . . . . . . . . . . . . . . . . . . . . . . .9

Operating a DVD Player . . . . . . . . . . . . . . . . . . . . . . .10

Operating A VCR . . . . . . . . . . . . . . . . . . . . . . . . . . .10-11

Programming Using Code Search . . . . . . . . . . . . . . . .11

Code Retrieval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Operating A TV/VCR Combo Unit . . . . . . . . . . . . . . .13

Special Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Lost Your Codes? . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Code Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31-35

Table of Contents

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 2

Button Description

Indicator Light

Flashes to show that the

remote is working.

POWER

Operates the same as on

your original remote.

MUTE

Operates the same as on

your original remote.

Device Buttons(TV, VCR/DVD,

CBL/AUX)

The TV,VCR/DVD and CBL/AUX

buttons are used to select the

home entertainment device

you want to control.

VOLUME andCHANNEL

Operate the same as on

your original remote. These

buttons are also used to

enter the code for your

device. The CHANNEL

buttons are also used to

control the SKIPfunctions

for DVD and CD Players.

VCR Buttons

The REV (Rewind/Reverse),

PLAY,FOR (Fast Forward),

REC (Record), STOP, and

PAUSE buttons control the

same functions as those

found on your VCR remote.

The REV and FOR are also

used to control the

REVERSE and FORWARD

functions for DVD and CD

Players.

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 3

Setting Up Your Universal Remote

Place batteries in the remote

Remove the battery compart-

ment cover.

2. Place two AAAbatteries as

shown, matching the + and –

end of each battery as indi-

cated in the battery compart-

ment.

3. Replace the cover.

(Some RCA, GE and ProScan devices may already be

pre-programmed. )

1. Press the button of the device

you want to control (for

example TV).

2. If the device turns on,press

another button to confirm

(for example

CHANNEL UP).

3. If the device you selected

(TV) responds, you will not

need to program the remote.

If the device you selected

(TV) does not respond, you

will need to program the

remote.

4. Repeat steps 1-3 for other

devices.

Determine if your remote needs programming

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 4

1. Manually turn on the TV.

2.Find the code for your

brand in the list starting

below.

3.Press and hold the TV but-

ton for five (5) seconds, the

Indicator Light will light up.

4.Release the TV button.

The following buttons

stand for each digit of the

code:

5.Enter the first digit in the

code with the REV button.

Example: if the first num-

ber is 3, depress the REV

button three times. If the

number is 0, do not press

REV and proceed to next

step.

Note: The Indicator Light

will blink after each num-

ber is entered.

6.Enter the second digit in

the code with the PLAY

button the same way as in

step 5. If the number is 0,

do not press PLAY and pro-

ceed to next step.

1st Digit 2nd Digit 3rd Digit

1ST CODE

NUMBER

2ND CODE

NUMBER

Programming TV Using Code Lists

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 5

3RD CODE

NUMBER

TV CODE

7.Enter the third digit in the

code with the FOR button

the same way as in step 5.

If the number is 0, do not

press FOR and proceed to

next step.

8.Press STOP after code is

entered and the Indicator

Light will turn off.

9. With your TV on, press

CHANNEL Up. If the TV

responds, no further

programming is required.

10.Enter your code here for

easy reference.

Programming TV Using Code Lists (con’t)

1. Manually turn on the VCR.

2.Find the code for your

brand in the list starting

below.

3.Press and hold the VCR/DVD

button for five (5) seconds,

the Indicator Light will light

up.

4.Release the VCR/DVD button.

Programming VCR or DVD Player Using

Code Lists

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 6

Programming VCR or DVD Player Using

Code Lists (con’t.)

The following buttons stand

for each digit of the code:

5.Enter the first digit in the

code with the REV button.

Example: if the first number

is 3, depress the REV button

three times. If the number is

0, do not press REV and pro-

ceed to next step.

Note: The Indicator Light

will blink after each number

is entered.

6.Enter the second digit in the

code with the PLAY button

the same way as in step 5. If

the number is 0, do not

press PLAY and proceed to

next step.

7.Enter the third digit in the

code with the FOR button

the same way as in step 5.

If the number is 0, do not

press FOR and proceed to

next step.

8.Press STOP after code is

entered and the Indicator

Light will turn off.

1st Digit 2nd Digit 3rd Digit

1ST CODE

NUMBER

2ND CODE

NUMBERX

3RD CODE

NUMBERX

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 7

1. Manually turn on the Cable

Box.

2.Find the code for your brand

in the list starting on the

next page.

3.Press and hold the CBL/AUX

button for five (5) seconds,

the Indicator Light will light

up.

4.Release the CBL/AUX button.

The following buttons stand

for each digit of the code:

5.Enter the first digit in the

code with the REV button.

Example: if the first number

is 3, depress the REV button

three times. If the number is

0, do not press REV and pro-

ceed to next step.

1ST CODE

NUMBER

1st Digit 2nd Digit 3rd Digit

VCR/DVD CODE

Programming VCR or DVD Player Using

Code Lists (con’t.)

9. With your VCR or DVD

player on, press CHANNEL

Up. If the VCR or DVD

player responds, no further

programming is required.

10. Enter your code here for

easy reference.

ProgrammingCableBoxUsingCodeLists

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 8

Note: The Indicator Light will

blink after each number is

entered.

6.Enter the second digit in the

code with the PLAY button

the same way as in step 5.

If the number is 0, do not

press PLAY and proceed to

next step.

7.Enter the third digit in the

code with the FOR button

the same way as in step 5.

If the number is 0, do not

press FOR and proceed to

next step.

8.Press STOP after code is

entered and the Indicator

Light will turn off.

9. With your Cable Box on,

press CHANNEL Up. If the

Cable Box responds, no

further programming is

required.

10. Enter your code here for

easy reference.

ProgrammingCableBoxUsingCodeLists

2ND CODE

NUMBER

3RD CODE

NUMBERX

CABLE/ OTHER

DEVICEBOX CODE

94903 Revised Size 1/21/02 2/25/02 4:26 PM Page 9

Turning the TV On and Off.

Press TV to set the remote

to control the TV (most

RCA, GE and ProScan

models will only turn on

when pressing TV not

power).

2. Press POWER to turn the

TV on or off.

Change Channels and Volume on

the TV.

Press VOLUME UPor VOLUME

DOWNto change volume on

the TV.

Press CHANNEL UPor CHAN-

NEL DOWN to change chan-

nels on the TV.

Turning the Cable Box On or

Off.

1. Point the remote at the

cable box and press

CBL/AUXE.

2. Press POWER to turn it on

or off.

Changing Channels on the

Cable Box.

Press CHANNEL UP or CHAN-

NEL DOWN to change chan-

nels on the cable box.

Operating A TV

Operating A Cable Box
