GE Profile Series Manual de usuario
GE Appliances
Refrigerators
Side by side
Part No. 162D7734P005 Pub. No. 49-6908
Profile Models
22–27
Owner’s Manual
Congratulations!
You Are Now Part of the GE Family.
Welcome to the GE family.
We’re proud of our quality
products and we are
committed to providing
dependable service. You’ll
see it in this easy-to-use
Owner’s Manual and you’ll
hear it in the friendly voices
of our customer service
department.
Best of all, you’ll experience
these values each time you
use your refrigerator.
That’s important, because
your new refrigerator will
be part of your family for
many years. And we hope
you will be part of ours for a
long time to come.
We thank you for buying
GE. We appreciate your
purchase, and hope you
will continue to rely on us
whenever you need quality
appliances for your home.
2
Important!
Staple sales slip or cancelled
check here.
Proof of the original purchase date
is needed to obtain service under
the warranty.
Write the model and serial
numbers here.
#
#
You can find them on a label on the
wall beside the top drawer or at the
bottom, just inside the fresh food
compartment door.
GE & You,
A Service Partnership.
Inside you will find many
helpful hints on how to use and
maintain your refrigerator
properly. Just a little preventive
care on your part can save you a
great deal of time and money
over the life of your refrigerator.
Read this Manual
Ask any GE appliance owner and they will
tell you we stand behind our products with
unmatched quality service. However, did
you know that most questions result from
simple problems that you can easily fix
yourself in just a few minutes? This
Owner’s Manual can tell you how.
You’ll find many answers to
common problems here.
If you review our chart of
Troubleshooting Tips first, you may
not need to call for service at all.
Review the Section on
Troubleshooting Tips
If you do need service, you can
relax knowing help is only a phone
call away. A list of toll-free
customer service numbers is
included in the back section. Or,
in
the U.S.,
you can always call the GE
Answer Center®at 800.626.2000,
24 hours a day, 7 days a week.
In Canada,
call 800-361-3400.
If You Need Service
English . . . . . . . . . . . . . . . . . .4
Français . . . . . . . . . . . . . . . .37
Español . . . . . . . . . . . . . . . . .75
Languages
Safety Information
Safety Precautions . . . . . . . . . . .4
How to Connect Electricity . . . .6
Use of Adapter Plugs . . . . . . .6, 7
Use of Extension Cords . . . . . . .7
Operating Instructions
Temperature Controls . . . . . .8, 9
Features . . . . . . . . . . . . . . .10–13
Ice Service . . . . . . . . . . . . .14, 15
Ice and Water Dispenser . .16, 17
Care and Cleaning . . . . . . .18–21
Installation Instructions
Preparing to
Install the Refrigerator . . . .22, 23
Water Line Installation . . .24–28
Troubleshooting Tips
Normal Operating Sounds . . . .29
Before You
Call For Service . . . . . . . . .30–33
Customer Service
Warranty
for Canadian Customers . . . . .34
Warranty
for U.S. Customers . . . . . . . . . .35
Service Telephone
Numbers . . . . . . . . . .Back Cover
3
Troubleshooting TipsInstallation Instructions Customer ServiceOperating InstructionsSafety Information
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
Use this appliance only for its intended purpose as
described in this Owner’s Manual.
■This refrigerator must be
properly installed and
located in accordance with
the Installation Instructions
before it is used.
■Do not allow children to
climb, stand or hang on the
shelves in the refrigerator.
They could damage the
refrigerator and seriously
injure themselves.
■Do not touch the cold
surfaces in the freezer
compartment, particularly
when hands are damp or wet.
Skin may stick to these
extremely cold surfaces.
■Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
■In refrigerators with
automatic icemakers, avoid
contact with the moving parts
of the ejector mechanism, or
with the heating element that
releases the cubes. Do not
place fingers or hands on the
automatic icemaking
mechanism while the
refrigerator is plugged in.
■Keep fingers out of the
“pinch point” areas;
clearances between the
doors and between the doors
and cabinet are necessarily
small. Be careful closing
doors when children are in
the area.
■Unplug the refrigerator
before cleaning and making
repairs.
NOTE: We strongly recommend
that any servicing be performed
by a qualified individual.
■Turning the control to the
OFF
position does not remove
power to the light circuit.
■Do not refreeze frozen
foods which have thawed
completely.
SAFETY PRECAUTIONS
Operating Instructions
Installation Instructions Safety InformationTroubleshooting TipsCustomer Service
When using electrical appliances, basic safety precautions
should be followed, including the following:
WARNING!
IMPORTANT:
PROPER DISPOSAL OF THE REFRIGERATOR
5
Troubleshooting TipsInstallation Instructions Customer ServiceOperating InstructionsSafety Information
Child entrapment and suffocation are not problems of
the past. Junked or abandoned refrigerators are still
dangerous…even if they will sit for “just a few days.”
If you are getting rid of your old refrigerator, please
follow the instructions below to help prevent accidents.
Before You Throw Away Your Old Refrigerator
or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not
easily climb inside.
CFC Disposal
Your old refrigerator has a cooling system that used
CFCs (chlorofluorocarbons). CFCs are believed to harm
stratospheric ozone.
If you are throwing away your old refrigerator, make
sure the CFC refrigerant is removed for proper disposal
by a qualified servicer. If you intentionally release this
CFC refrigerant you can be subject to fines and
imprisonment under provisions of the Federal Clean
Air Act.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
Operating Instructions
Installation Instructions Safety InformationTroubleshooting TipsCustomer Service
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
The power cord of this appliance is equipped with a 3-prong
(grounding) plug which mates with a standard 3-prong
(grounding) wall outlet to minimize the possibility of electric
shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified electrician
to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it is your
personal responsibility and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
The refrigerator should always be plugged into its own individual
electrical outlet which has a voltage rating that matches the rating
plate.
This provides the best performance and also prevents overloading
house wiring circuits which could cause a fire hazard from
overheated wires.
Never unplug your refrigerator by pulling on the power cord.
Always grip plug firmly and pull straight out from the outlet.
Repair or replace immediately all power cords that have become
frayed or otherwise damaged. Do not use a cord that shows cracks
or abrasion damage along its length or at either end.
When moving the refrigerator away from the wall, be careful not to
roll over or damage the power cord.
USE OF ADAPTER PLUGS
Because of potential safety hazards under certain conditions,
we strongly recommend against the use of an adapter plug.
However, if you must use an adapter, where local codes permit, a
temporary connection
may be made to a properly grounded 2-prong
wall outlet by use of a UL-listed adapter available at most local
hardware stores.
WARNING!
7
The larger slot in the adapter must be aligned with the larger slot in
the wall outlet to provide proper polarity in the connection of the
power cord.
When disconnecting the power cord from the adapter, always hold
the adapter in place with one hand while pulling the power cord
plug with the other hand. If this is not done, the adapter ground
terminal is very likely to break with repeated use.
If the adapter ground terminal breaks,
DO NOT USE
the refrigerator
until a proper ground has been established.
Attaching the adapter ground terminal to a wall outlet cover screw does not
ground the appliance unless the cover screw is metal, and not insulated, and the
wall outlet is grounded through the house wiring. You should have the circuit
checked by a qualified electrician to make sure the outlet is properly grounded.
Troubleshooting TipsInstallation Instructions Customer ServiceOperating InstructionsSafety Information
USE OF EXTENSION CORDS
Because of potential safety hazards under certain
conditions, we strongly recommend against the use of an
extension cord.
However, if you must use an extension cord, it is absolutely
necessary that it be a UL-listed, 3-wire grounding type appliance
extension cord having a grounding type plug and outlet and that
the electrical rating of the cord be 15 amperes (minimum) and
120 volts.
REMEMBER…
Your continued health and safety are important to us.
Please read and follow this Safety Information carefully.
We want you to remain a happy and healthy part of our
GE family.
SAVE THESE INSTRUCTIONS
Fresh Food Control
The fresh food control maintains the temperatures
throughout the fresh food compartment.
Moving the fresh food control to
OFF
stops cooling in
both areas—fresh food and freezer—but does not shut
off power to the refrigerator.
Freezer Control
The freezer control maintains the temperatures
throughout the freezer compartment.
8
Operating Instructions
Installation Instructions Safety InformationTroubleshooting TipsCustomer Service
About the controls on the refrigerator.
The temperature controls on your refrigerator have letters and numbers.
Initially set the fresh food control at 5and the freezer control at C.
If you want colder or warmer temperatures, adjust the fresh food
temperature first. When satisfied with that setting, adjust the freezer
temperature.
OFF 13579
A B C D E
Freezer Control
C is Initial Setting
E is Coldest
1
1
2
2
Control Settings
9
Troubleshooting TipsInstallation Instructions Customer ServiceOperating InstructionsSafety Information
You won’t find an energy saver switch on this refrigerator.
Warm liquid from the refrigerator’s condenser is automatically
circulated around the front edge of the freezer compartment to
help keep moisture from forming on the outside of the refrigerator
during humid weather.
Many refrigerators use special electric heaters. This refrigerator
needs none. That’s why there is no
energy saver
switch…there’s no
need for it.
Automatic Energy Saver System
The type of packaging used and the storage temperatures will affect
how long food will keep in the refrigerator.
New food storage guidelines are constantly being developed.
Consult the County Extension Service for the latest information on freezing and
storing foods.
Food Storage
Use the milk test for the fresh food compartment. Place a container
of milk on the top shelf and check it a day later. If the milk is too
warm or too cold, adjust the temperature controls.
Use the ice cream test for the freezer compartment. Place a
container of ice cream in the center of the freezer and check it after
a day. If it’s too hard or too soft, adjust the temperature controls.
After changing the controls, allow 24 hours for the refrigerator to reach the
temperature you have set.
How To Test Temperatures
To Remove To Replace
About the refrigerator shelves and dishes.
10
Operating Instructions
Installation Instructions Safety InformationTroubleshooting TipsCustomer Service
Not all features are on all models.
Shelves in the fresh food
and freezer compartments
are adjustable.
Rearranging the Shelves
Slide-Out Spillproof Shelf
The slide-out spillproof shelf allows you to reach items
stored behind others. The special edges are designed to
help prevent spills from dripping to lower shelves.
Make sure you push the shelves all the way back in before you
close the door.
Lift up and out
2Tilt up
1
Insert
top hook
1
Lower to
lock in place
2
Quick Serve™ System
CAUTION: Dishes and lids are not designed for
use on the range top, broiler or in the regular
oven. Such use can be hazardous.
Quick Serve™ dishes fit into a space-saving rack under
the shelf. The rack can be relocated anywhere in the
fresh food compartment.
Dishes and lids are safe for use in microwave ovens,
refrigerators and freezers.
Do not use when cooking high-fat foods, such as bacon, and high-
sugar foods, such as candy and syrup. The high temperatures of the
fat and sugar can cause bubbles to form on the inside of the dish.
Otros manuales para Profile Series
9
Tabla de contenidos
Idiomas:
Otros manuales de Refrigerador de GE
GE
GE GCV06GSNBSB Instrucciones originales
GE
GE GE Profile TBX14SIBAA Manual de usuario
GE
GE 21 Instrucciones de funcionamiento
GE
GE GTS17JBWBB - 16.6 cu. Ft. Top-Freezer... Instrucciones de montaje
GE
GE Monogram ZICS360NX Manual de usuario
GE
GE TFX20RN Manual de usuario
GE
GE PSF26NGPCBB and Guía de seguridad
GE
GE TURBOCOOL 23 Guía de seguridad
GE
GE Profile 24 CustomStyle Manual de usuario
GE
GE 162D3941P005 Manual de usuario
GE
GE Profile PGCS1PJZSS Instrucciones de montaje
GE
GE GTV100PANRSG Manual de usuario
GE
GE Profile PTS22LCS Manual
GE
GE GTJ18CBDSA Manual
GE
GE ENERGY STAR GSF25JGC Instrucciones originales
GE
GE 3ft 2 Door Instrucciones de funcionamiento
GE
GE Monogram ZIC30GNZAII Manual de usuario
GE
GE GMR04BANWW - Compact 4.3 Cubic Foot Total Capacity... Guía del usuario
GE
GE MBR12 Instrucciones de funcionamiento
GE
GE GSH22JFXCC - Refrigerator w/ Glass ESTAR Manual
