GE Profile PSW26PSSSS Manual

PSW26PSS

GE Profile™ ENERGY STAR® 25.5 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator

"94 SxS Refer

Front View

Top View

Dimensions and Installation Information

*When cap is removed: 69-1/4"

**Width including top caps is 35-7/8".

† Water hook-up fits in back air clearance when calculating

installation depth.

If installed against a wall, allow clearance of 14-3/16" on freezer

side to remove bin.

Clearance required to remove fresh food full-size pan without

disassembling is 18-15/16".

Allow additional space for any necessary leveling adjustments.

Overall

Dimensions

Height to top of hinge (in.) A 70-3/4*

Height to top of case (in.) B 68-3/4

Case depth without door (in.) C†28-1/2

Case depth less door handle (in.) D†32-3/4

Case depth with door handle (in.) E†35-3/8

Depth with fresh food door open 90° (in.) F†50-4/7

Width (in.) G

36**

Width with door open 90° less door handle (in.) H 42-3/8

Air

Clearances

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1

Listed by

Underwriters

Laboratories

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000.

Specification Revised 7/05 210329

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000.

PSW26PSS

GE Profile™ ENERGY STAR® 25.5 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator

Listed by

Underwriters

Laboratories

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Specification Revised 7/05 210329

To Remove Top Caps and Doors on PSW26PSS

Step 1: the refrigerator. Remove two screws, one on each side at the rear of the top

cap. Lift off and remove top cap.

Step 2: Open both doors. Remove one screw on each side of the toekick. Pull forward

to remove toekick.

Step 3: On the freezer door, disconnect water line coupler by pushing against the collar

on the left side. Disconnect wire harness.

Step 4: Use a Torx T-20 screwdriver to remove 2 screws holding the top hinge. Carefully

remove hinge while supporting door. Lift door up and off bottom hinge. Remove fresh

food door in the same manner. Note: Do not remove bottom hinges! Door alignment

will be difficult if bottom hinges are removed.

Step 5: Place refrigerator onto a hand truck, upright and against one side.

Move refrigerator to the installation location.

Step 6: Carefully lower doors onto bottom hinges. Be sure to route the tubing and

electrical connector through the bottom hinge. Reinstall top hinges.

Step 7: Place cap over the top of the refrigerator. Reinstall the original screws in the top

and back of the cap.

Step 8: Reconnect the wiring harness and waterline.

Water Line Coupler

366-15A

Hinge Screws

Wire Harness

Toekick Screw

PSW26PSS

GE Profile™ ENERGY STAR® 25.5 Cu. Ft. Stainless-Wrapped Side-by-Side Refrigerator

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

PSW26PSRSS

WATER

CRUSHED

CUBEDCLOCK SET

LIGHT

DOOR ALARMRESET WATER FILTER

HOLD 3 SEC.

LOCK CONTROL

HOLD 3 SEC.

Arctica

Specification Revised 7/05 210329

Features and Benefits

• Stainless-Wrapped - Provides stainless steel doors, side panels and top for a truly dramatic look

• ClimateKeeper2™ System - Keeps food garden fresh longer, while protecting ice from odor

transfer, with its unique dual-evaporator system

• CustomCool™ Technology With Full Extension Slides - Chills in minutes thaws in hours and keeps

foods fresher, longer

• Beverage Center - Keeps beverages and treats icy cold and easily accessible

• Upfront, Electronic Touch Temperature Controls with Digital Temperature Display -

Precise and easy to use, taking the guesswork out of setting accurate temperatures

• Integrated Ice™ System - Frees up valuable freezer space. It tilts down, providing easy access

to bulk ice

• Tall LightTouch! Dispenser with LED lighting- Dispenses water and ice at the slightest touch;

LED lighting provides long-lasting illumination

• Slide ‘n Store™ Full-Extension Freezer Baskets - Extends 12" to 16" beyond the cabinet, providing

easy loading and unloading

• FrostGuard™ Technology - Protects frozen items from freezer burn by monitoring door openings

and defrosting only when needed

• Integrated Shelf Support System - Provides strong, yet flexible support

• Adjustable Slide-Out, Spillproof Glass Shelves - Shelves slide out, spills stay put

• QuickIce™ Option - Makes ice up to 50% faster than normal settings-ideal for entertaining

• TurboCool™ Setting - “Revs up” the refrigerator, cooling it quickly after frequent door openings

• GE SmartWater™ Plus Filtration System - Delivers clean, great-tasting water and ice through the

LightTouch! Dispenser with indicator light

• ClearLook™ Adjustable Gallon Door Bin - Store gallon containers with ease

• Model PSW26PSSSS - Stainless-wrapped
