GE GSS20IEM Manual de usuario

GSS20IEM - GE 19.9 Cu. Ft. Side-By-Side Refrigerator

GE Appliances

Specification Revised 3/01

Dimensions (in inches)

A

Top View

G

D

C

F

BE

H

Height with hinge (in.) A 67-1/2

Height without hinge (in.) B 66-1/2

Depth without Doors (in.) C28

Depth with Doors (in.) D 30-3/4

Depth plus Handle with Doors Closed (in.) E33

Depth with Doors open 90° (in.) F 46-9/16

Width with Doors Closed (in.) G 31-1/2

Width with Doors open 90°Less Door Handle(in.) H 31-1/2

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1

Overall

Dimensions

Air

Clearances

Note: If the doors cannot be fully opened because of an obstruction or a

wall on either side, a door stop should be provided to prevent door or wall

damage. If the doors cannot be opened at least 90 degrees, access to the

drawers is limited.

Manufacturer Certified to

ASSOCIATION OF HOME

APPLIANCE MANUFACTURERS

ANSI/AHAN HRF-1-1979

VOLUME and

SHELF AREA

R

Total volume and shelf

area are calculated by the

Association of Home

Appliance Manufacturers’

standards.

Listed by

Underwriters

Laboratories

For answers to your Monogram,

®GE Profile™or

GE appliance questions, visit our website at

WWW.GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

Note: Add 9/16”for water hook-up. Hook-up fits in 5/8”back air clearance

when calculating installation depth.

If installed against a wall, allow clearance of 10-2/3”on freezer side to

remove bin.

To remove fresh food pans, remove door bins.

Clearance required to remove fresh food full-size pan without

disassembling: 13-1/2”(20 cu. ft.)

Plus, allow additional space for any necessary leveling adjustments.

Specification Revised 3/01

GE Appliances

GSS20IEM - GE 19.9 Cu. Ft. Side-By-Side Refrigerator

WATER

CRUSHED

CUBED

LIGHT

Features and Benefits

•19.9 cu. ft. Capacity (Fresh Food 12.75 cu. ft. / Freezer 7.11 cu. ft.)

•Upfront Electronic Temperature Controls

•FrostGuard™Technology

•LightTouch! Dispenser Delivers Water, Cubed and Crushed Ice

Through the Door

•NeverClean™Condensor

•3 Adjustable Glass Fresh Food Cabinet Shelves

•Adjustable Temperature Deli Pan

•Sealed Vegetable/Fruit Crisper

•4 Modular Fixed Fresh Food Door Shelves (2 with Gallon Storage)

•Electronic Icemaker

•Deluxe Quiet Design

•Model GSS20IEMWW - White on white

•Model GSS20IEMCC - Bisque

•Model GSS20IEMWH - White

Este manual sirve para los siguientes modelos

3
