GE GSHF5KGX Manual

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

GSHF5KGX

GE®25.4 Cu. Ft. Side-By-Side Refrigerator

Overall

Dimensions

Height to top of hinge (in.) A 69-1/2

Height to top of case (in.) B 68-3/4

Case depth without door (in.) C†28

Case depth less door handle (in.) D†32-1/2

Case depth with door handle (in.) E†35

Depth with fresh food door open 90° (in.) F†50-1/8

Width (in.) G 35-3/4

Width with door open 90° inc. door handle (in.) H 43-5/8

Air

Clearances

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1/8

Listed by

Underwriters

Laboratories

Specification Revised 4/08 310133

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Dimensions and Installation Information (in inches)

†Water hook-up fits in back air clearance when calculating

installation depth.

If installed against a wall, allow clearance of 14-3/16" on freezer

side to remove bin.

Clearance required to remove fresh food full-size pan without

disassembling is 18-15/16".

Allow additional space for any necessary leveling adjustments.

"94 SxS Refer

A

Front View

Top View

G

D

C

F

BE

H

GSHC5KGX

GSHC3KGX

Features and Benefits

• High Gloss Finish - Provides sleek elegance with a smooth finish

• External Controls with Actual Temperature Display and UltraFlow64 - Eliminates the guesswork

in setting refrigerator temperatures; dispenses 64 ounces of filtered water per minute

• Integrated Shelf Support System - Provides strong, yet flexible support

• Freshness Center™(2-pan stack) - Maximizes shelf space by utilizing two humidity-

controlled drawers

• Adjustable ClearLook™Door Bins - Hold gallon-size containers with style and ease

• In-the-Door Can Rack - Conveniently located inside the refrigerator door to increase

flexibility and free up valuable shelf space

• Adjustable Slide-Out, Spillproof Glass Shelves - Raised edges help contain spills and slide-

out shelves make clean up quick and easy

• GE Water Filtration System - Delivers clean great-tasting water and ice through the

LightTouch! Dispenser

• FrostGuard™Technology - Protects frozen items from freezer burn by monitoring freezer

door openings and defrosting only when needed

• AutoEnergy Saver - Senses freezer and fresh door openings and adjusts refrigeration

operation cycles accordingly

• NeverClean™Condenser - Condenser coils are encased, so they don't require cleaning in

normal operating environments

• Deluxe Quiet Design - Significantly reduces operating noise

• Model GSHF5KGXBB - Black on black

• Model GSHF5KGXCC - Bisque on bisque

• Model GSHF5KGXWW - White on white

GSHF5KGX

GE®25.4 Cu. Ft. Side-By-Side Refrigerator

Specification Revised 4/08 310133

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.
