GE Profile PB975SMSS Manual

†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires

that new construction (not existing) utilize a 4-conductor

connection to an electric range.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing

from adjacent walls below countertops. To reduce possibility

of scorching walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat,

no-load heating element operation.

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

PB975SM

GE Profile™ 30" Free-Standing Double Oven Range

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Specification Created 1/07 221006

KW Rating

240V 14.3

208V 10.7

Breaker Size

40 Amps†

7-1/2

29-7/8

25-3/4*

Acceptable electrical

outlet area

Orient the electrical

receptacle so the length

is parallel to the floor.

*Dimension from wall to front of

closed oven door handle is 28-7/8.

fse_dual_cavity_install.eps

PB975SM

GE Profile™ 30" Free-Standing Double Oven Range

Specification Created 1/07 221006

Features and Benefits

• Upper Oven - With an additional 2.2 cu. ft. of capacity, the upper oven is perfect for

preparing food items at the same time as the lower oven

• PreciseAir™Convection System - Delivers even air and heat circulation for superior

baking and roasting results

• Tri-ring Burner - 12"/9"/6" heating element offers a convenient choice for various size pans

• Bridge Element - Combines three cooktop elements into one large cooking area, ideal

for oversized cooking pans

• Large 4.4 Cu. Ft. Lower Oven Capacity - Provides an impressively large oven interior

to cook more dishes and large meals at once

• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Warming Zone - Provides low heat capability for foods, making meal coordination simple

• Single/Multi-Rack Convection Bake - Provides ideal airflow throughout the oven,

ensuring optimal results on both racks

• Convection Roast - Provides even cooking and consistent results, roasting meats faster

than a traditional oven

• Slow Cook - Offers four slow cook options-pork, poultry, beef and stew-to deliver ideal

conditions for specific meals

• Pizza Mode - Provides ideal cooking conditions for preparing fresh or frozen pizzas at

the touch of a button

• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled racks no

longer require hand cleaning

• 6.6 Cu. Ft. Total Capacity - Provides plenty of room to cook the biggest of meals,

4.4 cu. ft. in the lower oven and 2.2 cu. ft. in the upper oven

• Model PB975SMSS - Stainless steel (black patterned cooktop)

JB975SM

TART

LEAR

ook

ime

tart

elay

PPER

VEN

6”

9”

12”

RONT

EAR

ARMING

ONE

RONT
