Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires that new

construction (not existing) utilize a 4-conductor connection to an electric range.

Receptacle Locations

Locally approved flexible service cord or conduit must be used because terminals

are not accessible after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow range to be installed

directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent

walls below countertops. To reduce possibility of scorching walls, engineering

recommends a minimum of 1-1/2" spacing to allow for possible extended, high-

heat, no-load heating element operation.

Installation Information: Before installing, consult installation instructions

packed with product for current dimensional data.

KW Rating

240V 14.3

208V 10.7

Breaker Size

40 Amps†

PB978DP/TP

GE Profile™ 30" Free-Standing Electric Range

Specification Revised 5/09 221018

7-1/2

29-7/8

25-3/4*

Acceptable electrical

outlet area

Orient the electrical

receptacle so the length

is parallel to the floor.

*Dimension from wall to front of

closed oven door handle is 28-7/8.

fse_dual_cavity_install.eps

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Features and Benefits

• 6.6cu.ft.totalovencapacity-Largecapacityisidealforbigmeals

• PreciseAir™convection system - A reversing fan circulates heat and air for evenly

browned and baked foods

• Convectioncook-Areversingfansurroundedbyathirdelementcirculateshotairfor

great results on every rack

• Nextstepcontrols-Knob-freecontrolsilluminatetoleadthroughthecontrol

setting process

•  T r u e T e m p ™griddle system - Griddle can be set to heat from 200˚ – 400˚F for a variety

of cooking options

• 12"/9"/6"Tri-RingElement-Providesthreecookingareasinonefortheultimatein

cooking versatility

• PizzaMode-Providesidealcookingconditionsforpreparingfreshorfrozenpizzasat

the touch of a button

• Slowcookmode-Twoslowcookoptions–beefandpoultry–deliveridealconditions

for specific meals

• 5"/8"Dualelement-Toheatingelementsinoneallowsyoutochooseeithera5"or8"

element for your cookware

• WarmingZone-Provideslowheatcapabilityforfoods,makingmealcoordinationsimple

•ModelPB978DPBB–Blackonblack

•ModelPB978TPWW–Whiteonwhite

PB978DP/TP

GE Profile™ 30" Free-Standing Electric Range

Specification Revised 5/09 221018

PB978TPWW/DPBB

ELT

URNER

IZE

ELT

URNER

IZE

ELECT

WARMINGZONE

AKE

ARM

ROIL

LOCK

LEAN

ELF

TART

T O D

ELAY

TART

OOK

IME

LEAR

12345

67890

PPER

VEN

PPER

VEN

ETTINGS

OWER

VEN

RIDDLE

ONTROL

H 3 S

ONTROL

OCKOUT

TART

T O D

ELAY

TART

OOK

IME

LEAR

IZZA

IGHTS

VEN

AKE

ROBE

ROIL

IMER

LEAN

ELF

OOK

LOW

OWER

VEN

ITCHEN

IMER

OOK
