GE JGBS23BEACT Manual

GE Appliances

JGBS23WEAWW – GE 30" Free-Standing XL44™Gas Range

Dimensions (in inches) and Installation Information

30

46-1/2

29*

46-3/8

36±1/4

*Depth including handle

26-1/4"—Depth to front of closed oven door

25-1/4"—Depth to front top edge of cooktop

Optional Gas Range

Accessory Drip Pans for Sealed

and Standard Burner Models

(Available at additional cost)

To order these accessory drip pans,

call toll-free 800-848-7722.

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before

installing, consult installation

instructions packed with product

for current dimensional data.

24

30

8

4

92

C

L2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Recommended common area

for gas outlet and electrical

outlet for GE free-standing gas

range models

Specification Revised 4/02

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

For answers to your Monogram,

®GE Profile™or

GE appliance questions, visit our website at

GEAppliance.com or call

GE Answer Center®service, 800.626.2000.

CANADIAN GAS ASSOCIATION

RAPPROVED

Specification Revised 4/02

GE Appliances

JGBS23WEAWW –30" Free-Standing XL44™Gas Range

PRECISESIMMERMAXIMUMOUTPUT

Features and Benefits

•One-Piece Upswept Porcelain-Enameled Cooktop

•Sealed Cooktop Burners

•(1) 12,000/1,000 BTU Maximum Output Burner

•(1) 5,000/600 BTU Simmer Burner

•(2) 9,500/850 BTU All-Purpose Burners

•Deluxe Porcelain-Steel Square Grates

•Porcelain-Enameled One-Piece Drip Pans

•Electronic Pilotless Ignition System

•Extra-Large 4.4 cu. ft. Standard Clean Oven

•Electronic Clock and Timer

•Slide Out Broiler Drawer

•Extra-Large Broiler Pan and Grid

•2 Oven Racks/6 Embossed Rack Positions

•Removable Frameless Glass Oven Door with Big View Window

•Designer-Style Handle

•Model JGBS23WEAWW –White on white

•Model JGBS23DEFBB –Black on black

•Model JGBS23CEACC –Bisque on bisque

•Model JGBS23BEAWH –White

•Model JGBS23BEACT –Bisque
