Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

* Dimension from the wall to the front of the

closed door handle is 29”. Depth to front edge

of cooktop 25-1/4”.

JGBP88SEM

GE®30" Free-Standing Self-Clean Gas Range

Electrical Rating: 120V, 60Hz, 9A

Installation Information: Before installing,

consult installation instructions packed

with product for current dimensional data.

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

26-1/4*

46-1/8

46-3/8

36-1/4±1/4

*Dimension from wall

to front of closed

door handle is 29-1/8".

330592

Specification Revised 6/07

JGBP88SEM

PRECISESIMMERHIGHOUTPUT

BROIL LOCKED

COOKSTOPTIMER

CLEAN

CLOCK

START

CLEAN

BAKE

DELA

DOOR

ime

ontrols

ven

ontrols

On/Off

LoMedHi

ET/

SetWarmingZone

Control

Lockout

12345

67 8 90

lear

ooking

ime

elay

tart

ven

ight

elf

lean

lock

itchen

imer

ake

arming

rawer

roil

tart

rueT

emp

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• Center Oval Burner - Adds a fifth element to the center of the cooktop, ideal

for griddle or odd-size cookware

• Non-Stick Griddle - Offers a flat cooking surface, placed over the center oval

burner, for cooking multiple foods at once

• PowerBoil™17,000 BTU Burner - Delivers 17,000 BTUs of forceful heat

for rapid boiling

• Warming Drawer - Convenient drawer keeps breads, desserts or just-cooked foods

warm and ready-to-serve

• QuickSet V Oven Controls - Feature an easy to use design that allows you

to set precise cooking temperatures

• Precise Simmer Burner - Delivers a low setting of 140 degrees, ideal for delicate

foods and sauces

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement

of pans between burners

• Dishwasher-Safe Grates - Feature durable construction for worry-free

and effortless cleaning and maintenance

• Sealed Cooktop Burners - Eliminate the space between the burners and

the cooktop to help contain spills and boil over liquids, ensuring easy cleanup

• Model JGBP88SEMSS - Stainless steel

JGBP88SEM

GE®30" Free-Standing Self-Clean Gas Range

330592

Specification Revised 6/07
