GE JGB800DEP Manual

JGB800DEP

GE®30" Free-Standing Self-Clean Gas Range

Electrical Rating: 120V, 60Hz, 9A

Installation Information: Before installing,

consult installation instructions packed

with product for current dimensional data.

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Dimensions and Installation Information (in inches)

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

330547

Specification Created 6/09

All 30" GE gas and electric range backguards

are 30-7/8" wide.*

Note: 30" ranges conform to U.L. requirements

for 0" spacing from adjacent walls below

countertops. To reduce possible scorching of

walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended,

high heat, no-load heating element operation.

*Except these models: JGBS07, JGBS04, JGBP90,

all GE Profile free-standing electric and gas

ranges

Fits most countertop backsplash applications.

Consult Use & Care Manual for detailed

installation instructions.

30-7/8"

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30"

47"

26-1/4"

46-3/8"

36-1/4"+_1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

30" FS Gas Ranges-CL

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30"

47"

26-1/4"

46-3/8"

36-1/4"+_1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

JGB800DEP

PRECISESIMMER HIGHOUTPUT

ime

ontrols

ven

ontrols

Control

Lockout

12345

67890

lear

CTD

ake

roil

tart

ime

ontrols

ven

ontrols

Control

Lockout

12345

67890

lear

CTD

ake

roil

tart

Features and Benefits

• Self-cleanOven-Self-cleanallowsyoutospareyourselffromthetroubleand

effort it takes to scrub the oven interior. The oven does all the work!

• Super-large5.0cu.ft.OvenCapacity-Remarkablylargeoveninteriorisidealfor

holidays, dinner parties and everyday family cooking

• Heavy-cast,ContinuousGrates-Matte-finishcooktopgratesprovideasturdy,

uninterrupted surface that allows pots and pans to move easily

• WarmingDrawer-Theconvenientdrawerkeepsfoodswarmandreadytoserve

and helps makes meal coordination easier

• ReversibleCast-ironGriddle/Grill-Providestheflexibilitytosearmeatsonthegrill

and cook delicate meals on the griddle

• PowerBoil™17K Burner - This powerful element instantly supplies the intense heat

need for boiling, sautéing and stir frying

• CenterOvalBurner-Ovalfifthburnerinthecenterofthecooktopislargeto

accommodate odd-sized cookware or griddles

• Deep-recessedCooktop-Deeprecessedcooktopkeepsspills,andeverythingelse,

contained in one area that’s easy to wipe clean

• PreciseSimmerBurner-Simmerburnersallowsforlow,evenheatdistributionthat

is ideal delicate foods and sauces

•  T r u e T e m p ™OvenSystem-Thisfeaturehelpsensurethetemperatureyousetis

the temperature you get, with less variance, to give you the baking and broiling

performance you desire

• ModelJGB800DEPWW-Whiteonwhite

•ModelJGB800DEPCC-Bisqueonbisque

• ModelJGB800DEPBB-Blackonblack

JGB800DEP

GE®30" Free-Standing Self-Clean Gas Range

330547

Specification Created 6/09
