†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires

that new construction (not existing) utilize a 4-conductor

connection to an electric range.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing

from adjacent walls below countertops. To reduce possibility

of scorching walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat,

no-load heating element operation.

Installation information: Before installing, consult installation

instructions packed with product for current dimensional data.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Listed by

Underwriters

Laboratories

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Specification Created 4/07 321699

Dimension from wall to front of closed door handle is 27-3/4".

KW Rating

240V 10.5

208V 7.9

Breaker Size

40 Amps†

30

25

29-7/8

46-7/8

2-1/2

7-1/2

25-3/8

47-5/8

2-1/2

Acceptable electrical

outlet area

30_install_fse_ge.eps

Dimension from wall to front of

closed oven door handle is 27-3/4.

JBS55DM

GE®30" Free-Standing Electric Range

Specification Created 4/07 321699

Features and Benefits

• Standard Clean Oven - Offers a traditional oven design that requires

hand cleaning

• Super-Large Oven Capacity - Provides an impressively large oven interior for

cooking more dishes and large meals at one time

• QuickSet III Oven Controls - Feature an easy to use design that lets you set

precise cooking temperatures

• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning quick

and easy

• Big Hearth Window - Features an enhanced shape to add an elegant

appearance and make viewing trouble-free

• Dual Element Bake - Alternates the upper broiling element and the lower baking

element for even heating and optimal baking results

• Model JBS55DMKWW – White on white (white glass door and white

patterned cooktop)

• Model JBS55DMCC – Bisque on bisque (bisque glass door and bisque

patterned cooktop)

• Model JBS55DMBB – Black on black (black glass door and black patterned cooktop)

JBS55DM

BROIL OVEN

LIGHT

CLOCK

TIME CONTROLS

OVEN CONTROLS

ONOFF

KITCHEN

LIGHT

ONOFF

BAKESTART

ON

CLEAR

OFF

JBS55DM

GE®30" Free-Standing Electric Range
