†Note: Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires

that new construction (not existing) utilize a 4-conductor

connection to an electric range.

Receptacle Locations: Locally approved flexible service cord

or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location

of electrical outlet box. Recommended outlet locations allow

range to be installed directly against wall.

Note: 30" ranges conform to U.L. requirements for 0" spacing

from adjacent walls below countertops. To reduce possibility

of scorching walls, engineering recommends a minimum of

1-1/2" spacing to allow for possible extended, high-heat,

no-load heating element operation.

Installation information: Before installing, consult installation

instructions packed with product for current dimensional data.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000.

Listed by

Underwriters

Laboratories

R

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

JBP84TK/KK/BK

GE® 30" Free-Standing Electric Convection Range

Specification Created 5/05 321571

*Dimension from wall to front of closed door handle is 27-3/4".

KW Rating

240V 13.7

208V 10.3

Breaker Size

40 Amps†

30

25

29-7/8

46-7/8

2-1/2

7-1/2

25-3/8*

47-5/8

2-1/2

Acceptable electrical

outlet area

30_install_fse_ge.eps

*Dimension from wall to front of

closed oven door handle is 27-3/4

on models JBP84/81/80/72/70/66/

65/64/35/27/24 and JBS55.

JBP84TK/KK/BK

GE® 30" Free-Standing Electric Convection Range

Specification Created 5/05 321571

Features and Benefits

• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing

• Super-Large 5.3 Cu. Ft. Oven Capacity - Provides an impressively large oven interior

for cooking more dishes and large meals at one time

• Hidden Bake Oven Interior - Hides previously exposed bottom element to deliver

a clean interior appearance

• Self-Clean Heavy-Duty Oven Racks - Double coated procelain-enameled racks no

longer require hand cleaning

• Dual Size Ribbon Element - Offers a convenient choice of using a 9" or 12" heating

element, depending on the size of the pan

• Bridge Element - Combines three cooktop elements into one large cooking area,

ideal for oversized cooking pans

• Warming Drawer - Convenient drawer keeps breads, desserts or just-cooked

foods warm and ready-to-serve

• Warming Zone - Provides low heat capability for foods, making meal coordination simple

• QuickSet V Oven Controls - Feature an easy to use design that allows you to set

precise cooking temperatures

• True European Convection - A third dual-loop heating element surrounds the fan

to deliver uniform and savory cooking results

• Model JBP84TKWW – True white (white glass door and true white cooktop)

• Model JBP84KKCC – True bisque (bisque glass door and true bisque cooktop)

• Model JBP84BKBB – Black on black (black glass door and black patterned cooktop)

WARMING ZONE

MED

FRONT

BURNER

BRIDGE

BURNER

SMALL

BURNER

LARGE

BURNER

JBP84TK/KK/BK
