Specification Revised 11/01

JGSP44WEYWW—GE Profile™30" Slide-In Gas Range

Dimensions (in inches) and Installation Information

Counter Cutout Dimensions (in inches)

36-1/4

29-1/2*

45-13/16

35-7/8 to 38

*Depth with door handle.

26-7/8" Depth without handle.

Note: Model JGSP44WEY is shipped with special “vented” rear

filler strip. This filler strip or an optional backguard kit is

required when installing this range.

Optional Kits for Slide-In Gas Ranges

(Available at additional cost)

JXS28—Rear Filler Strip Kit (Brushed-Chrome)

Lower/Side Trim Kits

JXS52BB—Lower Trim Kit (Black)

JXS53WW—Lower Trim Kit (White)

JXS54AA—Lower Trim Kit (Almond)

Pub. No. 3-A040 Vertical Side Trim Kit

Accessory Backguards

JXS31—White Accessory Backguard

JXS32—Brushed-Chrome Accessory Backguard

JXS33—Almond Accessory Backguard

JXS34—Black Accessory Backguard

Endcap Kit

JXS40—Endcap kit to accommodate replacement where

countertop may already be notched.

Optional Gas Range Wok Accessory

(Available at additional cost)

JXWK—Wok accessory sits on top of maximum burner grate to

hold a round-bottom wok.

Note: Model JGSP44WEY is shipped with special “vented”rear

filler strip. This filler strip or the optional backguard kit

JXS33 is required when installing this range.

Electrical Rating: 120V, 60Hz, 5A

Note: Cabinets installed adjacent to slide-in ranges must have an

adhesion spec of at least 194°.

Installation Information: Before installing, consult installation

instructions [Pub. No. 31-10181] packed with product for current

dimensional data.

2" MIN. to

nearest

sidewall

(both sides)

35-7/8" MIN.

38" MAX.

18" MIN.*

30" MIN. clearance to cabinets

above cooktop

* AGA Requirement

2-1/2

1-1/2

2-1/2 20 10

2-1/2

7-1/2

Recommended area

for 120V outlet on

rear wall and area

for through the

wall connection

of pipe stub

and shut-

off valve

Recommended area

for through the floor

connection of pipe stub

and shut-off valve

12-1/2

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

For answers to your Monogram,

®GE Profile™or

GE appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

Specification Revised 11/01

JGSP44WEYWW—GE Profile™30" Slide-In Gas Range

Features and Benefits

•Glass Cooktop

•Sealed Cooktop Burner Design

•Standard Simmer Burner

•Maximum Output Burner

•Deluxe Cast Grates

•Porcelain-Enameled Drip Pans

•Electronic Pilotless Ignition System

•Self-Cleaning Oven with Delay Clean Option

•SmartSet Electronic Controls with Temperature Display, Start Pad, Delay Bake Option

with Cook and Hold, Audible Preheat Signal, Control Lock Capability

•Electronic Clock and Timer

•Auto Oven Shut-Off with Override

•In-Oven Broiling

•Porcelain-Enameled Broiler Pan

•Two Oven Racks

•Frameless Glass Oven Door With Window

•Removable Large Storage Drawer

•Soft Sure Grip Handle

•Model JGSP44WEYWW–White on White

•Model JGSP44BEYBB–Black on Black

•Model JGSP44AEYAA–Almond on Almond

•Model JGSP44CEYCC–Bisque on bisque
