GE Profile JT980SKSS Manual

R

Listed by

Underwriters

Laboratories

Dimensions and Installation Information

Note: Cabinets installed adjacent to wall ovens must have an adhesion

spec of at least a 194°F temperature rating. Electric wall ovens are not

approved for installation with a plug and receptacle. They must be

hard wired in accordance with installation instructions. Suitable oven

cabinet bracing must support 275 lbs.

Installation Information: Before installing, consult installation instructions

packed with product for current dimensional data.

KW Rating

240V 8.9

208V 6.7

Breaker Size

240V 40 Amps

208V 40 Amps

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000. Dimension and installation information are shown in inches.

C

L

Suitable

bracing

to support

runners

18

Over centerline

of cabinet

2 x 4 or

equivalent

runners

21" minimum

Door Opening

Allowance

B

B

A

A

Cutout height

51-13/16" MIN.

51-15/16" MAX.

Minimum cutout

location 2" from

the floor.

Cutout

depth

23-1/2"

MIN

5

47" to

bottom of

junction

box

Cutout width

28-1/2'' MIN.

28-5/8'' MAX.

21

Cabinet

width 30"

C

E

D

MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.

Conduit

(48-1/2"

long)

Junction

box

location

Bottom of

Cutout

DWO

jt980_install_ii.eps

32

25

7

Acceptable

junction box

location area

DWO

Cabinet 30"

A - Overlap of Oven Over Side Edges of Cutout 11/16"-3/4"

B - Overlap of Oven at Bottom of Cutout 1"

Oven

C - Overall Depth 23-1/2"

D - Overall Height 52-7/8"

E - Overall Width 29-3/4"

Specification Created 1/05

220603

JT980SK

GE Profile™ 30" Built-In Double Oven with Trivection™ Technology

JT980SH

Specification Created 1/05

220603

Features and Benefits

• TrivectionTM Technology - Combines thermal, convection and microwave energies to

produce quaility food remarkably fast

• Speed baking / Speed broiling - Uses TrivectionTM technology to cook food up to five

times faster than a traditional oven

• Convection bake (multi-rack) - Provides ideal convection baking for multiple racks of

food, ensuring superb results

• Convection roast - Provides even cooking and consistent results, roasting meats up to

25% faster than a conventional oven

• Glass touch oven controls - Feature a smooth glass design that is both easy-to-operate

and easy-to-clean

• Self-clean oven - Conveniently cleans oven cavity without the need for scrubbing

• Extra-large oven capacity - Provides a large oven interior ideal for cooking more

items at once

• TrueTempTM system - Delivers even heat distribution and maximum oven control

• Model JT980SKSS – Stainless steel

JT980SK

GE Profile™ 30" Built-In Double Oven with Trivection™ Technology
