GE JTP50SHSS Manual

GE Appliances

JTP50SH – GE®30" Built-In Double Wall Oven

Specification Created 8/03

320129

Dimensions (in inches)

R

Listed by

Underwriters

Laboratories

For answers to your Monogram,®GE Profile™or

GE®appliance questions, visit our website at

GEAppliances.com or call

GE Answer Center®service, 800.626.2000.

Cabinet 30"

A – Overlap of Oven Over Side Edges of Cutout 11/16" – 3/4"

B – Overlap of Oven at Top and Bottom of Cutout 1"

Oven

C –Overall Depth 23-1/2"

D –Overall Height 52-7/8"

E –Overall Width 29-3/4"

Note: Cabinets installed adjacent to wall ovens must have an

adhesion spec of at least a 194°F temperature rating.

Installation Information:Before installing, consult installation

instructions packed with product for current dimensional data.

21" minimum

Door Opening

Allowance

B

B

A

A

Cutout height

51-13/16" MIN.

51-15/16" MAX.

Minimum cutout location

12" from the floor.

Cutout width

28-1/2’’ MIN.

28-5/8’’ MAX.

21

Cabinet

width

30"

C

E

D

MOST 30’’ WALL CABINETS CAN BE USED WITH THIS UNIT.

THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2’’ WIDE.

CUTOUT DEPTH

23-1/2’’ MIN.

C

L2 x 4 or

equivalent

runners

Suitable

bracing

to support

runners 21-5/8"

over centerline

of cabinet

(Must support 275 lbs.)

KW Rating

240V 7.2

208V 5.4

Breaker Size

240V 40 Amps

208V 30 Amps

Electric wall ovens are not approved for installation with a plug and receptacle.

They must be hard wired in accordance with installation instructions.

Specification Created 8/03

320129

JTP50SH –GE®30" Built-In Double Wall Oven

Features and Benefits

•Self-clean oven –conveniently cleans oven cavity without the need for scrubbing.

•Super large oven capacity –Provides the impressively large oven interior for cooking more

dishes and large meals at one time.

•Electronic oven controls –One-touch electronic pads are easy-to-use and allow for simple

oven operation.

•TrueTemp™system –Delivers even heat distribution and maximum oven control.

•Big Clearview™window –An extra large clear window makes monitoring the progress of

the food easy.

•Interior oven light –Supplies light to make viewing the progress of cooking easy

and convenient.

•Dual element bake –Alternates the upper broiling element and the lower baking element

for even heating and optimal baking results.

•Model JTP50SHSS –Stainless steel

GE Appliances
