GE GDF520PGJ Manual

Listed by

Underwriters

Laboratories

GDF520PGJ/PSJ

GE®Series Dishwasher with Front Controls

Specification Created 5/15

DimenSionS anD inStallation inFormation (in incheS)

For answers to your Monogram,® GE Profile™ Series

or GE®Series appliance questions, visit our website

at geappliances.com or call GE Answer Center®

service, 800.626.2000.

ERUSOLCNEREHSAWHSIDERAPERP

• The rough cabinet opening must be at least 24" deep, 24"

wide and approximately 33-1/2" to 34-3/4" high from floor

to underside of the countertop.

24"

Min.

This Wall Area

must be Free

of Pipes or

wires

Plumbing and Electric Service

Must Enter Inside This Area

24"

Min.

Cabinets

Square

and

Plumb

34-1/2" 1/4"

Underside of

Countertop

to Floor

Figure A

33-1/2” to 34-3/4”

Underside of

Countertop

to Floor

ElEctrical rating

Volt age AC ........................................................120

Hertz................................................................. 60

Total connected load amperage......................... 7.1

Calrod®heater watts ......................................... 415/800

For use on adequately wired 120-volt, 15-amp circuit having

2-wire service with a separate ground wire. This appliance

must be grounded for safe operation.

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

24"

Typical

33-3/8" MIN.

MAX.

adj .to

34-5/8"

23-3/4"

29-7/8"

4"(toekick)

27-1/2"

Specification Created 5/15

GDF520PGJ/PSJ

GE®Series Dishwasher with Front Controls

GDF520PGJBB_GDF520PGJCC

GDF520PGJWW_GDF520PSJSS

Features and Benefits

GE’s most advanced wash system – Consistently clean and dry dishes are ensured with

GE’s most advanced wash system, featuring 65% more wash power.*

Piranha™hard food disposer with removable filter – To ensure consistently clean items,

this stainless steel blade rotates at 3,600 RPM to pulverize food particles and helps to

prevent large particles from clogging the wash arms

Steam PreWash – Loosens tough soils before any cycle, virtually eliminating the need

for soaking or pre-rinsing dishes

Sanitize option (NSF residential) – High-temperature rinse sanitizes and reduces

99.999% of bacteria found on dishes

54 dBA with status light on door – A dishwasher this quiet has a multi-colored status

light to let you know it is running

SpaceMaker®silverware basket – Enjoy table-ready silverware and loading flexibility

with this unique basket that can be placed on the rack or onto the door

Pearlescent dark gray racks with ball tip tines – Offer durability and secure dishes

Model GDF520PSJSS – Stainless steel

Model GDF520PGJWW – White

Model GDF520PGJBB – Black

Model GDF520PGJCC – Bisque

*Wash power delivered to each rack. Compared to previous GE models
