Dishwasher Training –2011

New Door Configuration

2011 E - Star

2

Updates Front Control Models

•2011 E-star w/ enhanced control.

•Locking connectors on control/harnesses.

•Upper rack slides improved to wheels on rails.

•Revised tines spacing in upper/lower racks.

New Product - Top Controls on Plastic Tubs

•Top controls –new console and tactile UI for control.

•Locking connectors on harnesses.

•Pocket handle and towel bar handle models.

•Racking improvements –upper rack slides + tine spacing improvements.

•Gray tubs and inner doors .

New Product - Entry level Top Controls on SS Tubs

•Top controls –new console and tactile UI (same as above)

•Limited pocket handle models.

Current front control

New pocket handle top control

3

7/28/2011

IMPORTANT SAFETY NOTICE

The information in this presentation is intended for use by individuals

possessing adequate backgrounds of electrical, electronic, & mechanical

experience. Any attempt to repair a major appliance may result in

personal injury & property damage. The manufacturer or seller cannot be

responsible for the interpretation of this information, nor can it assume

any liability in connection with its use.

WARNING

To avoid personal injury, disconnect power before servicing this product.

If electrical power is required for diagnosis or test purposes, disconnect

the power immediately after performing the necessary checks.

RECONNECT ALL GROUNDING DEVICES

If grounding wires, screws, straps, clips, nuts, or washers used to

complete

a path to ground are removed for service, they must be returned to their

original position & properly fastened.

4

7/28/2011

GE Factory Service Employees are required to use safety glasses with side

shields, safety gloves & steel toe shoes for all repairs.

Dyneema® Cut

Resistant Glove

Steel Toe Shoes Plano Safety Glasses

VR Gloves –provide shock protection

Prescription Safety Glasses

Safety Glasses

must be

compliant with

ANSI Z87.1-2003

5

7/28/2011

Front Control

Top Control

6

7/28/2011

New Door components

Tactile Control Buttons, Vent, Pocket Door Handle and

Front Light Indicator Lens

7

7/28/2011

Front Controls Top Controls

GLD2800V GLD2850V GLD4908V GLD4968V

GLD4500V GLD4550V GLD4560V GLD5606V GLD5656V GLD5666V

GLD4604V GLD4644V GLD4664V GLD5706V GLD5756V GLD5766V

GLC5604V GLD5808V GLD5868V

GLD5604V GLD5654V GLD5664V GLD7706V GLD7766V

GLD5600V GLD5660V GLD7708V GLD7768V

GLD7806V GLD7866V

GDET106V GDWT166V

8

7/28/2011

Cycles and Times (Top Control):

Auto**: 5-7 gallons* 49-133 minutes*

Sanitize: 8.8-11.8 gallons* 50-279 minutes*

Normal: 3.3-8.3 gallons* 54-143 minutes*

Light: 7.6-10.5 gallons* 46-88 Minutes*

*Min = low soil

Max = high soil and all options selected

35 minute heated dry in Normal Wash

45 minute dry in Auto, Sanitize and Light Wash

Steam Option adds 15 minutes to cycle

**Some models do not have an Auto Cycle

Use and Care shows Minimum Times. No Enhancements

9

7/28/2011

Cycles and Times (Front Control):

Pots & Pans or Heavy**: 11.8 gallons 88 minutes (Timed cycle)

Sanitize**: 8.8-11.8 gallons* 50-279 minutes*

Normal: 3.3-8.3 gallons* 54-143 minutes*

Light**: 7.6-10.5 gallons* 46-88 Minutes*

China Crystal**: 9.2 gallons 41 minutes (Timed Cycle)

Rinsed Only**: 1.2 gallons 7 minutes

*Min = low soil

Max = high soil and all options selected

35 minute heated dry in Normal Wash

45 minute dry in Auto, Sanitize and Light Wash

Steam Option adds 15 minutes to cycle

**Some models do not have an this Cycle

Use and Care shows Minimum Times. No Enhancements

10

7/28/2011

Cycle Time Definition Normal or Auto Cycles with all

Heat Options selected (times and cycles change

depending on Turbidity Sensor readings)

Pre- Pre- Pre- Steam Steam Pre- Pre- Main Post Post Final

Wash Wash Wash Wash Wash Wash Wash Wash Rinse

Water Valve (seconds) 63 17 17 63 21 63 21 21 63 23 23

Circulation (minutes) 5 5 5 15 2 10 15 30 2 3 10

Heater (minutes) 17 7 10 15 30 8 5

Drain (seconds 7 7 75 10 75 10 10 75 11 11 105

35 minute heated dry in Normal Wash

45 minute dry in Auto,

Note: depending on Turbidity Response, it is possible the cycle could skip

from the first Pre-Wash to the Main Wash and then to Final Rinse.
