GE 165D4700P138 Manual de usuario

GE Appliances

GE Answer Center

800.626.2000

Dishwashers

Part No. 165D4700P138 Pub. No. 49-5792

GSD4010

GSD4020

GSD4030

Owner’s Manual

Congratulations!

You Are Now Part of the GE Family.

Welcome to the GE family.

We’re proud of our quality

products and we are

committed to providing

dependable service. You’ll

see it in this easy-to-use

Owner’s Manual and you’ll

hear it in the friendly voices

of our customer service

department.

Best of all, you’ll experience

these values each time you

use your dishwasher. That’s

important, because your

new dishwasher will be part

of your family for many

years. And we hope you will

be part of ours for a long

time to come.

We thank you for buying

GE. We appreciate your

purchase, and hope you

will continue to rely on us

whenever you need quality

appliances for your home.

Important!

Staple sales slip or cancelled

check here.

Proof of the original purchase date

is needed to obtain service under

the warranty.

Write the model and serial

numbers here.

#You can find them on the tub wall just

inside the door.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

GE&You,

AService Partnership.

Inside you will find many

helpful hints on how to use and

maintain your dishwasher

properly. Just a little preventive

care on your part can save you a

great deal of time and money

over the life of your dishwasher.

Read this Manual

Ask any GEappliance owner and they will

tell you we stand behind our products with

unmatched quality service. However, did

you know that most questions result from

simple problems that you can easily fix

yourself in just a few minutes? This

Owner’s Manual can tell you how.

You’ll find many answers to

common problems here.

If you review our chart of

Troubleshooting Tips first,

you may not need to call for

service at all.

Review the Section on

Troubleshooting Tips

If you do need service, you can

relax knowing help is only a

phone call away. A list of toll-free

customer service numbers is

included in the back section.

Or you can always call the

GE Answer Center®at

800.626.2000, 24 hours a day,

7 days a week.

If You Need Service

Safety Information . . . . . . .4–7

Operating Instructions

Control Panel . . . . . . . . . . . . . . .8

Control Settings . . . . . . . . . . .8, 9

Dial Cycles . . . . . . . . . . . . .10–11

Using the Dishwasher . . . .12, 13

Loading the

Dishwasher Racks . . . . . . .14, 15

Changing Color Panels . . . . . . .16

Care and Cleaning . . . . . . . . . .18

Troubleshooting Tips

Before You

Call For Service . . . . . . . . . 19–23

Customer Service

Warranty . . . . . . . . . . . . . . . . .27

Service Telephone

Numbers . . . . . . . . . .Back Cover

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be

followed to minimize the risk of fire, explosion, electric

shock, or to prevent property damage, personal injury,

or loss of life.

Under certain conditions hydrogen gas may be produced in

a water heater that has not been used for two weeks or

more. Hydrogen gas can be explosive under these

circumstances.

If the hot water has not been used for two weeks or more, prevent

the possibility of damage or injury by turning on all hot water

faucets and allow them to run for several minutes. Do this before

using any electrical appliance which is connected to the hot water

system. This simple procedure will allow any built-up hydrogen gas

to escape. Since the gas is flammable, do not smoke or use an open

flame or appliance during this process.

WATER HEATER SAFETY

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Use this appliance only for its intended purpose as

described in this Owner’s Manual.

This dishwasher must be properly installed and located in

accordancewith theInstallation Instructionsbefore itis used.

If you did not receive an Installation Instructions sheet with

your dishwasher, you can receive one by calling us toll-free

at the GE Answer Center®

, 800.626.2000.

■Connect to a grounded

metal, permanent wiring

system; or run an equipment-

grounding conductor with

the circuit conductors and

connect to the equipment-

grounding terminal or lead

of the appliance.

■Improper connection of the

equipment-grounding

conductor can result in a risk

of electric shock. Check with

a qualified electrician or

service representative if you

are in doubt whether the

appliance is properly

grounded.

■Dispose of discarded

appliances and shipping or

packing material properly.

■Do not attempt to repair or

replace any part of your

dishwasher unless it is

specifically recommended in

this manual. All other

servicing should be referred

to a qualified technician.

■To minimize the possibility of

electric shock, disconnect

this appliance from the

power supply before

attempting any maintenance.

NOTE:

Turning the

dishwasher off does not

disconnect the appliance

from the power supply. We

recommend having a

qualified technician service

your appliance.

PROPER INSTALLATION

AND MAINTENANCE

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

DO NOT…

■Do not tamper with controls.

■Do not abuse, sit on, or stand

on the door or dish rack of

the dishwasher.

■Do not discard a dishwasher

without first removing the

door of the washing

compartment.

■Do not store or use

combustible materials,

gasoline or other flammable

vapors and liquids in the

vicinity of this or any other

appliance.

■Do not allow children to play

inside, on or with this

appliance or any discarded

appliance.

WARNING!

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

WHEN USINGYOUR DISHWASHER

■Use only powder or liquid

detergents or wetting agents

recommended for use in a

dishwasher.

■Locate sharp items so that

they are not likely to damage

the door seal.

■Load sharp knives with the

handles up to reduce the risk

of cut-type injuries.

■Do not wash plastic items

unless marked

dishwasher

safe

or the equivalent. For

plastic items not so marked,

check the manufacturer’s

recommendations.

■Do not touch the heating

element during or

immediately after use.

■Do not operate your

dishwasher unless all

enclosure panels are properly

in place.

■Close supervision is necessary

if this appliance is used by or

near children.

■Load light plastic items so

they will not become

dislodged and drop to the

bottom of the dishwasher—

they might come into contact

with the heating element and

be damaged.

REMEMBER…

Your continued health and safety are important to us.

Please read and follow this Safety Information carefully.

We want you to remain a happy and healthy part of our

GE family.

SAVE THESE INSTRUCTIONS

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dishwasher control panel.

You can locate your model number on the tub wall just inside the door.

Throughout this manual, features and appearance may vary from your model.

Control Settings

Cycles

POTSCRUBBER For heavily soiled dishes or cookware with dried-on

or baked-on soils. Everyday dishes may be included.

This cycle will not remove burned-on foods.

NORMAL WASH For loads of everyday dishes, glasses and cookware

with medium soils.

NOTE:

Many dishes have lighter

soil than normal. Choosing a cycle other than

NORMAL WASH

will save energy and water.

LIGHT WASH For dishes with light soils.

■Make sure the Dial is at the

OFF

position.

■Latch the door.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

CYCLES

PLATE

WARMER

(PRESS

HEATED DRY)

START

OFF

ENERGY OPTIONS STATUS

POT-

SCRUBBER NORMAL

WASH LIGHT

WASH TEMP

BOOST HEATED

DRY ENERGY

SAVER CYCLE

1 2 3

Energy Options

TEMP BOOST Provides extra heat for best performance. It is used

best with heavily-soiled dishes.

HEATED DRY Turns the drying heater on for fast drying. This

cycle will extend the time to your wash cycle.

ENERGY Shuts off the drying heat options. Dishes air dry

SAVER naturally and energy is saved.

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information

Start

Slowly turn the Dial to the

START

position. Don’t turn it

past the

START

position, or you could accidentally miss a

rinse. There is a time delay between start-up and water

fill so you will not hear any wash action right away.

Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service

About the dial cycles.

Short Wash

For quickly washing loads of everyday dishes with

medium soils that have not dried on.

Select the

NORMAL WASH

cycle and any options.

Be sure the door is unlatched.

Slowly turn the Dial to

SHORT WASH

Latch the door to start the cycle.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE

WARMER

(PRESS

HEATED DRY)

START

OFF

Rinse & Hold

For rinsing partial loads that will be washed later.

Do not

use detergent.

Make sure

ENERGY SAVER

is selected.

Be sure the door is unlatched.

Slowly turn the Dial to

RINSE & HOLD.

Latch the door to start the cycle.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE

WARMER

(PRESS

HEATED DRY)

START

OFF

Plate Warmer

For warming clean dishes and serving plates. This cycle

will take approximately 32 minutes.

Load clean dishware to be warmed.

Select

HEATED DRY.

Be sure the door is unlatched.

Slowly turn the Dial to

PLATE WARMER.

Latch the door to start the cycle.

SHORT

WASH

START DELAY

(HRS)

RINSE & HOLD

PLATE

WARMER

(PRESS

HEATED DRY)

START

OFF

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de GE

GE GSD3200 Series Manual de usuario

GE GE Nautilus GSD2325FBB Manual de usuario

GE GDT665SMNES Manual de usuario

GE GDT645S Manual de usuario

GE Monogram ZBD3500 Manual de usuario

GE GSD700L Manual de usuario

GE Profile PDW8900N Manual

GE GSD906 Manual de usuario

GE Triton GSD5900G Manual de usuario

GE Stainless Steel Tub Dishwashers Manual de usuario

GE Adora GHDT108V Manual de usuario

GE Profile PDW8000 Series Manual de usuario

GE Monogram ZBD1850NII Manual de usuario

GE GSD700G Manual de usuario

GE GDF510PSDSS Instrucciones de montaje

GE GSC870 Manual de usuario

GE Stainless Steel Tub Dishwashers Manual de usuario

GE GDF520PSDSS Manual

GE 206C1559P148 Manual de usuario

GE GDF 570 Series Manual de usuario

GE GDF510-540 Series Manual de usuario

GE GSD4900Z Cómo utilizar

GE Dishwashers Manual de usuario

GE Electronic Dishwasher Manual de usuario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
