For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

130255

Specification Created 6/07

Listed by

Underwriters

Laboratories

ZHU30RBM

GE Monogram®30" Electric Induction Cooktop

Dimensions and Installation Information (in inches)

Cutout Dimensions:

30" Models A B C D

ZHU30RBM 29-3/4" 21-3/8" 28-1/2" 19-5/8"

269Dia1

A

C

2" Min.

to Side Walls

B

2-1/2"

Min.

to Front

Edge

1-3/4"

Min.

D

269Dia2

3-1/4" 6-1/4"

5-1/2"

557ZEU669

16" Min

Junction

Box

Combination installations

Consideration must be given to electrical supply locations

when the cooktop is installed with other products in the same

cabinet. Always refer to each product's installation instructions

for clearances and electrical requirements.

• Install these cooktops with any exhaust hood of the same

or treater width; 300 CFM or greater air flow rating is

recommended.

• The 30" cooktop may be installed in combination with a

Monogram®30" downdraft vent. Install the 36" cooktop with

a 36" downdraft vent. See downdraft vents for details.

• A Monogram single oven may be installed below these

cooktops.

The serial plate is located on the bottom of the cooktops.

Electrical requirements

Product rating is 120/240V, 60Hz, 36" cooktops

to a 50-amp circuit; and 30" cooktops to a 40-

amp circuit. The cooktops must be connected

to a supply circuit of the proper voltage and

frequency and protected by a time-delay fuse or

circuit breaker.

All models require 12" minimum clearance below

the cooktop bottom to combustible materials.

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

130255

Specification Created 6/07

Listed by

Underwriters

Laboratories

ZHU30RBM

GE Monogram®30" Electric Induction Cooktop

Features and Benefits

• Induction Technology - Induction elements use

electricity to produce a magnetic field that reacts

with the iron in metal cookware - including cast

iron and magnetic stainless steel pans - and

transfers the heat to the cookware

• Sophisticated Styling - Frameless black models

are smooth from edge to edge, making them

easy to clean

• Digital Controls - Embedded in the cooktop offer

added style and convenience

• 3,700-Watt, 11" Element - The most powerful

induction in the industry, it provides instantaneous

heat across 19 different cooking settings

• Digital Pan-Sensing Technology - Detects the

presence of pans made of iron materials, a

requirement for induction cooking

• Pan Size Sensor - Automatically adjusts the heating

element to the size of the pan

• Warm Setting - provides just enough heat to

maintain an ideal serving temperature

• Timer, Control-Lock Capability and Hot-Surface

Indicator - provide an extra measure of

convenience and safety

• Flexible Installation - Above a Monogram single

wall oven is made possible by shallow-depth

configuration with integrated cooling system

• Model ZHU30RBMBB – Black

ZHU30RBMBB
