GE JGP630SEKSS Manual

Dimensions and Installation Information

For answers to your Monogram,® GE Profile™ or

GE® appliance questions, visit our website at

ge.com or call GE Answer Center® service,

800.626.2000. Dimension and installation information are shown in inches.

JGP630SEK

GE® 36" Built-In Gas Cooktop

Specification Created 11/04

330343

Gas Connection

Cooktop

2-1/2

(Min.)

33-7/8

19-1/8

3-3/16

36 21

Electrical junction

box 12" MIN.

below countertop

30" MIN. to

unprotected

cabinet

Cut should

not interfere

with cabinet

structure at

front

3-3/4" MIN.

clearance to

side wall

from cut-out

6" MIN.

clearance to

side wall

from cut-out

18" MIN.

to cabinet

2-1/4" to

rear wall

13" MAX.

depth

Electrical

cord

Electrical

outlet

Shut-off

valve

Pressure

regulator

1/2" pipe

Coupling

AGA Requirement: All gas cooktop models require

7/16" free area below cooktop height to combustible

material. Requires 18" minimum from countertop to

adjacent overhead cabinets.

Note: If installing with a GE ProfileTM Telescopic

Downdraft System, consult both cooktop and

downdraft installation instructions packed with

product before installing. Cooktop gas/electric

supply may need to be re-routed to install

downdraft.

Electrical Rating: 120V, 60Hz, 5A

Installation With Single Wall Oven Information:

30" Gas Cooktops are approved for use over select

GE 27" and 30" Wall Ovens and Warming Drawers.

30" and 36" Gas cooktops are approved for use

over 30" Wall Ovens and Warming Drawers.

Refer to cooktop and wall oven/warming drawer

installation instructions packed with product for

current dimensional data.

Installation Information: Before installing, consult

installation

instructions, packed with product, for

current dimensional data.

JGP630SEK

GE® 36" Built-In Gas Cooktop

Features and Benefits

• Deep Recessed Cooktop - Designed with a recessed surface to help

contain spills and make cleaning easy

• Sealed Cooktop Burners - Eliminates the space between the burners

and the cooktop to help contain spills and boil over liquids, ensuring

easy cleanup

• High Output Burner - Provides a powerful burner output for efficient

heat-up and boiling

• Precise Simmer Burner - Delivers a low settng of 140 degrees, ideal for

delicate foods and sauces

• Continuous Grates - Provide a flat, sturdy surface allowing easy

movement of pans between burners

• Dishwasher-Safe Grates and Knobs - Feature durable construction

for worry-free, effortless cleaning and maintenance

• Medium Cast Grates - Constructed from a durable cast iron material

for long-lasting performance and reliability

• Electronic Pilotless Ignition - Provides reliable burner ignition operation,

eliminating the need for a standing pilot

• Model JGP630SEKSS - Stainless steel

Specification Created 11/04

330343
