3
Important Safety Information
8
Installation Instructions
Important Electrical Safety
Window Installation
Through-the-Wall Installation
4
Operating Instructions
The Controls on Your Air Conditioner
Care of Product
24
Helpful Information
Things That Are Normal
25
If Something Goes Wrong
Before You Call for Service
GE Service Numbers
Warranty
GE Appliances
Air Conditioner
Owner’s Manual
Standard and Easy Mount
Cool Only:
AJCS 06 LZ
AJCS 08, 10 AZ
Heat/Cool:
AJES 06 LS
AJES 08 AS
AJES 10 DS
Heat Pump:
AJHS 08 AS
GE Answer Center
®
800.626.2000
49-7362-1
2-98 CG

Welcome to the GE family. We’re

proud of our quality products and

we believe in dependable service.

You’ll see it in this easy-to-use

manual and you’ll hear it in the

friendly voices of our customer

service department.

Best of all, you’ll experience

these values each time you enjoy

the comfort of your air conditioner.

That’s important, because your

new air conditioner will be part of

your family for a long time.

Welcome

Write down the model and serial

numbers here.

They are on a label

on the front of the control box

behind the front grille.

Model number

Serial number

Date of purchase

Staple your receipt to the inside back

cover of this manual. You will need it

to obtain service under warranty.

Start Here!…Before using your air conditioner

Need Help?

Read this manual.

It contains

instructions to help you use and

maintain your air conditioner

properly.

Save time and money.

Check the

section titled “If Something Goes

Wrong” before calling. This sec-

tion helps you to solve common

problems that might occur.

If you do need service, you can

relax knowing help is only a

phone call away. A list of toll-free

customer service numbers is

included in the back of this book.

Or call the

GE Answer Center

at 800.626.2000,

24 hours a day,

7 days a week.

Help us

help you

800.626.2000

Before you call for service,

there are a few things you

can do to help us serve you

better.

IMPORTANT SAFETY INFORMATION

READ ALL SAFETY INFORMATION

BEFORE USING

•This air conditioner must be

properly installed in accordance

with the Installation Instructions

before it is used.

•Repair or replace immediately

all electric service cords that have

become frayed or otherwise

damaged.

•Turn the mode control to

OFF

and

unplug your air conditioner before

making any repairs.

NOTE:

We strongly recommend

that any servicing be performed by

a qualified individual.

Because most 2-prong outlets are

not grounded, we strongly advise

against using an adapter plug.

However, a temporary connection

may be made where local codes

permit and if the 2-prong wall out-

let is properly grounded.

When you plug the adapter in,

make sure the larger prong goes

into the larger slot to provide the

proper polarity for the power cord.

FOR PROPER GROUNDING:

1 Screw the adapter to the outlet,

using the outlet cover screw.

2 Ground the outlet through the house

wiring.

When disconnecting the power

cord from the adapter, hold the

adapter close to the outlet while

pulling the plug out. If this is not

done, the grounding connector is

likely to break with repeated use.

If the grounding connector breaks,

DO NOT USE

the air conditioner

until a proper ground has again

been made.

Adapter Plug

This is a temporary method.

UL-listed adapters are avail-

able at most hardware stores.

The use of an extension cord is not

recommended. However, if an

extension cord is required to reach

the nearest wall receptacle, use only

a UL-listed, 3-wire, grounded, 14

gauge, 15A, 125V appliance exten-

sion cord.

CAUTION:

DO NOT use an extension cord with

any of the 208/230-volt models.

Extension Cord

SAVE THESE INSTRUCTIONS

Your model will look like one of these.

The temp control is used to maintain the

room temperature. The compressor will cycle

on and off to keep the room at the same level

of comfort. When you turn the knob to

COOLER

(blue) the indoor air will become cooler. Turn

the knob to

WARMER

(red) and the indoor air

will become warmer.

HEAT PUMP MODELS

When the outdoor temperature is lower than

25°F., heat is provided by the electric heater in

the air conditioner instead of by the heat pump.

NOTE:

The electric resistance heater in the 115-volt

heat pump model operates during defrost when

the outdoor coil temperature is below 36°F. It is

not intended to provide full heat capability.

HIGH COOL

and

LOW COOL

provide cooling with

different fan speeds.

HIGH HEAT

and

LOW HEAT

provide heating with

different fan speeds.

LOW FAN

HIGH FAN

provides air circulation

and filtering without cooling or heating.

NOTE:

If you move the switch from a cool or heat setting

to OFF or to a fan setting, wait at least 3 minutes

before switching back to a cool or heat setting.

A 3-minute delay is automatically provided on the

Heat/Cool and Heat Pump models.

Operating Instructions

The

controls

on your

air

conditioner

Temp Control Mode Control

1 2

TEMP CONTROLS MODE CONTROLS

OFF

LOW

FAN

HIGH

FAN HIGH

COOL

LOW

COOL

OFF

LOW

FAN HIGH

FAN

HIGH

HEAT HIGH

COOL

LOW

COOL

LOW

HEAT

Cooling/Heating Descriptions

FOR NORMAL COOLING

OR HEATING

Select

HIGH COOL

HIGH

HEAT

with the thermostat

at mid point.

FOR MAXIMUM COOLING

Select

HIGH COOL

with the

thermostat at maximum

cool.

FOR MAXIMUM HEATING

Select

HIGH HEAT

with the

thermostat at maximum

heat.

FOR QUIETER &

NIGHTTIME COOLING

Select

LOW COOL

LOW

HEAT

with the thermostat

at mid point.

3 4 5 6

Each position equals

approximately 3° F.

Limits

heat

temp

Limits

cool

temp

OPEN

On Heat/Cool models, the fan switch lever is

located in a hole through the control panel. To

reach it, you need to remove the front grille.

Use a small screwdriver to change the setting.

Cool only models have a rocker switch on the

front of the control box.

When set at

CYCLE

(down) the fan cycles on and

off when cooling or heating. When set at

CONT

(continuous, up) the fan runs all the time. The

unit is shipped in the

CONT

setting.

The vent control is located behind the front

grille. When set at

, only the air inside the

room will be circulated and conditioned. You

may adjust it by removing the front grille. When

set at

OPEN

, some inside air is exhausted out-

side.

NOTE:

The vent lever is taped in the

position when it leaves the factory. Remove

the tape before using.

Fan Switch Vent Control

Limiting the maximum and minimum settings

prevents users from turning the control to the

extreme heat or cool positions.

The normal range of the temp control is approx-

imately 60° F to 85° F. The control range may be

narrowed by the use of the temperature limiting

screws located behind the control panel.

Horizontal louvers on the front grille let you

control the air direction up and down.

Remove the front grille to adjust the vertical

louvers side-to-side to direct the air left or right.

Temperature Limiting Air Direction

Features and appearance may vary.

Operating Instructions

Care & Cleaning

Turn the air conditioner off and

remove the plug from the wall out-

let before cleaning.

To clean, use water and a mild

detergent. Do not use bleach or

abrasives.

Grille and Case

The coils on the outdoor side of

the air conditioner should be

checked regularly. It is necessary to

remove the chassis from the wall

case to inspect them. Dirt build-up

occurs on the surface which is not

visible from the outside. If they are

clogged with dirt or soot they may

be professionally steam cleaned, a

service available through your GE

service outlet.

Turn the air conditioner off before

cleaning.

The most important thing you can

do to maintain the air conditioner

is to clean the filter at least every 30

days. Clogged filters reduce cool-

ing, heating and airflow.

Keeping the filter clean will:

•Decrease cost of operation.

•Save energy.

•Prevent clogged heat exchanger

coils.

•Reduce the risk of premature

component failure.

To clean the air filter:

•Vacuum off the heavy soil.

•Run water through the filter

from the back side.

•Dry thoroughly before replacing.

Carefully pull the tab forward, up

and out.

Replace the clean filter by pushing

it back into place.

CAUTION:

DO NOT operate the air conditioner

without the filter in place. If a filter

becomes torn or damaged it should

be replaced immediately.

Operating without the filter in

place or with a damaged filter will

allow dirt and dust to reach the

indoor coil and reduce the cooling,

heating, airflow and efficiency of

the unit.

Replacement filters are available

from your salesperson, GE dealer,

GE Service and Parts Center

or authorized Customer Care®

servicers.

•For personal safety, this air conditioner must be

properly grounded.

•It is important to have the wall outlet and circuit

checked by a qualified electrician if there is any

doubt as to whether a proper ground exists.

•Follow National Electrical Code (NEC) or local

codes and ordinances.

CAUTION:

•

Do not, under any circumstances, cut or remove

the third (ground) prong from the power cord.

•

Do not change the plug on the power cord of this

air conditioner.

•

Aluminum house wiring may present special

problems—consult a qualified electrician.

We recommend that the 230/208-volt, 60 Hz

models be installed on their own single branch

circuit supplying 230/208-volt a.c., protected

with a time delay fuse or circuit breaker.

PPaarraalllleellPPeerrppeennddiiccuullaarrTTaannddeemm

115V. 230/208V. 230/208V.

15 Amp. 20 Amp. 15Amp.

This is recommended for best performance and

to prevent overloading house or apartment

wiring circuits, which could cause a possible fire

hazard from overheating wires.

The 115-volt models require a 115/120-volt a.c.,

60 Hz grounded outlet protected with a 15-amp

time delay fuse or circuit breaker.

The 3-prong grounding plug minimizes the possi-

bility of electric shock hazard.

If the wall outlet

you plan to use is only a 2-prong outlet, it is your

responsibility to have it replaced with a properly

grounded 3-prong wall outlet.

Important Notes

Installation Instructions

Important Electrical Safety–Read Carefully

Installer: Leave these instructions with the appliance.

Owner: Keep these instructions for future use.

Electrical Requirements

Before you begin AJES and AJHS models have filler panels. Directions begin below.

The installation instructions for AJCS models with accordion curtains

begin on page 17.

IMPORTANT:

Be sure to remove the shipping pad inside the air conditioner next to the compressor.

•Phillips-head

screwdriver

•Wood saw

•Adjustable wrench

•Ruler or tape

measure

•Scissors or knife

•Pencil

•Level

•Drill

Installation Instructions

Read completely, then follow step-by-step

•These instructions are for a standard double-

hung window. You will need to modify them for

other types of windows.

•The air conditioner can be installed without

the filler panels if needed to fit in a narrow

window. See the window opening dimensions

to the right.

•All supporting parts must be secured to firm

wood, masonry or metal.

•The electrical outlet must be within reach of

the power cord.

A storm window frame will not allow the air

conditioner to tilt towards the outside and will

keep it from draining properly. To adjust for this,

attach a piece of wood to the sill and the stool.

WOOD PIECES:

WIDTH:

2²

LENGTH:

Long enough to fit inside the window

frame.

THICKNESS:

To determine the thickness, place a

piece of wood on the stool to make it 1/2²higher

than the top of the storm window frame.

Attach securely with nails or screws provided by

the installer.

Window opening dimensions are for a standard double-hung

window.

17²min.

31²to 43²

(With filler panels)

261¤4²min.

(Without filler panels)

1/2²higher

than frame

Stool

Sill

Storm window

frame

Wood

Window Requirements

Storm Window Requirements

Otros manuales para AJCS 06 LZ

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de GE

GE AJCQ10DCD Series Instrucciones de montaje

GE AHTT06 Instrucciones originales

GE ASV08FK Manual

GE AQX06 Instrucciones de instalación

GE AHD08 Manual de usuario

GE AZ29E15DABM1 and Instrucciones de funcionamiento

GE AJCQ12ACD Instrucciones de montaje

GE AGW06 Instrucciones de funcionamiento

GE AVE15 Instrucciones originales

GE ASH12AL Instrucciones de funcionamiento

GE Appliances AEE18 Instrucciones de funcionamiento

GE Quietaire AQ708 Instrucciones de instalación

GE AEQ06 Instrucciones de funcionamiento

GE Zoneline AZR Series Manual de usuario

GE AJES10DSC Manual de usuario

GE AEZ05 Instrucciones de funcionamiento

GE ADQ12 Instrucciones de funcionamiento

GE AGW05 Instrucciones de funcionamiento

GE AEM12AX Instrucciones de funcionamiento

GE GES-NX2G70OUT Manual de usuario

GE AER05LX Instrucciones de funcionamiento

GE AEE12DK Instrucciones de montaje

GE GE Zoneline AZ38H09E Instrucciones de uso

GE AGM12AB Instrucciones de montaje

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
