INFRARED ELITE

MODELS I , II AND III

INFRARED

GAS GRILLS

OWNERS MANUAL

FOR OUTDOOR USE ONLY

Contents:

qLocation Requirements

qAssembly

qGas Requirements

qLP Gas Hook-up

qNatural Gas Hook-up

qOperation

qMaintenance and Cleaning

qReplacement Parts

qTrouble shooting

qWarranty

For Your Safety

If you smell gas:

1. Shut off gas to the appliance

2. Extinguishanyopename

3. Open lid.

4. If odor continues, immediately call your gas

 supplieroryourredepartment.

For Your Safety

1. Do not store or use gasoline or other

 ammablevaporsorliquidsinthevicinity

of this or any other appliance.

2. An LP cylinder not connected for use shall

 notbestoredinthevicinityofthisorany

other appliance.

Location Requirements:

WARNING: ThisgrillisDesignCertiedforuseoutdoors

  onlyandisnotintendedforuseonrecreational

vehicles or boats.

The“InfraredElite”isdesignedtobeattachedtotheoptional

pedestal/cartorbepermanentlyinstalledonafree-standing

masonryorothersuitablepatioxture.

Minimumclearanceofamobilegrilltoanyadjacent

combustibleconstructioncanbefoundinTableA.

Table A.

Ifyouareinstallingyourgrillasabrick-inormasonrysupported

variation,itshouldbelocatedsotheventilationlouversremain

clearofallobstructions.Thelouversarelocatedinthefrontface

ofthegrillandattherearofthehood.Accumulationofdebrisin

thelouverscancausethegrilltooverheat.Thereshouldbeno

combustibleconstructionabovethegrillwithin6feet.

Theinstallationofyourgrillmustconformtolocalcodesor,in

theabsenceoflocalcodes,witheithertheNationalFuelGasCode,

ANSIZ223,1orCAN/CGA-B149.1,NaturalGasInstallationCodeor

CAN/CGA-B149.2,PropaneInstallationCode.

Combustible Non-Combustible

Construction Construction

Sides 12” 0”

Back 12” 0”

ASSEMBLY:

ToolsRequired:

Phillipsheadscrewdriver,adjustablewrench.

PEDESTAL/PORTABLECARTASSEMBLY:

1.Removegrillheadfromcartonandplaceonatsurface.

2.Removepedestal/cartfromcartonandsetuprightwith

 castersonground.

3.Openhoodongrillheadandremovewarmingrack,andcooking

 gridsandsetaside.

4.Carefullylifthoodassembly,bezelandinnerlineroffof

 grillbody.Seegure1.

5.Positiongrillbodyontopofpedestal/cartandfastenwith

 seven(7)¼-20x½”boltsforModelIandII,ten(10)for 

 ModelIIIwithlockingnuts.Seegure2.

6.Drippancannowbeinstalledintoposition.Seegure3.

SIDESHELFASSEMBLY:

1.Removesideshelffromcarton

2.Removethe4-¼”-20x½”boltsfromleftsideofgrill 

 body.

3.Aligntheholesinsideshelfwiththeholesinthegrillbodyand

 fastenwithfourboltsremovedearlier.

4.Ifsecondsideshelfisusedonrightsideofgrillattach

in same manner.

Figure1.

Figure2.

Boltsw/

Lockingnuts

FINALASSEMBLY:

1.Carefullylifthoodassembly,bezelandinnerlinerand

 positionbackongrillbody.

2.Placecookinggridsandwarmingrackinposition.

 Makesure“channel”portionofgridisfacingup.

Figure3.

DripPan

INFRARED ELITE I

(1 BURNER MODEL)

Note: Eight (8) side shelf screws will need to be removed.

We recommend the grill be on site prior to building in.

Build in (Brick in) Specifications:

For non combustible surround (brick, block, stone etc…)

Front View

Top View

Back View Side View

13”

22 5/16”

2”

3 1/4”

1 1/2” Hole for

back fed gas

22 5/16”

6” Hood Clearance

Splash

Guard

INFRARED ELITE II

(2 BURNER MODEL)

Note: Eight (8) side shelf screws will need to be removed.

We recommend the grill be on site prior to building in.

Build in (Brick in) Specifications:

For non combustible surround (brick, block, stone etc…)

Front View

Top View

Back View Side View

13”

30 1/4”

22 5/16”

2”

3 1/4”

1 1/2” Hole for

back fed gas

22 5/16”

6” Hood Clearance

Splash

Guard

INFRARED ELITE III

Note: Eight (8) side shelf screws will need to be removed.

We recommend the grill be on site prior to building in.

Build in (Brick in) Specifications:

For non combustible surround (brick, block, stone etc…)

Front View

Top View

Back View Side View

13”

41 7/16”

22 5/16”

2”

3 1/4”

1 1/2” Hole for

back fed gas

22 5/16”

6” Hood Clearance

Splash

Guard

GASREQUIREMENTS:

WARNING:WHENPURCHASEDFORUSEWITHLPGAS,THE

“INFRAREDELITE”GRILLCOMESWITHAREGULATORASSEMBLY

THATUSESAQUICK-CONNECTTYPECOUPLING.THISTYPECOUPLING

CANONLYBEUSEDWITHQUICK-CONNECTSTYLETANKVALVE.

WARNING:THEGASSUPPLYHOSESHOULDBEINSPECTEDPRIOR

TOEACHUSE.DONOTUSEAGASHOSETHATHASABRASIONS,CUTS

OREXCESSIVEWEAR.

WARNING:IFTHEOUTDOORCOOKINGGASAPPLIANCEISNOTIN

USE,THEGASMUSTBETURNEDOFFATTHESUPPLYCYLINDER.

STORAGEOFANOUTDOORCOOKINGGASAPPLIANCEINDOORS

ISPERMISSABLEONLYIFTHECYLINDERISDISCONNECTED

ANDREMOVEDFROMTHEOUTDOORCOOKINGGASAPPLIANCE.

CYLINDERSMUSTBESTOREDOUTDOORSOUTOFREACHOF

CHILDRENANDMUSTNOTBESTOREDINABUILDING,GARAGEOR

ANYOTHERENCLOSEDAREA.

The“InfraredElite”isofferedinoneoftwogascongurationsLPor

Naturalgas.LPmodelsincludepressureregulatorandhoseassembly.

Naturalgasmodelsrequireaseparateregulatorsuppliedwithgrill.LP

modelsrequireastandard20-lb.LPcylinderwithQC

(quickconnect)stylevalve.

PleaseNote:ThePressureregulatorandhoseassemblywiththeoutdoor

cookinggasappliancemustbeused.Replacementpressureregulators

andhoseassembliesmustbethosespeciedforthe“InfraredElite”.

GasSupplySpecications

 SUPPLY OPERATING MAINBURNER BURNER

GASTYPE PRESSURE PRESSURE ORIFICESIZE INPUT

Natural 14.0”WCMAX 4.0”WC #49 15,000BTU/HR

 5.0”WCMIN

LP 14.0”WCMAX 11”WC #57 15,000BTU/HR

 12.0”WCMIN

LPGasCylinderSafety:

NOTE:AnLPgascylinderisnotprovidedwiththisgrill.

OnlyD.O.T.approved20-lborCAN/CGA-B339approved

(cylinders,spheresandtubersforthetransportationof

dangerousgoods)LPgascylindersshouldbeused.

Allapprovedcylindersmusthaveanintegralcollardesigned

toprotectthecylindervalvefromdamage.Donotuseortry

torepairadamagedLPgascylinderatanytime.Contact

yourlocalLPgassupplierforreplacement.

q Donotllyourgascylinderbeyond¾full.

q Gascylinderscomewithapressurereliefvalve.Ifa 

 cylinderissubjectedtoexcessheat,the 

 reliefvalvewillopenandlethighlyammablegasvapor

 and/orliquidescape.Donotstoregascylindersnearan

 openameorsourceofheat.Storecylindersonlyinwell

 ventilatedareas.

InstallingyourLPgascylinder:

NOTE:Foryoursafety,onlyusetheregulatorandhose

assemblyprovidedasoriginalequipmentwithyourgrill.

NOTE:AreextinguisherforClassA,B,C&Dresshouldbe

readilyavailableatalltimes.

Gascylindershouldbesetuprightsocylindervalveisatthe

top.Thiswillensurepropervalvewithdrawal.

Connectingthecylinder:

1. Turnhandwheeloncylindervalveclockwisealltheway

to close.

2. Turnburnervalvestooffposition.

3. PlacetheLPcylinderbaseintotheholeinpedestal/cart

 oorandremoveprotectivecapontankvalve.

See gure 4.
