Gateway 23-inch LCD TV
Specifications
Specifications are subject to change without notice or obligation.
Display Panel
Screen size Diagonal 23-inch
Aspect ratio 16:9 wide
Number of pixels 1280 (Horizontal, RGB Trio) × 768 (Vertical) pixels
Pixel pitch 0.3915 × 0.3915 mm
Luminance 450 cd/m2, at APL13% typical
Contrast ratio 500:1 typical
Response time 16 ms typical
Colors 16.7 M colors / 8 bits
Viewing angle 85° Horizontal / 85° Vertical
Power Source
Input voltage 90 ~ 264 Vac, 47 Hz -63 Hz
Input current 1.5 A
Power consumption 130 Watts typical
Stand-by and Power Save 5 Watts max.
Video Formats (AV/S)
NTSC, PAL, SECAM
2
Gateway 23-inch LCD TV Specifications
www.gateway.com
Connector Types
14 RCA jacks for audio, video, and YPBPR(component)
2 6-pin Din S-terminal for S-Video
1 24-pin DVI/HDCP
1 15-pin D-SUB for RGB
1 F-terminal coax
Video Signal, S-Video
Type Analog
Polarity Positive
Amplitude Y: 1 Vp-p, C: 0.286 Vp-p
Input impedance 75 ohms
YPBPR Signal (Component)
Type Analog
Polarity Positive
Amplitude Y: 1 Vp-p, UV: 0.286 Vp-p
RGB Signal
Type Analog
Polarity Positive or Negative
Amplitude RGB: 0.7 Vp-p
Audio Signal
Analog 500 mV rms /more than 22 Kohm
3
Gateway 23-inch LCD TV Specifications
www.gateway.com
Pin Assignments for D-SUB Connector (In/Loop Out)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 RED 6 RED GND 11 GND
2 GREEN 7 GREEN GND 12 SDA
3 BLUE 8 BLUE GND 13 H-SYNC
4 GND 9 +5 V for DDC 14 V-SYNC
5 GND 10 GND 15 SCL
Pin Assignments for DVI-D Connector
Pin Signal Assignment Pin Signal Assignment
1 TMDS DATA 2 – 13 TMDS DATA 3 +
2TMDSDATA2+ 14+5V
3 TMDS DATA 2/4 SHIELD 15 GND
4 TMDS DATA 4 – 16 HOT PLUG DETECT
5 TMDS DATA 4 + 17 TMDS DATA 0 –
6 DDC CLOCK 18 TMDS DATA 0 +
7 DDC DATA 19 TMDS DATA 0/5 SHIELD
8NC 20TMDSDATA5–
9 TMDS DATA 1 – 21 TMDS DATA 5 +
10 TMDS DATA 1 + 22 TMDS CLOCK SHIELD
11 TMDS DATA 1/3 SHIELD 23 TMDS CLOCK –
12 TMDS DATA 3 – 24 TMDS CLOCK –
4
Gateway 23-inch LCD TV Specifications
www.gateway.com
RGB For VESA Standard
Mode
No.
Resolution Refresh
Rate
(Hz)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
V-Sync
Polarity
(TTL)
H-Sync
Polarity
(TTL)
1 720 × 400 70 31.47 70.0 + –
2 640 × 480 60 31.47 60.0 – –
3 640 × 480 72 37.86 72.0 – –
4 640 × 480 75 37.50 75.0 – –
5 640 × 480 85 43.4 85.0 – –
6 800 × 600 56 35.16 56.0 + –
7 800 × 600 60 37.88 60.0 + +
8 800 × 600 72 48.08 72.0 + +
9 800 × 600 75 46.88 75.0 + +
10 800 × 600 85 53.70 85.0 + +
11 1024 × 768 60 48.36 60.0 – –
12 1024 × 768 70 56.48 70.0 – –
13 1024 × 768 75 60.02 75.0 + +
14 1024 × 768 85 68.70 85.0 + +
RGB For Apple Standard
Mode
No.
Resolution Refresh
Rate
(Hz)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
V-Sync
Polarity
(TTL)
H-Sync
Polarit
y (TTL)
15 832 × 624 75 49.7 75.00 – –
16 1024 × 768 75 60.2 75.00 – –
YPBPRfor Component
Mode Resolution Refresh Rate
1 480i, 480p, 720p, 1080i 60
5
Gateway 23-inch LCD TV Specifications
www.gateway.com
Maximum Resolution
Up to 1280 × 768
Dimensions With/Stand
Width 29.53 in. (750 mm)
Height 16.89 in. (429 mm)
Depth 8.47 in. (215 mm)
Weight
Net weight 24.25 lbs (11.0 kgs)
Operating
Temperature 0~35°C (32~95°F)
Relative humidity 10~90%
Pressure 0~12,000 feet
Non-Operating
Temperature -20~60°C (-4~140°F)
Relative humidity 10~90%
Pressure 0~40,000 feet
Vibration 1.0 G / 2~200 Hz (sweep), 60 min. per axis
6
Gateway 23-inch LCD TV Specifications
www.gateway.com
Many products for Gateway and its subsidiaries are custom engineered by our
suppliers to Gateway specifications and may vary from similarly marketed
products.
Sound
2 Speakers 5 W
Reliability Requirement
The MTBF is 50,000 hours under operation at 25±5°C (Half luminosity, motion picture)
Emissions Requirement
Your LCD TV meets the EMI limits in all screen modes as qualified by FCC class B part 15.
MAN MON QTA 23” LCD TV SPEC R0 12/03
