Approach®S2
2
Approach®S2
Getting Started
WARNING
See the Important Safety and Product
Information guide in the product box for
product warnings and other important
information.
When using the device the rst time, complete
these tasks.
1Charge the device (page 1).
2Turn on the device (page 2).
3Start a round (page 4).
Charging the Device
WARNING
This device contains a lithium-ion battery. See
the Important Safety and Product Information
guide in the product box for product warnings
and other important information.
3
NOTICE
To prevent corrosion, thoroughly dry the
contacts and the surrounding area before
charging or connecting to a computer.
1 Plug the USB cable into a USB port on your
computer.
2 Align the charger posts with the contacts
on the back of the device, and press the
charger ➊ until it clicks.
3 Charge the device completely.
Turning on the Device
The rst time you use the device, you are
prompted to choose your language.
NOTE: The time of day and date are set
automatically when you are outdoors. You can
also set them manually (page 7).
1 Hold .
2 Select your language.
3 Play a game of golf (page 4).
4
Keys
➊Hold to turn the device on
and off.
Select to turn on the
backlight.
➋Select to scroll through
menus, holes, and settings.
➌Select to scroll through
menus, holes, and settings.
➍Hold to open the menu for
the current screen.
OK Select to choose menu
options and acknowledge
messages.
Icons
Battery is low.
Odometer is measuring dis-
tance and time (GPS active).
Alarm is on.
5
Playing Golf
Before you can play golf, you must wait until
the device acquires satellite signals, which
may take 30–60 seconds.
1 Hold .
2 Select Start Round.
3 Select a course from the list.
The device automatically starts on the hole
closest to your present location.
Hole View
The device shows the current hole you are
playing, and automatically transitions when
you move to a new hole.
NOTE: Because pin locations change, the
device calculates the distance to the front,
middle, and back of the green, but not the
actual pin location.
➊Current hole number.
➋Distance to the back of the green.
➌Distance to the middle of the green.
➍Distance to the front of the green.
➎Par for the hole.
Measuring a Shot
1 Hold .
6
2 Select Measure Shot.
3 Walk to your ball.
The distance automatically resets when you
move to the next hole.
Viewing Layup and Dogleg Distances
You can view a list of layup and dogleg
distances for par 4 and 5 holes.
From the hole view (page 4), select .
Layup ➊ and distance to reach the layup
➋appear on the screen.
NOTE: Distances are removed from the list
as you pass them.
Sunrise/Sunset
The sunrise/sunset information is to provide
you the reference of planning a golf play
and tempo to prevent yourself from dim
environment.
Select > Sunrise/Sunset to check the sunrise/
sunset information.
Pause Round
To pause the game, you can press the menu
for the Pause Round function to disable the
device (switch to watch mode) in order to save
battery.
Press Menu for Resume Round if you want to
continue the game.
7
1. When you are at the Hole View page, hold
the menu button to enter the page with
Pause Round function.
2. After you press the Pause Round button, it
will automatically switch back to the watch
mode.
3. To be back to the game, hold the menu
button to see the Resume Round button.
Continue Round
If nishing the rst nine hole, you can press
Continue Round to continue the rest of the
nine holes. The hole information will start from
10.
1. When you are at the ninth-hole, hold the
menu button to Start Scoring.
2. After you nish entering your record, hold
menu to show the Continue Round button,
press it to save your previous nine-hole
scorecard.
3. Hold menu button to Continue Round page,
after you press it will inform you to select a
course.
4. Then it will start from the tenth-hole.
Dual Green
Support Dual Green
Press Change Green to switch green.
1. Hold the menu button to change green if
you are at a course which has dual green.
2. The change will be shown on the upper left
side of the page.
8
Keeping Score
Before you begin keeping score, you must
start a round (page 4).
1 From the hole view (page 4), hold .
2 Select Start Scoring.
3 Select or to set the score.
Your total score ➊is updated.
Reviewing Scores
You can edit individual scores but not the total
score.
1 Hold .
2 Select Scorecard.
3 Select or to select the hole.
4 Select OK to edit.
Viewing Scorecards on a Computer
You can view all saved scorecards on your
computer.
1 Connect the device to a USB port on your
computer using the charging cradle.
2 The device appears as a removable drive in
My Computer on Windows® computers, and
as a mounted volume on Mac®computers.
3 Open ScorecardViewer.html to view your
scorecards.
9
Using the Odometer
You can use the odometer to record the
time and distance traveled. The odometer
automatically starts and stops when you start
or end a round, and you can also start and
stop it manually.
1 Hold or .
2 Select Odometer to view or start the
odometer.
3 Select an option:
• Select > Continue to keep using the
odometer.
• Select > Turn Off to stop the odometer.
• Select > Reset to reset the time and
distance.
Customizing Your Device
Settings
Hold , and select Setup.
Time: Sets the time to automatic or manual
(page 7).
Format: Sets the time format to 12- or 24-
hour.
Tones: Turns audible tones on or off.
Language: Sets the language.
Units: Sets to measure distance in yards or
meters.
Setting the Time Manually
By default, the time is set automatically when
the device acquires satellite signals.
1 Hold .
2 Select Setup > Time > Manual.
10
3 Select or to set the hour and minute.
4 Select AM or PM.
Setting the Alarm
1 Hold .
2 Select Alarm > Set.
3 Select or to set the hour and minute.
4 Select AM or PM.
5 Verify the alarm is set to On.
Viewing Device Information
You can view the software version and unit ID.
1 Hold .
2 Select About.
Appendix
Device Care
NOTICE
Avoid extreme shock and harsh treatment,
because it can degrade the life of the product.
Avoid pressing the keys under water.
Do not use a sharp object to clean the device.
Avoid chemical cleaners, solvents, and
insect repellents that can damage plastic
components and nishes.
Thoroughly rinse the device with fresh
water after exposure to chlorine, salt water,
sunscreen, cosmetics, alcohol, or other harsh
chemicals. Prolonged exposure to these
substances can damage the case.
Do not store the device where prolonged
exposure to extreme temperatures can occur,
because it can cause permanent damage.
