Garland EC0-E-20 Manual de usuario

FORM # ECO/ICO E-10 Electric Convection Ovens (Rev1)

ELECTRIC CONVECTION OVENS

Models: ECO-E10, EC0-E-20,

ICO-E10, ICO-E-20

Toll Free Phone, (US & Canada): (800) 427-6668

Toll Free Fax, (US & Canada): (800) 361-7745

http://www.garland-group.com

Page 2 FORM # ECO/ICO-E10 Electric Convection Ovens (Rev1)

Page 3FORM # ECO/ICO E-10 Electric Convection Ovens (Rev1)

ELECTRIC CONVECTION OVENS

Models: ECO-E10, EC0-E-20,

ICO-E10, ICO-E-20

Contents:

Control Panel Up to 7/25/94 ....................................................................................................... Page 4

Two Key Control Panel After 8/12/94 .......................................................................................... Page 6

Door Components ...................................................................................................................... Page 8

Oven Components .................................................................................................................... Page 10

Main Exterior ............................................................................................................................ Page 12

Revision History ........................................................................................................................ Page 17

Page 4 FORM # ECO/ICO-E10 Electric Convection Ovens (Rev1)

ICO/ECO

CONTROL PANELS

Up to 7/25/94

PS93-06 REV. 0

ELECTRONIC CONTROL

MANUAL CONTROL

Page 5FORM # ECO/ICO E-10 Electric Convection Ovens (Rev1)

GARLAND PARTS IDENTIFICATION

ECO/ICO Control Panels Electric

ITEM PART # DESCRIPTION QUANTITY DATE

ECO ICO FROM UP TO

Manual Controls

11657901 Control Panel 1 1 17 Nov. 92

1719801 Control Panel 1 1 17 Nov. 92

31657902 Overlay 1-Speed 1 1

1657904 Overlay 2-Speed 1 1

5 1006493 Pilot Light Green 1 1

6 1006498 Pilot Light Amber 1 1

71019203 Switch 1 - Speed 1 1

1019207 Switch 2 - Speed 1 1

8 1019209 Switch 1 1

9 1181000 Momentary Push Switch 1 1

10 1749201 Panel Bracket 1 1

11 1314001 Dial 2 2

1314121 Insert 2 2

13 1285701 1 Hour Timer 230V 1 1

1258601 12 Hour Timer 230V 1 1

14 1032400 Thermostat 1 1

* 9005400 Mercury Contactor 1 1

Electronic Control

1657799 2 Key & 8 Key Panel 1 1 17 Nov. 92

1657798 Cook’N Hold Panel 1 1 17 Nov. 92

1719899 2 Key & 8 Key Panel 1 1 17 Nov. 92 25 Jul. 94

1719898 Cook’N Hold Panel 1 1 17 Nov. 92 25 Jul. 94

1657702 Overlay 2 Key 1 Speed (Long Overlay) 1 1 Jun. 90 Aug. 94

1657704 Overlay 2 Key 2 Speed (Long Overlay) 1 1 Jun. 90 Aug. 94

1657706 Overlay 8 Key 1 Speed (Long Overlay) 1 1 Jun. 90

1657710 Overlay 8 Key 2 Speed (Long Overlay) 1 1 Jun. 90

1657710 Overlay Cook ‘N’ Hold (Long Overlay) 1 1 Jun. 90

1399000 2 Key Overlay (Short) 1 1 Jun. 90

1399100 8 Key Overlay (Short) 1 1 Jun. 90

1541600 12 Key Overlay 1 1 Jun. 90

5 1006498 Amber Pilot Light 28V 1 1

71019203 Switch - 1 Speed 1 1

1019207 Switch - 2 Speed 1 1

8 1019209 Switch 1 1

9 1018100 Momentary Push Switch 1 1

10 1749201 Panel Bracket 1 1

12 9007200 Knob 2 2

1517704 Controller 2 Key 1 1 Jul. 94

1517706 Controller 2 Key 1 1 Jul. 94

1544801 Controller Cook ‘N’ Hold 1 1

16 9006800 Temperature Probe 1 1

17 1516600 Key Lock 1 1

* 9005400 Mercury Contractor 1 1

* NOT ILLUSTRATED

RECOMMENDED STOCK PARTS

Page 6 FORM # ECO/ICO-E10 Electric Convection Ovens (Rev1)

ICO/ECO

TWO KEY CONTROL PANEL

AFTER 8/12/94

PS94-15 REV. 0

Page 7FORM # ECO/ICO E-10 Electric Convection Ovens (Rev1)

GARLAND PARTS IDENTIFICATION

ECO/ICO Two Key Control Panel

(After 8/12/94)

ITEM PART # DESCRIPTION QUANTITY

ECO ICO

1 1719897 Control Panel 1 1

2 1657712 Overlay - @ Speed 1 1

31270000 Amber Pilot Light (Gas) 1 1

1006498 Amber Pilot Light (Electric) 1 1

4 1019207 Rocker Switch - 3 Position 1 1

5 1019209 Rocker Switch - 3 Position 1 1

6 1720501 Knob 2 2

7 1749201 Panel Bracket 1 1

8 1181000 Momentary Push Switch 1 1

91517706 2 Bottom Controller - Gas 1 1

1517707 2 Bottom Controller - Electric 1 1

10 9006800 Prob 1 1

11 1771601 Relay - 120V - Gas 1 1

1771602 Relay - 240V - Electric 1 1

12 1269800 Transformer - Gas 1 1

13 1516300 Module - Propane Gas 1 1

1516301 Module - Natural Gas 1 1

14 1774702 Module Mounting Bracket 1 1

15 1774701 Module Mounting Plate 1 1

16 1671100 Polar Fan - 115V - Gas 1 1

1671101 Polar Fan - 230V - Electric 1 1

17 1774402 Cooling Fan Mounting Bracket 1 1

* 90020991 Thermistor 1 1

* NOT ILLUSTRATED

RECOMMENDED STOCK PARTS

Page 8 FORM # ECO/ICO-E10 Electric Convection Ovens (Rev1)

ICO/ECO

RIGHT AND LEFT DOOR COMPONENTS

PS93-02 REV 0

Page 9FORM # ECO/ICO E-10 Electric Convection Ovens (Rev1)

GARLAND PARTS IDENTIFICATION

ECO/ICO Control Panels Electric

ITEM PART # DESCRIPTION QUANTITY DATE

ECO ICO FROM UP TO

1029279 Left Door Assy With Window 1 1

1029277 Left Door Assy Solid (Opt.) 1 1

1029278 Right Door Assy Soild 1 1

1029276 Right Door Assy With Window (Opt.) 1 1

1 1016700 Oven Door Handle 1 1

2 1016702 Oven Door Handle End (Top) 1 1

3 1016701 Oven Door Handle End (Bottom) 1 1

4 1016703 Oven Door Spacer 2 2

51011605 Left Oven Door Panel (W/Window) 1 1

1011606 Left Oven Door Panel (Solid)

6 1011707 Handle Spacer Tubing 2 2

7 1021904 Door Catch (Mounted on Door) 1 1

8 1021902 Door Catch (Mounted on Frame) 1 1

9 1010999 Oven Door Window 1 1

10 1011895 Left Door Frame 1 1

11 1019701 Roller Pin 1 1

12 1302800 Upper Door Bearing Retainer 2 2

13 1010589 Hinge Bracket Assembly with Bearing 2 2

14 1011201 Steel Tubing Chrome Spacer 2 2

15 1011799 Left Door Liner Assembly With Window 1 1

1011798 Left Door Liner Assembly Solid 1 1

16 8004004 Allen Head Cap Screw 1/4 - 20 x 3-3/16 2 2

17 1011402 Right Door Panel Solid 1 1

1011403 Right Door Panel With Window

18 1011897 Right Door Frame Solid 1 1

1011896 Right Door Frame With Window 1 1

19 1011502 Right Door Liner Solid 1 1

1011599 Right Door Liner With Window

20 1014201 Left Door Rod (Short) 2 2

21 1014200 Right Door Rod (Long) 2 2

22 1021100 Roller Chain 2 2

23 1015000 Turnbuckle 2 2

24 1019600 Micro Switch 1 1

25 1533400 Micro Switch Cover (Insulation Paper) 1 1

26 1533800 Micro Switch Bracket 1 1

27 1581600 Top Door Seal 1 1

28 1581601 Slide Door Seals 2 2 17 Nov. 92

1581601 Left Side Seal Only 1 1 17 Nov. 92

29 1534500 Bottom Door Seal 1 1

30 1304201 Side Door Bracket 2 2 17 Nov. 92

1304201 Left Side Door Bracket Only 1 1 17 Nov. 92

31 1304202 Top Door Bracket 1 1

32 1719001 Right Door Seal 1 1 17 Nov. 92

* NOT ILLUSTRATED

RECOMMENDED STOCK PARTS

Page 10 FORM # ECO/ICO-E10 Electric Convection Ovens (Rev1)

ICO/ECO

OVEN COMPONENTS - ELECTRIC

PS93-09 REV 0
