Gardena 1490 Manual de usuario

GARDENA

DBetriebsanleitung

Bohrmaschinenpumpe

GB Operating Instructions

Drill Pump

FMode d’emploi

Mini-pompe

NL Instructies voor gebruik

Voorzetpomp

SBruksanvisning

Borrmaskinpump

IIstruzioni per l’uso

Pompa da trapano

EManual de instrucciones

Minibomba

PInstruções de utilização

Mini Bomba

Art. 1490

GARDENA

Drill Pump

1. Applications and Media to be Pumped

The GARDENA Drill Pump is designed for private

use in the house and garden. This includes draining

of small containers, such as aquariums, paddling

pools, defective washing machines, as well as

pumping fuel oil, and temporary aeration of small

garden pools.

AAcids, easy combustible or explosive

substances like petrol, kerosene, nitro,

or food must not be pumped. The temperature

of the liquid must not exceed 40 °C.

In case of doubt, please contact your GARDENA

GARDENA Service Department.

2. Use of Operating Instructions

Translation of the original instructions from German.

Read the operating instructions carefully.

AFor safety reasons, people who are not

familiar with the operating instructions

must not operate the pump.

Children under 16 years must not operate the

pump and have to be kept away from plugged-in

unit.

3. Operation and Maintenance

For intermittent or short time use a drill rated

450 Watt minimum is required. For runs of 30 minu-

tes or more a rating of 600 Watt is needed.

Fit the drive shaft (8 mm ∅) to the drill chuck.

AMake sure that the pump cannot twist,

wobble or tilt.

Connect suction and pressure hoses (using

GARDENA hose fittings). The direction of flow

is shown by the white arrows on the pump top.

Connect suction and pressure hoses (using

GARDENA hose fittings). The direction of flow

is shown by the white arrows on the pump top.

Check that the drill rotates clockwise, correspond-

ing with the direction shown by the arrows on the

pump side.

The suction hose should not be more than 3 m

(9 ft.) long. Please make certain that it is leak proof

when connected. The hose should be of non-

collapsing type (hose with woven reinforcement,

e.g. GARDENA Flex Hose or Cord Hose).

Place the suction hose inlet into fluid to be pumped.

Prime pump at max. drill speed. The outlet side

should be open during priming. Pump output can

be regulated by drill speed.

The pump is self-priming. If it does not start

pumping within 12 seconds, switch off at once

and locate the cause (probably a leaking, blocked or

collapsed inlet hose). The pump should not operate

against a closed outlet side for too long a period.

When liquid no longer flows switch off the

electric drill immediately.

After use, or after pumping of fuel oil, clean the

pump out thoroughly with clean water.

4. Technical data

Max. performance

with 13 mm (½”) hose 1.7 m3/h

(6.24g.p.m.)

with 19 mm (¾”) hose 2.4 m3/h

(8.81g.p.m.)

Max. pressure approx. 3 bar

(42 p.s.i.)

Max. pumping height approx. 30 m

(98.43 ft.)

Max.suction height approx. 3 m (9ft.)

Max. permissible r.p.m. 3,400 r.p.m.

Max. permissible temperature

of the liquid to be pumped 40 °C

Drive shaft ∅8 mm

Max. dry running time 12 seconds

We expressly point out that, in accordance with

the product liability law, we are not liable for any

damage caused by our units if it is due to impro-

per repair or if parts exchanged are not original

GARDENA parts or parts approved by us, and if

the repairs were not carried out by a GARDENA

Service Centre or an authorised electrician. The

same applies to spare parts and accessories.

EU Certificate of Conformity

The undersigned,

GARDENA Manufacturing GmbH

Hans-Lorenser-Str. 40

D-89079 Ulm

hereby certifies that, when leaving our factory, the

unit indicated below is in accordance with the har-

monised EU guidelines, EU standards of safety and

product specific standards.

This certificate becomes void if the unit is modified

without our approval.

Description of the unit: Drill Pump

Art. no.: 1494

EU directives: Machinery Directive

98/37/ EC : 1998

2006/42/EC : 2006

Year of CE marking: 1994

Ulm, 01.12.1998 Thomas Heinl

Technical Dept. Manager

Deutschland / Germany

GARDENA

Manufacturing GmbH

Service Center

Hans-Lorenser-Straße 40

D-89079 Ulm

Produktfragen:

(+49) 731 490-123

Reparaturen:

(+49) 731 490-290

service@gardena.com

Argentina

Argensem®S.A.

Calle Colonia Japonesa s/n

(1625) Loma Verde

Escobar, Buenos Aires

Phone: (+54) 34 88 49 40 40

info@argensem.com.ar

Australia

Nylex Consumer Products

50-70 Stanley Drive

Somerton, Victoria, 3062

Phone: (+61) 1800 658 276

spare.parts@nylex.com.au

Austria / Österreich

GARDENA

Österreich Ges.m.b.H.

Stettnerweg 11-15

2100 Korneuburg

Tel.: (+43) 22 62 7 45 45 36

kundendienst@gardena.at

Belgium

GARDENA Belgium NV/SA

Sterrebeekstraat 163

1930 Zaventem

Phone: (+32) 2 7 20 92 12

Mail: info@gardena.be

Brazil

Palash Comércio e

Importação Ltda.

Rua São João do Araguaia, 338

– Jardim Califórnia –

Barueri – SP - Brasil –

CEP 06409-060

Phone: (+55) 11 5181-0909

eduardo@palash.com.br

Bulgaria

Хускварна България ЕООД

1799 София

Бул. „Андрей Ляпчев” Nº72

Тел.: 02 / 8755148, 9753076

www.husqvarna.bg

Canada

GARDENA Canada Ltd.

100 Summerlea Road

Brampton, Ontario L6T 4X3

Phone: (+1) 905 792 93 30

info@gardenacanada.com

Chile

Antonio Martinic y Cia Ltda.

Cassillas 272

Centro de Cassillas

Santiago de Chile

Phone: (+56) 2 20 10 708

garfar_cl@yahoo.com

Costa Rica

Compania Exim

Euroiberoamericana S.A.

Los Colegios, Moravia,

200 metros al Sur del Colegio

Saint Francis - San José

Phone: (+506) 297-68 83

exim_euro@racsa.co.cr

Croatia

KLIS d.o.o.

Stanciceva 79

10419 Vukovina

Phone: (+385) 1 622 777 0

gardena@klis-trgovina.hr

Cyprus

FARMOKIPIKI LTD

P.O. Box 7098

74, Digeni Akrita Ave.

1641 Nicosia

Phone: (+357) 22 75 47 62

condam@spidernet.com.cy

Czech Republic

GARDENA spol. s r.o.

Tuшanka 115

627 00 Brno

Phone: (+ 420) 800 100 425

gardena@gardenabrno.cz

Denmark

GARDENA Norden AB

Salgsafdeling Danmark

Box 9003, S-200 39 Malmö

info@gardena.dk

Finland

Oy Husqvarna Ab

Lautatarhankatu 8b / PL 3

FI-00581 HELSINKI

France

GARDENA

PARIS NORD 2

69, rue de la Belle Etoile

BP 57080

ROISSY EN FRANCE

95948 ROISSY CDG CEDEX

Tél. (+33) 0826 101 455

service.consommateurs@

gardena.fr

Great Britain

Husqvarna UK Ltd

Preston Road

Aycliffe Industrial Park

Newton Aycliffe

County Durham

DL5 6UP

info.gardena@husqvarna.co.uk

Greece

Agrokip

Psomadopoulos S.A.

Ifaistou 33A

Industrial Area Koropi

194 00 Athens Greece

V.A.T. EL093474846

Phone: (+30) 210 66 20 225

service@agrokip.gr

www.agrokip.gr

Hungary

GARDENA

Magyarország Kft.

Késmárk utca 22

1158 Budapest

Phone: (+36) 80 20 40 33

gardena@gardena.hu

Iceland

Ó. Johnson & Kaaber

Tunguhalsi 1

110 Reykjavik

ooj@ojk.is

Ireland

Michael McLoughlin & Sons

Hardware Limited

Long Mile Road

Dublin 12

Italy

GARDENA Italia S.p.A.

Via Donizetti 22

20020 Lainate (Mi)

Phone: (+39) 02.93.94.79.1

info@gardenaitalia.it

Japan

KAKUICHI Co. Ltd.

Sumitomo Realty &

Development Kojimachi

BLDG., 8F

5-1 Nibanncyo, Chiyoda-ku

Tokyo 102-0084

Phone: (+81) 33 264 4721

m_ishihara@kaku-ichi.co.jp

Luxembourg

Magasins Jules Neuberg

39, rue Jacques Stas

Luxembourg-Gasperich 2549

Case Postale No. 12

Luxembourg 2010

Phone: (+352) 40 14 01

api@neuberg.lu

Netherlands

GARDENA Nederland B.V.

Postbus 50176

1305 AD ALMERE

Phone: (+31) 36 521 00 00

info@gardena.nl

Neth. Antilles

Jonka Enterprises N.V.

Sta. Rosa Weg 196

P.O. Box 8200

Curaçao

Phone: (+599) 9 767 66 55

pgm@jonka.com

New Zealand

NYLEX New Zealand Limited

Building 2

118 Savill Drive

Mangere, Auckland

Phone: (+64) 0800 22 00 88

spare.parts@nylex.com.au

Norway

GARDENA Norden AB

Salgskontor Norge

Kleverveien 6

1540 Vestby

info@gardena.no

Poland

GARDENA Polska Sp. z o.o.

Szymanów 9 d

05-532 Baniocha

Phone: (+48) 22 727 56 90

gardena@gardena.pl

Portugal

GARDENA Portugal Lda.

Sintra Business Park

Edifício 1, Fracção 0-G

2710-089 Sintra

Phone: (+351) 21 922 85 30

info@gardena.pt

Romania

MADEX INTERNATIONAL SRL

Soseaua Odaii 117-123,

Sector 1,

Bucureєti, RO 013603

Phone: (+ 40) 21 352 76 03

madex@ines.ro

Russia / Россия

ООО ГАРДЕНА РУС

123007, г. Москва

Хорошевское шоссе, д. 32А

Тел.: (+7) 495 540 99 57

info@gardena-rus.ru

Singapore

Hy - Ray PRIVATE LIMITED

40 Jalan Pemimpin

#02-08 Tat Ann Building

Singapore 577185

Phone: (+65) 6253 2277

hyray@singnet.com.sg

Slovak Republic

GARDENA Slovensko, s.r.o.

Panónska cesta 17

851 04 Bratislava

Phone: (+421) 263 453 722

info@gardena.sk

Slovenia

GARDENA d.o.o.

Brodiљиe 15

1236 Trzin

Phone: (+386) 1 580 93 32

servis@gardena.si

South Africa

GARDENA

South Africa (Pty.) Ltd.

P.O. Box 11534

Vorna Valley 1686

Phone: (+27) 11 315 02 23

sales@gardena.co.za

Spain

GARDENA IBÉRICA S.L.U.

C/ Basauri, nº 6

La Florida

28023 Madrid

Phone: (+34) 91 708 05 00

atencioncliente@gardena.es

Sweden

GARDENA Norden AB

Försäljningskontor Sverige

Box 9003

200 39 Malmö

info@gardena.se

Switzerland / Schweiz

GARDENA (Schweiz) AG

Bitziberg 1

8184 Bachenbülach

Phone: (+41) 848 800 464

info@gardena.ch

Turkey

GARDENA / Dost Diþ Ticaret

Mümessillik A.Þ. Sanayi

Çad. Adil Sokak No.1

Kartal - Ýstanbul

Phone: (+90) 216 38 93 939

info@gardena-dost.com.tr

Ukraine / Украина

ALTSEST JSC

4 Petropavlivska Street

Petropavlivska

Borschahivka Town

Kyivo Svyatoshyn Region

08130, Ukraine

Phone: (+380) 44 459 57 03

upyr@altsest.kiev.ua

USA

Melnor Inc.

3085 Shawnee Drive

Winchester, VA 22604

Phone: (+1) 540 722-9080

service_us@melnor.com

1490-20.960.08/ 0308

©GARDENA

Manufacturing GmbH

D-89070 Ulm

http://www.gardena.com

Otros manuales para 1490

Tabla de contenidos

Otros manuales de Bomba de agua de Gardena

Gardena

Gardena 11000 SL automatic Manual de usuario

Gardena

Gardena 9000/3 Manual de usuario

Gardena

Gardena 5500/3 Manual de usuario

Gardena

Gardena 8200 Manual de usuario

Gardena

Gardena 5500/5 inox Manual de usuario

Gardena

Gardena WP 600 7630 Manual de usuario

Gardena

Gardena 3000/4 Manual de usuario

Gardena

Gardena 3000/4 Manual de usuario

Gardena

Gardena 9000/3 Manual de usuario

Gardena

Gardena inox automatic 5900/4 Manual de usuario

Gardena

Gardena 5500/5 inox Manual de usuario

Gardena

Gardena WSP 7000 Manual de usuario

Gardena

Gardena 6000 Manual de usuario

Gardena

Gardena 3000/300 Jet Manual de usuario

Gardena

Gardena 1490 Manual de usuario

Gardena

Gardena 5900/4 inox Manual de usuario

Gardena

Gardena 7000 Manual de usuario

Gardena

Gardena 9000CLEAR Manual de usuario

Gardena

Gardena 3000/4 eco Manual de usuario

Gardena

Gardena CW Pump 2000/2 Li-18 Manual de usuario

Gardena

Gardena 4000/5 eco Manual de usuario

Gardena

Gardena 21000 inox Manual de usuario

Gardena

Gardena 5500/3 Manual de usuario

Gardena

Gardena 13000 aquasensor Manual de usuario

Manuales populares de Bomba de agua de otras marcas

Neptun

Neptun NPHW 5500 Manual de usuario

Sensidyne

Sensidyne Gilian BDX-II Instrucciones de instalación y funcionamiento

Draper

Draper 47808 Manual de usuario

Trolla

Trolla 12820 Manual de usuario

Sunfab

Sunfab SVH Series Manual de usuario

WilTec

WilTec 50740 Manual de usuario

Fieldmann

Fieldmann FVC 5015 EK Manual de usuario

Everbilt

Everbilt EFSUB5-122HD Manual de usuario

Graco

Graco Husky 3300e Manual de usuario

esotec

esotec 101018 Manual de usuario

moyno

moyno 2000 CC Manual de usuario

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manual de usuario

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guía de solución de problemas

DUROMAX

DUROMAX XP WX Series Manual de usuario

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manual de usuario

Franklin Electric

Franklin Electric IPS Manual de usuario

Xylem

Xylem e-1532 Series Manual de usuario

Milton Roy

Milton Roy PRIMEROYAL Manual de usuario
