20V Cordless Telescopic Chainsaw Instruction
Manual
For correct usage, please read these instructions carefully before use and keep in a
safe place for future reference.
After Sales Support
Call 0871 911 7031
Email
customerservice@gardengearonline.
co.uk
Product Code G4801
Thank you for purchasing this
product, which has been made to
demanding high quality standards
and is guaranteed for domestic
use against manufacturing faults
for a period of 12 months from
date of purchase

2
INTRODUCTION
Congratulations
You have made an excellent choice with the purchase of this quality Garden
Gear product.
By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest
standards, performance and safety.
We want you to be completely satisfied with your purchase, so this Garden
Gear product is backed by our full 12 month manufacturers guarantee
and an outstanding after sales service through our dedicated Helpline.
We hope you enjoy using your purchase for many years to come.

3
Contents
2. Introduction
3. Technical specifications
4. Safety information and general warnings
6. Safety symbols and their meanings
7. Description of parts
7. Assembly
11. Adjusting cutting length
11. Adjusting cutting angle
11. Adding lubricant
12. Operating the chainsaw
13. Sharpening the chain
14. Storage
14. Troubleshooting
14. Care and maintenance
15. Li-Ion battery care and maintenance
16. Declaration of conformity
17. Guarantee
Technical specifications
Battery voltage DC 20V
No-load speed 5.5m/s
Sawing length (max.) 180mm
Battery capacity
2.0Ah
Charging time 4 hours
A-weighted sound pressure level LpA 79.5 dB (A)
Uncertainty KpA 3 dB
A-weighted sound power level LwA 94.0 dB (A)
Uncertainty KwA 3 dB
Vibration ah1.79 m/s2
Uncertainty K 1.5 m/s2

4
Safety information and general warnings
•Remove all packaging and make sure that the product is intact. Do
not leave packaging materials like bags and staples within the reach
of children and pets.
•This appliance is approved solely for use in accordance with the
description and safety instructions specified in this user manual.
•Read through these instructions fully before using the product.
•Wear appropriate personal protective clothing during use, including
hearing protection, a dust mask and gloves.
•Wear solid, closed in shoes with a good grip when using the power tool.
•Do not use if any parts are damaged, always consult a qualified repair
person.
•Do not use in wet weather, wet areas or in areas where gases or other
flammable materials are stored.
•Not suitable for use in frozen or snowy conditions.
•Keep children and pets well away from the working area.
•Tie long hair back and remove any loose jewellery before use.
•Only use the power tool in a well-lit area.
•When not in use store in a cool dry area and out of reach of children.
•Keep the power tool in good clean condition.
•Do not use the power tool if you are tired or under the influence of
drugs or alcohol.
•If the blades strike a foreign object, turn it off immediately and check
for damage.
•If the power tool starts to vibrate abnormally, turn them off immediately
and check for the cause.
•Wear gloves and use caution when cleaning or performing
maintenance on the trimming shears.
•Do not put hands, feet or any body part or clothing near the blades
•The product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the product by a person responsible for their safety.
•Do not attempt to modify the product or use accessories. Any such
modification or misuse could result in a hazardous condition leading to
serious injury.
•If any parts are damaged or missing, do not operate until the parts are
replaced.
•Always carry the power tool by the handle.

5
•Do not over reach. Always keep a firm footing and maintain balance
during operation, always distribute the weight evenly on your body
and reduce the possibility of strain.
•Do not use the tool if the switch fails to turn it on and off. Any machine
that cannot be controlled with its switch is potentially dangerous and
must be checked by a qualified electrician and repaired if necessary.
•Recharge the battery only with the charger provided. A charger that is
suitable for one type of battery may create risk of fire when used with
another battery.
•The supplied battery charger is only suitable for charging the power
tool, it must not be used for charging any other product.
•Before each use, check the battery charger, cable and plug for signs
of damage. If the battery charger is damaged, do not use it or try to
repair it, always take it to your local qualified specialist.
•Make sure the power rating on the charger plug matches the outlet.
•Never modify the charger plug in any way.
•Do not use any adaptor plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce the risk of electric
shock.
•Never use the power cable for carrying, pulling or unplugging the
charger.
•Never expose the battery charger or plug to damp or wet
environments.
•When you are not using the trimming shears charger store in a safe dry
place.
•Never leave a battery unattended when charging.
•Not suitable for commercial purposes.

6
Safety symbols and their meanings
Read the instruction manual completely before using the power
tool.
Wear protective equipment such as ear defenders, a dust mask,
and gloves.
Wear solid, closed shoes with a good grip.
Warning! This symbol is displayed on the appliance to remind you
of the safety precautions you should take when operating the
machine.
Keep hands and feet away from the blades.
Do not use the power tool near overhead electric wires. Keep at
least 10 metres away.
Objects thrown by the tool could hit the user and other bystanders.
Ensure that other people ae pets remain at a safe distance from
the tool when it is in operation. Children must not come near the
tool when it is in use. Minimum distance 15 metres.
Do not expose to rain.
Only use the battery charger provided.
The product should not be disposed of with other household waste.
Follow the disposal instructions within this manual.
The manufacturer confirms that this power tool is in accordance
with applicable European directives.
The manufacturer confirms that this power tool is in
accordance with applicable UK directives.

7
Description of parts
1. Charger 14. Working head
2. Battery pack 15. Sprocket
3. Switch 16. Oil tank cover
4. Switch lock 17. Oil sealing plate
5. Strap connector 18. Chain bar cover
6. Strap position lock nut 19. Chain tightening ring
7. Fixed tube 20. Cover nut
8. Lock for telescopic tube 21. Chain tightener A
9. Lock for assembly 22. Saw chain
10. Middle casing 23. Chain tightener B
11. Release button 24. Chain bar
12. Rotating handle 25. Scabbard
13. Rotating function button
Assembly
WARNING! This product requires assembly. Carefully remove the
product and any accessories from the box. Make sure that all items listed in
the packing list are included.
Inspect the product carefully to make sure no breakage or damage
occurred during shipping.
Do not discard the packing material until you have carefully inspected and
satisfactorily operated the product.

8
WARNING! If any parts are damaged or missing, do not operate this
product until the parts are replaced. Failure to heed this warning could result
in serious personal injury.
WARNING! Do not attempt to modify this product or create
accessories not recommended for use with this product. Any such alteration
or modification is misuse and could result in a hazardous condition leading to
possible serious personal injury.
WARNING! Do not connect battery pack until assembly is complete.
Failure to comply could result in accidental starting and possible serious
personal injury.
Connecting the poles
1. Open the lock trigger for assembly and disassembly (9) and put the
rotating handle (12) into the connecting middle casing (10). There will
be audible click and you will see the release button which confirms it is
in place (11).
2. Close the lock trigger of assembly and disassemble (9). Don't forget to
check it and it ensure it is properly engaged.
WARNING! Failure to lock the power-head pole as directed above
could result in serious injury or death.

9
Assembling the chain bar and chain
Warning! The saw chain has very sharp edges, use thick protective
gloves for safety.
1. Loosen the cover nut (20), remove the SDS control system and chain
bar cover(18).
Please note that the oil sealing plate(17) must on the working head.
2. Position the chain bar(24) onto the working head.
3. Fit the saw chain (22) over the sprocket(15) and into the chain bar
groove. The cutters on the top of the chain bar should face toward the
chain bar tip, in the direction of the chain rotation. (Note: If the chain is
not properly fitted over on the sprocket, the chain saw will not work and
could cause serious injury).
4. Replace the chain bar cover(18) and install the SDS control system.
Tighten the cover nut(20) finger tight only. The cover nut(20) is used to
fasten the cover. The chain tightening piece A(21) is fixed to the cover
nut(20). The chain tightening piece A(21) must coordination to the
chain tightening piece B(23) which is on the chain bar(24), the chain
tightening ring is used to tightening the chain. The chain bar must be
free to move by chain tightening ring(19)
5. Adjust the chain tension by turning the chain tightening ring(19) until the

10
tie straps just touch the bottom of the chain bar rail. Turning clockwise
tightens the chain tension. Then check the chain for smooth rotation
and proper tension while moving it by hand (wear gloves). If necessary,
readjust the chain tightening ring (but loosen the bar cover first).
6. Hold the tip of the bar up and tighten the cover nut securely.
7. Chain is correctly tightened when there is no slack on the underside of
the bar, the chain is snug, but it can be turned by hand without binding.
During normal operation, the temperature of the chain will increase. The
drive links of a correctly tightened warm chain will hang
approximately .050 in. out of the bar groove.
NOTE: If chain is too tight, it will not rotate. Turn adjusting chain tightening ring
anticlockwise.
Assembling the shoulder strap
Always operate using the shoulder strap provided . Failure to do so could
result in loss of balance and result in personal injury
Place the shoulder strap so that it runs over the left shoulder, crossing the
chest and back.
Adjust the position of the securing clip loosening the strap position lock
nut(6) anticlockwise and sliding it into required position.
This unit is designed with a quick-release strap hook, pulling the bar-shaped
