Garage Smart MyLIFTER Instrucciones de funcionamiento

TOC

Installation and Operation Guide 3

About Garage Smart Basic Lifter 4

FCC Statement 5

Limited Lifetime Warranty 6

Installation Overview 8

What you need 8

Identify parts 8

Part 1: Install the Mounting Bracket 10

Part 2: Install the Power Adapter 14

Part 3: Install the Eyelet Screw 18

Part 4: Install the Hook and Pulley 20

Using the MyLifter App 24

Pair Your MyLifter With The App 24

Edit and Rename a Paired MyLifter 25

Raising and Lowering Items 26

Set the smart high and low points 27

Creating MyLifter Groups 28

To create a Locked Group: 28

To create a Flex Group: 31

- 1 -

Installation and Operation Guide

About Garage Smart Basic Lifter

The Garage Smart Basic MyLifter is a motorized hoist controlled by your smart device.

It allows you to safely lift your items off the garage floor to be stored on the ceiling. A

single MyLifter can lift up to 100 pounds when using the included pulley hook. Multiple

MyLifters can be connected to work as if they were one to raise, lower, and store items

weighing up to 400 pounds. The MyLifter app gives you control of your garage storage

with the touch of your finger.

SAFETY INFORMATION

lRead and follow all safety, installation, and operation instructions.

lDo not lift items while hands or other body parts are near the sys-

tem.

lDo not stand under the MyLifter or any items that have been lifted

by the system.

lDo not use the MyLifter to lift people or animals.

lDo not use the MyLifter to lift or lower items over people or animals.

lTotal lifting capacity for the MyLifter is 100 pounds.

lAlways balance load before lifting.

If your MyLifter cable is tangled, damaged, or bent, stop using your

MyLifter unit immediately.

WARNING

Failure to follow these safety instructions may result in property damage,

serious personal injury, or death.

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that

may cause undesired operation.

Warning: Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful inter-

ference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

lReorient or relocate the receiving antenna.

lIncrease the separation between the equipment and receiver.

lConnect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

lConsult the dealer or an experienced radio/TV technician for help.

RF WARNING STATEMENT: The device has been evaluated to meet general RF

exposure requirement. The device can be used in portable exposure condition without

restriction.

Limited Lifetime Warranty

Garage Smart offers a Limited Lifetime Warranty on all products. If a defect in the hard-

ware, or any component thereof, occurs Garage Smart will repair or replace the sys-

tem, or the defective component. There is no cost to you beyond the cost of shipping

the defective item to us. If your Garage Smart Product is defective, we will send

replacement parts or, at our option, replace it at no charge to you after the defective

product is returned to Garage Smart. If we send replacement parts for your Garage

Smart Product, we may use new or reconditioned parts. If we choose to replace your

Garage Smart Product, we may replace it with a new or reconditioned one of the same

or similar design.

Who Makes This Warranty?

Garage Smart

Who Is Covered?

This warranty extends only to the original purchaser of the product. This warranty is

intended for natural persons only and does not extend to any corporation, limited liab-

ility company, or commercial entity.

What Is Covered?

Any defect in material and workmanship from personal, normal household use in

accordance with the Owner’s Manual.

Warranty Does Not Cover: This warranty does not cover installation commercial use,

defects resulting from accidents, damage while in transit to our service location or dam-

age resulting from altercations misuses or abuse, lack of proper maintenance, unau-

thorized repair or modifications of the product, affixing of any attachment not provided

with the product, staples through wiring, pinched or broken wires, broken cables

power outages, use of extension cords, missing or damaged parts or discounted clear-

ance, final sale or taped cartons, fire, flood, acts of God, or failure to follow the

Owner’s Manual. This warranty is the only one we will give on your Garage Smart

Product. There are no other express warranties.

Where and How to Obtain Warranty Service

You can obtain warranty service from Garage Smart at the address indicated below. It

is your responsibility to deliver or ship the defective product to us at your date of pur-

chase and a description of the claimed defect, prior to the expiration of the warranty

period. To obtain information regarding this warranty, you may contact us by mail,

email, or phone.

Garage Smart

3000 Sierra Vista Way

Provo, UT 84606

Support@GarageSmart.com or (801) 649-4136

Exceptions and Exclusions

This warranty does not include damage or defects resulting from misuse, accident, fail-

ure to maintain, or any other causes following your purchased of the product. Use of

the Lifter system with any other system or components (including affixing non Garage

Smart attachments or accessories) voids this warranty. Failure to follow the owner’s

manual in installation or use of the Lifter system voids the warranty. Unauthorized

repair or modification voids the warranty.

The Lifter system is intended for personal, indoor, home use. Garage Smart does not

warrant its lift system for commercial use, and any such use voids the warranty.

TO THE GREATEST EXTENT PERMITTED BY LAW, THIS WARRANTY IS IN LIEU

OF AND EXCLUDES ALL OTHER WARRANTIES NOT EXPRESSLY SET FORTH

HEREIN, WHETHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO

ANY WARRANTIES OF MERCHANT ABILITY AND FINESS FOR A PARTICULAR

PURPOSE. Limitation of Liability: THE SOLE REMEDIES AFFORDED UNDER

THIS WARRANTYARE REPAIR, REPLACEMENT, OR, IF REPAIR OR

REPLACEMENT IS NOT COMMERCIALLY PRACTICABLE OR CANNOT BE

TIMELY MADE, A REFUND OF THE PURCHASE PRICE. IN NO EVENT SHALL

THE LIABILITY OF GARAGE SMART RELATED TO ANY PRODUCT EXCEED

THE PURCHASE PRICE OF THE PRODUCT. YOUR USE OF GARAGE SMART

PRODUCTS IS AT YOUR SOLE RISK. GARAGE SMART SHALL NOT BE LIABLE

UNDER ANY CIRCUMSTANCES FOR CONSEQUENTIAL, INDIRECT, SPECIAL,

OR INCIDENTAL 42 DAMAGES ARISING FROM OR IN CONNECTION WITH THE

USE OF ANY GARAGE SMART PRODUCT. (SOME STATES DO NOT ALLOW

THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL

DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO

YOU.)

Other Legal Rights

This warranty gives you specific legal rights and you may also have other rights which

vary from state to state.

Installation Overview

Installing the Basic Lifter is easy and involves the following basic steps:

1. Install the mounting bracket.

2. Install the power adapter.

3. Screw in the eyelet screw.

4. Attach the cable to the hook.

What you need

Installation requires the following tools:

lLadder

lStud finder

lTape measure

lPencil

lDrill

l1/2" wrench or socket wrench

lPhilips screwdriver

lSafety glasses

Identify parts

Inspect the box and make sure that you have all the parts shown in the image below:

If you are missing parts, contact Garage Smart for replacements (visit https://gar-

agesmart.com or call 833-234-8711, 6:00 am to 10 pm Mountain Time).

Part 1: Install the Mounting Bracket

Before you mount the bracket, determine the location in your garage where you would

like to store your item. Make sure there will be enough space between the walls and

where you mount the bracket so your item does not bump into anything on its way up

or down.

NOTICE

The mounting bracket needs to be installed in the center of a ceiling stud.

MyLifter units from Garage Smart are designed to be secured to flat ceil-

ings only. Do NOT attempt to secure lifters to angled ceilings or walls.

Do NOTinstall the mounting bracket in any manner other than specified

in these instructions.

1. Place the item you want to store on the floor in the area where you want to lift it.

2. Use your tape measure to measure the distance from the two nearest walls to

the center of the item you will be lifting.

3. Use your ladder to mark these same measurements on the garage ceiling. You

will use this mark as a reference point to find the nearest ceiling stud.

4. Use a stud finder to find the stud that is closest to reference point mark on the

ceiling.
