1. GENERAL INFORMATION
INTRODUCTION:
Congratulations, you have just purchased one of the most
innovative and reliable LED fixtures on the market today. Our company has been
designed to perform reliably for years when the guidelines in this booklet are
followed. Please read and understand the instructions in this manual carefully
and thoroughly before attempting to operate this unit. These instructions contain
important information regarding safety during use and maintenance.
UNPACKING:
Thank you for purchasing our company products. Every product
has been thoroughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your fixture for
damage and be sure all accessories necessary to operate the fixture have arrived
intact. In the event damage has been found or parts are missing, please contact
our customer support team for further instructions. Inside the box you should find:
the fixture, a DMX XLR cable, a power cable, and this user manual.
Please do not discard the shipping carton in the trash. Please recycle whenever
possible.
2. SAFETY INSTRUCTIONS
Notice: As part of our ongoing commitment to continuous
products update, company will keep the right to
improve this products, the information in this menu
may be changed in the future, the company reserve the
right to change the data without any advises.
www.g-lites.com 3
●1.In order to ensure the light could operate normally, the ambient temperature
couldn't be higher than 35ª and no lower than 2 ª.
●2.Under normal condition, the highest sectional surface temperature may be
up to 50°C.
●3.These projectors are designed depends on the electric shock protection, the
projector should be connected with the power supply system which
connected ground enough. The projector's ground cable should be
connected with the ground cable of the power supply system as well. The
ground mark of the light metal cover should be connecting with the
installation bricked steadily.
●4.Connecting the main power supply should be done by the professional
person.
●5.Please check the voltage, frequency data of power supply system is suitable
for the mentioned on the projector. Please do avoid the different voltage
between them and burn the projector.
●6.Do not attempt to operate this fixture if the power cord has become damaged
or frayed.
●7.Never open this fixture while in use.
●8.Never look directly into the light source. You risk injury to your retina, which
may induce blindness.
●9.Please be aware that damages caused by modifications to the device are not
subject to warranty.
Notice: To guarantee proper and consistent operation, it is
important to follow the guidelines in this manual. Our
company will not accept responsibility for damages
resulting from the misuse of this fixture due to the
disregard of the information printed in this manual.
www.g-lites.com 4
3. PERFORMANCE TRAIT AND SKILL SPECIFICATIONS
Lighting equipment is installed with 56pcs LED. We use EDISON LED
chip as default LED chip. Client also can choose LUXEON K2 high power
LED chip.
Low power consumption, super luminance, rich and splendid color.
It adopt the LCD display, as its operating in terrace, the words can also
be plus or reverse settled by 180°, very easy for using on the floor or
hang on.
With inner automatic run function, master/slave setting very easy to
operate by users.
The fixture's out shape adopt pressed construction design and strong
wind refrigeration system which be know as a good cooling system.
DMX channel: Two or three different DMX modes.
Standard DMX-512.
Color mixing: color additive mixing.
Dimmer: continuous dimming 0~100%.
Strobe: electronic strobe 0~18 fps.
LED life: 100,000 hours rated life.
LED power: 3W
Voltage: AC90-260V/50-60Hz
Power: 169W
LED QTY: R20 + G18 + B18
N.W.: 10.8 Kg.
G.W.: 11.9 Kg.
Carton size: 495 x 270 x 290 (mm)
Body size: 428 x 202 x 246 (mm)
IP rate: IP65
Lens angle: 45°
Choice lens angle: 60°
www.g-lites.com 5
4. OPERATION PANEL
5. DIMENSIONAL DRAWINGS
www.g-lites.com 6
6. PHOTOMETRIC DATA
PL5603CT：40° lens
7. MOUNTING AND INSTALLATION
Cautions: For added protection mount the fixtures in areas outside walking paths,
seating areas, and away from areas were unauthorized personnel might reach
the fixture. Before mounting the fixture to any surface, make sure that the
installation area can hold a minimum point load of 10 times the device's weight.
Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable. To avoid injury, never stand directly below
the device when mounting, removing, or servicing the fixture.
Mounting points: Overhead mounting requires extensive experience, including
amongst others calculating working load limits, a fine knowledge of the
installation material being used, and periodic safety inspection of all installation
material and the fixture. If you lack these qualifications, do not attempt the
installation yourself. Improper installation can result in bodily injury. Be sure to
complete all rigging and installation procedures before connecting the main
power cord to the appropriate wall outlet.
Mounting: Our company is fully operational in any mounting position, hanging
www.g-lites.com 7
upside-down, side mounted, or set on a flat level surface, etc. Be sure this fixture
is kept at least 0.5m (1.5 feet) away from any flammable materials (decoration
etc.).
When clamp mounting; always use and install the supplied safety cable as an
added safety measure to prevent accidental damage in the event of a clamp
failure. See the image below.
8. POWER SUPPLY AND SIGNAL CONNECTION
1. Power supply
Use the professional plug to connect the projector and main power supply.
Please pay attention to the voltage, frequency the same as the mentioned on the
projector. Suggest each light has separately switched of the power supply so that
could turn on or turn off each projector desultorily.
2. Signal connection
Please use the round 3-pin XLR plugs & sockets offered by menu facture to
connect the first projector's output to the second projector' input and connect the
second projector's output to the third projector's input. And in the same way for
the rest, eventually connect the last projector's output, all the projectors are
together as the following figure.
www.g-lites.com 8
The projectors’ control signal output or input by using the 3-pin XLR pug and
socket. If need to long then the communication cable, please make sure the both
side of 3-pin plug is one to one (one to one, two to two, three to three).
Otherwise, the communication cable will be interrupted. The communicate cable
is 2-pin shielded cable 75Ω
Resistance with each core is at least a 0.5mm diameter. (Caution: All the inside
leading wire of 3-pin XLR plug couldn't touch each other or plinth).
Recommend to use the DMX signal terminator for the installation to avoid the
electronic noise damage the digital control signal. Simply speaking, DMX
terminator is an XLR connector with a 120Ω/1w resistor connected across pin 2
and 3.Which is then plugged into the output socket on the last projector in the
chain. Refer to the connection as above: (Picture ). We suggest using the DMX
signal distributor when the distance of the lights over 15meter. In case of effect
the light communication because of the signal feeble.
3. Light power connection:
After doing the above operation and making sure all the projectors had been
installed with natural operate, press the power switch to check whether
everything is working normally.
www.g-lites.com 9
9. DISPLAY MENU
