ECHO SOUNDER

MODEL FE-700

9-52, Ashihara-cho,

Nishinomiya, Japan

Telephone: 0798-65-2111

Telefax: 0798-65-4200

Your Local Agent/Dealer

PUB. No. SME-23660-A

FE-700

(MAYA)

FIRST EDITION : APR 2000

Printed in Japan

A1-1

Addenda No.1 to FE-700 service manual, Pub. No. SME-23660

How to upgrade software

Necessary tools:

1) A DOS/V compatible PC (NEC PC98 cannot be used.)

2) OS: MS-DOS/Windows 95/98

3) Interconnection cables: 80-0654 and SAP-161-101

4) New Software

Fabricate the interconnection cable between the monitor unit and the PC as below.

FE-700 PC

DATA Port MJ6P (D-SUB,9pins)

4 >- - - - - - - - - ->1>- - - - - - - - - <2

5 >- - - - - - - - - ->2> <1

6 >- - - - - - - - - ->3>- - - - - - - - - <3

7 >- - - - - - - - - ->4>- - - - - - <4

>5> <6

10 >- - - - - - - - - - >6>- - - - - - - - - <5

----<7

----<8

Cable: SAP-161-101 Cable: 80-0654

1. New software supplied is a self-extracting file. Make a new file on the PC, copy a

file supplied, fe700vx.exe to the new file, then, double-click the fe700vx.exe icon.

Nine files are extracted.

Up700.bat, load600.b, load600.b96, uppg.exe, dummy.b, boot600.bin,

upboot60.bat, fe700t1.bin, update.txt

2. Copy these files to a floppy disk to execute the program from the floppy disk.

3. Connect the DATA port on the FE-700 display unit to the serial I/O port of the

PC.

4. Turn on the PC. Do not as yet turn on the FE-700.

5. Select MS-DOS prompt in the program file to run MS-DOS program.

C:¥windows> appears.

6. Insert the program disk and type A:, followed by Enter key.

A:¥> is on the screen.

7. Type up700 and press Enter key.

A1-2

8. Select baud rate “2:19200.”

“TARGET power on” comes on the PC screen.

9. Turn on the FE-700.

10. Wait for about 6 minutes.

The PC screen shows the progresses of updating. When loading of new

software is completed, “Finish version up.ted” appears on the PC screen while

the FE-700 shows normal picture.

11. Turn off the FE-700 and the PC to disconnect the cable.

2/2

C29

Figure 1 C29 on MAIN board (02P6280(A) with wrong polarity

Figure 2 C4 on CONE board (02P6283) with wrong polarity

CONTENTS

General

SYSTEM CONFIGURATION...............................................1

Chapter 1. Circuit Description

1.1 GENERAL BLOCK DIAGRAM ..................................2

1.2 FUNCTION OF EACH UNIT.......................................3

1.3 POWER SUPPLY..........................................................4

1.4 TRANSMISSION CIRCUIT.........................................7

1.5 RECEIVING CIRCUIT.................................................8

1.6 DISPLAY.......................................................................9

Chapter 2. Maintenance

2.1 ADJUSTMENT.............................................................12

2.2 REPLACEMENT OF LITHIUM BATTERY................12

Chapter 3. Troubleshooting

3.1 DIAGNOSTIC TEST ....................................................13

3.2 CLEARING THE MEMORY........................................15

3.3 ALARM AND ERROR MESSAGE.............................15

3.4 INSPECTION OF EACH BOARD...............................16

Chapter 4. Parts Location

4.1 DISPLAY UNIT ............................................................18

4.2 DISTRIBUTION BOX..................................................23

4.3 MATCHING BOX.........................................................24

4.4 SWITCH BOX...............................................................25

Chapter 5. Digital interface (IEC 61162-1)

5.1 I/O SENTENCES..........................................................26

5.2 SENTENCE DESCRIPTION........................................26

PARTS LIST........................................................................30

Exploded View..................................................................D-1

Electrical Parts List.......................................................E-1

Schematic Diagram.......................................................S-1

SYSTEM CONFIGURATION

The FE-700 consists of Display Unit ( FE701 ) , Distribution Box ( FE702 ), Transducer

Switching Box ( EX-8 ) and Matching Box ( MB-502/MB-504 ). The Switching Box and

Matching Box connected to switching box are supplied optionally.

TRANSDUCER

DISTRIBUTION

BOX

FE-702

DISPLAY UNIT

FE-701

JUNCTION BOX

JIS F8821-1

MATCHING BOX MB-502 (f r 50B-6B)

MB-504 (f r 200B-8B)

JB JB

IEC 61162-1

EIA-232C

IEC 61162-1 Navigation Device

Navigation Device

Personal Computer

IEC 61162-1

T ANSDUCE SWITCH BOX

EX-8

DIGITAL DEPTH INDICATO

FE-720

CONTACT CLOSU E BUZZE

: Standard Supply

Ship’s mains

100-115 VAC/200-230 VAC

24 VDC

: Optional Supply

General

1.1 GENERAL BLOCK DIAGRAM

Figure 1.1 General Block Diagram

Chapter 1. Circuit Description

Filter Switching Power Supply

+100 V

Transmitter

Receiver

Selector

TX0-M/TX1-N

ASIG

G IN

OPC

+12 V

+9 V

15 V

+5 V

GND

FREQ

D/ Converter

200 KHz

50 kHz

CPU

Gate rray

LCD

I/F

Inverter

+9 V

DR M

Flash ROM

RTC

SR M

Flash ROM

RS232C

LCD Unit

EDTCA14QCF

Photo Cupler

Panel Boar

PNL( 02P6250 )

MEM ( 02P6282 )

CONTRUST

M IN Board ( 02P6280 )

NLG Board ( 02P6281 )

DISTRIBUTION BOX

FE-702

DISPL Y UNIT FE701

TB2

TB4

CONE Boar

( 02P6283 )

Fuse Fuse

Fuse

TB6

TB5 J2

RS422

21 21

25 25

22 22

27 27

Ship’s Main

100/115/200/230 V C

Ship’s Main

24 VDC

M TCHING BOX

Transducer

Filter

1.2 FUNCTION OF EACH UNIT

Display Unit (FE-701 )

Board/Unit Functions

MAIN Board

(02P6280) 1) Processes depth signal by the CPU and the gate array, and converts them

into the video signal.

2) Receives panel signal.

3) Detects the depth.

4) Generates the "SHALLOW DEPTH ALARM".

5) Includes a LCD I/F and an inverter for LCD backlighting.

6) Communicates with external equipment in IEC61162-1 and RS232C data

format.

ANLG Board

(02P6281) Consists of a power circuit, a depth sounder circuit and an interface circuit.

PNL Board

(02P6250) Consists of keys, rotary switches, VRs, LEDs for panel illumination and a

buzzer.

MEM Board

(02P6282) 1) Memorizes the depth and time for 24 hours.

2) Contains a backup battery and a clock circuit.

Color Display

(EDTCA14QCF) Consists of an LCD and a cold cathode tube for LCD backlighting.

Distribution Box (FE-702 )

Board/Unit Functions

CONE Board 1) Interfaces the I/O signal between the Display Unit and External Unit.

2) Converts 100/115/200/230 VAC to 24 VDC for the Display Unit.

Matching Box (MB-502/MB-504 )

Matches impedance between transmitter/receiver and transducer.

Transducer Switching Box ( EX-8 )

Selects the transducer to be used.

1.2 FUNCTION OF EACH UNIT
