Fujitsu PRIMERGY TX100 S2 Manual de usuario

Operating Manual - English

PRIMERGY TX100 S2

Server

Operating Manual

March 2011

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

email: [email protected].

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any without the prior written permission of

Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

TX100 S2 Operating Manual

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the product

is used in a hot environment. The customer shall bear the cost of replacing

replaceable components which have exceeded their operating life. Note that

these are only guidelines, and do not constitute a guarantee of trouble-free

operation during the maintenance support period.

High safety use

This product has been designed and manufactured for general uses such as

general office use, personal use, domestic use and normal industrial use. It has

not been designed or manufactured for uses which demand an extremely high

level of safety and carry a direct and serious risk to life or body if such safety

cannot be ensured.

Operating Manual T X100 S2

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance control

in weapons systems (hereafter, "high safety use"). Customers should not use

this product for high safety use unless measures are in place for ensuring the

level of safety demanded of such use. Please consult the sales staff of Fujitsu if

intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market:

About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://primeserver.fujitsu.com/primergy/harddisk/

TX100 S2 Operating Manual

Only for the Japanese market:

IAlthough described in this manual, some sections do not apply to the

Japanese market. These options and routines include:

– USB Flash Module (UFM)

– Replacing the lithium battery

TX100 S2 Operating Manual

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Concept and target groups for this manual . . . . . . . . . . 9

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10

1.3 Performance features . . . . . . . . . . . . . . . . . . . . . 11

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 15

1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 15

2 Installation steps, overview . . . . . . . . . . . . . . . . . . 19

3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 21

3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 29

3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 29

3.4 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.5 Transporting the server . . . . . . . . . . . . . . . . . . . . 33

3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 34

4 Installing the hardware . . . . . . . . . . . . . . . . . . . . . 37

4.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 38

4.2 Setting up the server . . . . . . . . . . . . . . . . . . . . . . 39

4.3 Connecting devices to the server . . . . . . . . . . . . . . . 40

4.4 Connecting the server to the mains . . . . . . . . . . . . . . 42

4.5 Notes on connecting/disconnecting cables . . . . . . . . . 43

5 Installation and operation . . . . . . . . . . . . . . . . . . . 45

Operating Manual T X100 S2

Contents

5.1 Control and display elements . . . . . . . . . . . . . . . . . . 45

5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 45

5.1.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 46

5.1.1.2 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

5.2 Switching the server on and off . . . . . . . . . . . . . . . . 49

5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 51

5.3.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 51

5.3.2 Configuring the server and installing the operating system with the

ServerView Installation Manager . . . . . . . . . . . . . . . . . 52

5.3.3 Configuring the server and installing the operating system without the

ServerView Installation Manager . . . . . . . . . . . . . . . . . 53

5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 53

6 Property and data protection . . . . . . . . . . . . . . . . . . 55

6.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 55

7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 57

7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 57

7.2 Server switches off itself . . . . . . . . . . . . . . . . . . . . 58

7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 58

7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 59

7.5 No screen display or display drifts . . . . . . . . . . . . . . . 59

7.6 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 60

7.7 Hard disk drive error messages at system boot . . . . . . . . 60

7.8 Added drive reported as defective . . . . . . . . . . . . . . . 61

7.9 Error message on screen . . . . . . . . . . . . . . . . . . . . 61

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

TX100 S2 Operating Manual 9

1 Preface

The PRIMERGY TX100 S2 server is an Intel-based server for workgroups and

small networks. The server is suitable for use as a file server and also as an

application, information or Internet server.

Thanks to its highly developed hardware and software components, the

PRIMERGY TX100 S2 server offers a high level of data security and availability.

Security functions in the BIOS-Setup and on the system board protect the data

on the server against manipulation. The supported RAID levels allow the hard

disk controllers to offer error tolerance, through data redundancy, for users who

want to provide complete protection for valuable data.

Its low noise level and high energy efficiency make it ideal for office

environments.

1.1 Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server.

This operating manual is intended for those responsible for installing the

hardware and ensuring that the system runs smoothly. It contains all the

information you need to put your PRIMERGY TX100 S2 into operation.

To understand the various expansion options, you will need to be familiar with

the fields of hardware and data transmission and you will require a basic

knowledge of the underlying operating system.

The PRIMERGY TX100 S2 has a power management function

that reduces power consumption to <65 W in typical

configurations. The server thus satisfies the requirements of the

U.S. Environmental Protection Agency (EPA) - see section

"ENERGY STAR" on page 31.

10 Operating Manual T X100 S2

Preface

1.2 Documentation overview

More information on your PRIMERGY TX100 S2 can be found in the following

documents:

– "Quick Start Hardware - PRIMERGY TX100 S2" leaflet

"はじめにお読みください -PRIMERGY TX100 S2" for the Japanese market

(only included as a printed copy)

– "Quick Start Software - Quick Installation Guide" DVD booklet

(only included with the ServerView Suite as a printed copy) except for the

Japanese market

– "Safety notes and other important information" manual

"安全上の注意およびその他の重要情報 " for the Japanese market

– "Warranty" manual

"保証書 " for the Japanese market

– "Returning used devices" manual and "Service Desk" leaflet

"サポート＆サービス " for the Japanese market

– "PRIMERGY TX100 S2 Server Operating Manual"

– "PRIMERGY TX100 S2 Server Options Guide"

– "System Board D2779 for PRIMERGY TX100 S2 Technical Manual"

– “D2779 BIOS Setup Utility for PRIMERGY TX100 S2” manual

IPRIMERGY manuals are available in PDF format on the

ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the

ServerView Suite supplied with every server.

If you no longer have the ServerView Suite DVDs, you can obtain the

relevant current versions using the order number U15000-C289 (the

order number for the Japanese market: please refer to the configurator

of the server http://primeserver.fujitsu.com/primergy/system.html).

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL (for EMEA market):

http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can

be accessed using the Industry standard servers navigation option.

For the Japanese market please use the URL:

http://primeserver.fujitsu.com/primergy/manual.html.

Otros manuales para PRIMERGY TX100 S2

Tabla de contenidos

Otros manuales de Servidor de Fujitsu

Fujitsu

Fujitsu PRIMERGY RX300 S8 Manual de usuario

Fujitsu

Fujitsu Primergy CX270 S2 Manual de usuario

Fujitsu

Fujitsu SPARC M10-4 Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX150 S6 Manual de usuario

Fujitsu

Fujitsu ETERNUS CS800 S5 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M4000 Manual de servicio

Fujitsu

Fujitsu PRIMERGY 10/40GbE Connection Blade 18/8+2 Manual de lista de piezas

Fujitsu

Fujitsu Primergy CX250 S2 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX600 S4 Manual de usuario

Fujitsu

Fujitsu BS2000 SE700 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX600 S4 Manual de usuario

Fujitsu

Fujitsu PRIMERGY BX922 S2 Manual de usuario

Fujitsu

Fujitsu Primergy TX120 Manual de usuario

Fujitsu

Fujitsu SPARC ENTERPRISE T1000 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise T5140 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M8000 Manual de usuario

Fujitsu

Fujitsu PRIMERGY BX900 Manual de usuario

Fujitsu

Fujitsu PRIMERGY MX130 S2 Upgrade and maintenance... Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX1320 M1 Manual de usuario

Fujitsu

Fujitsu PRIMERGY SX650 Instrucciones de instalación

Fujitsu

Fujitsu PRIMERGY Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise T5140 Guía de instalación

Fujitsu

Fujitsu PRIMERGY RX200 S5 Manual de usuario

Fujitsu

Fujitsu Primepower200 Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
