FTP-624MCL303/304/FTP-624DSL113

■OVERVIEW

FTP-624MCL303/304 is a high speed, battery driven thermal

printer with a miniature cutter, printing on 2-inch wide paper

(58mm/60mm). A newly developed, long life, compact, light

weight cutter has been partnered with a FTP-624MCL

mechanism to produce this new product.

The design allows easy maintenance, head cleaning, head

replacement, and cutter replacement.

This printer is suitable for a variety of applications, such as

hand held POS terminals, measurement and medical

instruments.

A dedicated LSI (microcontroller) for driving the printer or an

interface board mounting this LSI is also available.

■HIGHLIGHTS

• Long life

Due to our proprietary cutter driving mechanism, the life of

the cutter is 300,000 cuts.

• High speed printing

It can print at 60 mm/s (480 dotlines) maximum by using

Fujitsu's unique head drive control.

• Paper auto loading function

Thermal paper can be loaded without head-up lever

operation.

• Two types of cut functions

Full and partial cut are possible.

• UL Recognized

File No. E171434

BATTERY DRIVE, MICRO LINE THERMAL PRINTER

2” TYPE MECHANISM AND INTERFACE BOARD

WITH MINIATURE CUTTER

FTP-624MCL303/304

FTP-624DSL113

FTP-624CU

FTP-624MCL303/304/FTP-624DSL113

■DESIGNATION

*1: 303 is for front paper insertion (curl path) and 304 is for rear paper insertion (straight path).

*2: Includes ANK+Kanji and Flash Memory.

Printer mechanism FTP-624MCL303/304*1

Interface board (Centronics /RS-232C) FTP624DSL113*2

LSI Micro Controller Unit FTP-624CU112

Thermal head cable FTP-624Y001

Parallel interface cable FTP-441Y201

Cables Serial interface cable FTP-624Y301

Power cables FTP-621Y401

FTP-621Y601

Part numberItem

Part number FTP-624MCL303/304

Printing method Thermal-sensitive line dot method

Dot structure 384 dots/line

Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density

Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch

Effective printing area 48 mm

Paper width (MCL303) 58 mm

Paper width (MCL304) 60 mm

Paper thickness 60 to 100 µm

Number of columns 32 columns/line (24 ×12 dot font)

480 dotlines/s (60 mm/s)

Conditions: 1 ply, printing on high sensitive thermal paper,

8 columns of “H” /line, double density 16 ×8 dot font,

room temperature, 8.5 VDC drive

JIS ANK : 128 International : 195

Character types ASCII : 31

JIS KANJI : approximately 6800

24 ×12 dots, (3.0 ×1.5 mm), 32 columns

16 ×8 dots, (2.0 ×1.0 mm), 48 columns

16 ×16 dots, (2.0 ×2.0 mm), 24 columns

24 ×24 dots, (3.0 ×3.0 mm), 16 columns

Interface Centronics / RS-232C (selectable by dip swtich)

■GENERAL SPECIFICATIONS

SpecificationsItem

Maximum printing speed

Character, dimensions (H×W), number of

characters

(Continued)

FTP-624MCL303/304/FTP-624DSL113

For head Voltage: 4.2-8.5 VDC

Peak current: approx. 2.6 A (conditions: room temp., 7.2 VDC, 64 dots on)

For motor Voltage: 4.2-8.5 VDC

Peak current: approx. 0.8 A (conditions: room temperature, 7.2 VDC)

For logic Voltage: 5.0 VDC ±5%

Current: 0.2 A maximum

For cutter Voltage: 5.0 VDC ±5%

Current: Approximately 5.0A (in-rush)

Approximately 1.0A (average)

Mechanism 97 (W) ×57 (D) ×38 (H) mm

Dimensions Interface board 131 (W) ×89 (D) ×24 (H) mm

Weight (Mechanism) Approximately 280 g

Mechanism Pulse durability: 1 ×108pulse/dot (using Fujitsu Takamisawa's standard

driving method)

Expected life Wear resistance: 50 km (at 25% print ratio)

Cutter 300,000 cuts minimum

Operating temperature 0 to +50°C*1

Operating humidity 20 to 85% RH (no condensation)

Storage temperature –20 to +60°C (excluding paper)

Storage humidity 5 to 95% RH (no condensation)

Head temperature By thermistor (applied energy control, abnormal temperature detection)

Detection Paper out/Mark detect By photointerrupter

Head-up By microswitch

For front insertion use (58 mm width) : FTP-020PU001, FTP-020P0104/

P0701

For rear insertion use (60 mm width) : FTP-020P0020, FTP-020P0105/

P0702

Recommended thermal sensitive paper In Europe (58 mm width) : FTP-021P0060-45

· Oji Paper : PD150R, PD160R-N, PD170R

· NIPPON Paper : TF50KS-E4,TF60KS-E,TF50KS-E

· MITSUBISHI Paper Mills : P220VBB-1, AFP-235

SpecificationsItem

(Continued)

Power

supply

Environmental

conditions

*1: Guarantee +5°C to +40°C.

FTP-624MCL303/304/FTP-624DSL113

■DIMENSIONS

Printer mechanism

Unit: mm

(Motor)

(Sensor)

FTP-624MCL303/304/FTP-624DSL113

Interface board

Unit: mm

17.0

1.6

5.0 23.6

120.7

105.4

86.4

69.9

56.7

15.233.0 71.1

105.4

120.7

130.8

5.1

5.1 5.1

5.1

CN3

CN9 CN10 CN6 CN5

CN11 CN1 CN2 CN4

5.1

CN8

39.4

78.7

88.9

5.1

Mounting height

4-ø3.6

FTP-624MCL303/304/FTP-624DSL113

■CONNECTOR PIN ASSIGNMENT FOR PRINTER MECHANISM

1. Thermal Head

Head side : B16B-PH-K-S-2.2 (J.S.T.) or equivalent

Board side : PHR-16 (J.S.T.) or equivalent

2. Motor connectors

Motor side : PHR-4 (J.S.T.) or equivalent

Board side : B4B-PH-K-S (J.S.T.) or equivalent

*1: Symbol: " " means a negative logic signal

1, 2, 3, ......................................15, 16

Motor Thermal head heat sink Head up level

Connector Pin No.

3. Sensor connectors

Sensor : PHR-5 (J.S.T.) or equivalent

Board side : B5B-PH-K-S (J.S.T.) or equivalent

FTP-624MCL303/304/FTP-624DSL113

■FUNCTION

metImetI

.1noitcnuftnirptseT.8noitcetedytilamronbarettuC

.2noitcetedtuorepaP.9noitcnufgnivasrewoprotoM

.3noitceteddneraenrepaP.01noitcnufnoitcetedkraM

.4noitcetedpudaeH.11noitcetedytilamronbanoitarepoUCM

.5 ytilamronbaerutarepmetdaehlamrehT

noitceted .21noitcetorpecneuqesFFO/NOrewoP

.6noitcetedesuftuo-wolB.31noitcetorptnerruc-revorotoM

.7noitcetedytilamronbaegatlovdaeH.41remiterawdraH

3. Cutter

Mech side : EHR-4 (J.S.T.) or equivalent

Board side : B4B-EH (J.S.T.) or equivalent
