Fujitsu Halcyon 9R2 Guía de instalación

Standard Features

Optional Wired Remote

pWeekly Timer

pFull Function Wired Remote

pChild Lock Capable

UTY-RNBYU

lWireless Remote Control

lSleep Timer

lCoil Dry Mode

lDry Mode

lAuto Louver: 4-Way

lAuto Mode

lQuiet Mode

Wall Mounted

9 and 12,000 BTU Systems

SYSTEMS 9R2, 12R2

Up to 14.3-SEER

lEconomy Mode

lAuto Restart/Reset

lAuto Changeover

lLow Ambient

lCold Prevention

lMinimum Heat

lBasic Third Party Interface*

Stylish, slim and elegant, these popular wall mounted

units are designed for single rooms. Indoor units have a

clean, aesthetic design and are small but mighty and

shorter in length than competing units, helping them blend

into any room. 13 and 14-SEER heat pump systems have

over a 30% increase in efficiency over conventional

10-SEER models and feature environmentally friendly

R410A refrigerant, both heating and cooling operation,

quiet mode and easy maintenance.

Function

Applications

This category of equipment is ideal for smaller spaces

where spot cooling or heating is required. Residential

applications including sunrooms and additions are made

easier with these 115 volt air conditioners and heat

pumps. Do you have a warm or cool spot in your home?

Our mini-splits can provide extra cooling or heating

capacity for those hard to cool areas. Commercially, their

small size makes them ideal for small offices, providing

individual temperature control.

FRONT & SIDES OF AOU9R2, AOU12R2

FRONT & SIDES OF ASU9R2, ASU12R2

Indoor

ASU9R2

Outdoor

AOU9R2

Indoor

ASU12R2

Outdoor

AOU12R2

FOR MORE INFORMATION:

Note: Figures are based on 115 Volts.

FUJITSU GENERAL AMERICA, INC.

353 Route 46 West •Fairfield, NJ 07004

Tel: (973) 575-0380 •Fax: (973) 836-0448

www.fujitsugeneral.com

Rev. 11/10

The Fujitsu logo is a registered trademark of Fujitsu Limited. The Halcyon logo and name is a

Fujitsu’s products are subject to continuous improvements. Fujitsu reserves the right to modify

product design, specifications and information without notice and without incurring any

obligations.

31-1/8

10-13/16

8-7/16

11-1/2

11-5/16

2-3/16

31-1/8

11/16

21-3/8

Easy Maintenance

Front panel is easily removed for cleaning.

9R2

Heat Pump

12R2

Heat Pump

9,700 12,300

9,600 12,800

8.2

14.3

8.2

13.7

11.8/13.9 11.5/12.9

32~115 (0~46)

17~75 (-8~24)

2.1 (1.0)

32~115 (0~46)

17~75 (-8~24)

3.2 (1.5)

115/60/1 115/60/1

15 20

324 (550) 383 (650)

271 (460) 324 (550)

241 (410) 265 (450)

200 (340) 206 (350)

40/38 45/42

36/34 40/37

31/29 34/32

26/25 29/27

640 770

43/45 (Clg/Htg) 45/46 (Clg/Htg)

7.6 9.9

6.5 9.2

0.82 1.07

0.69 0.99

4 + Auto 4 + Auto

Manual Manual

Automatic Automatic

Washable Washable

Flare Flare

49 (15) 49 (15)

26 (8) 26 (8)

Suc. 3/8 Dis. 1/4 Suc. 3/8 Dis. 1/4

21 (9.5) 71 (32) 21 (9.5) 79 (36)

10-13/16 21-3/8 10-13/16 21-3/8

275 540 275 540

31-1/8 31-1/8 31-1/8 31-1/8

790 790 790 790

8-1/2 11-1/2 8-1/2 11-1/2

215 290 215 290

R410A R410A

Nominal Cooling BTU/h

Nominal Heating BTU/h

HSPF BTU/hW

SEER BTU/hW

EER Clg/Htg

Clg. Operating Range °F(°C)

Htg. Operating Range °F(°C)

Moisture Removal Pt./h(l/h)

Voltage/Frequency/Phase

Recommended Fuse Size (A)

Air Circ. C.F.M. (m3/h): Hi

Medium

Low

Quiet

Noise Level dB(A): Hi

Medium

Low

Quiet

Outdoor Fan Speed RPM

Outdoor Noise Level dB(A)

Current (A): Cooling

Heating

Power Use (kw): Cooling

Heating

Fan Speeds Stage

Air Direction: Horizontal

Vertical

Air Filter

Connection Method

Combined Max. Lgth Ft (m)

Max. Vertical Diff. Ft (m)

Conn. Pipe Diameter Inch

Net Weight lbs. (kg)

Dimensions: Height Inch

Width Inch

Depth Inch

Refrigerant
