Fujitsu Siemens Computers PRIMERGY RX600 S3 Manual técnico

PRIMERGY RX600 S3

incl. SAS version

System configurator and order-information guide

Contents

Instructions

Configuration diagram

Configurator

00System software

1IBasic unit

2II Processor

3III Memory

4IV onboard SCSI / SAS Contr

5VUSB devices / optical devices

6VI Hard disk drives

7VII Tape Devices

8VIII optional SCSI / RAID controller

9IX Fibre Channel controller

10 XCommunication / Network

11 XI System Management Products (RemoteView)

12 XII National accessories pack

Change report

PRIMERGY Server

February 2007

System configurator and order-information guide

PRIMERGY RX600 S3 Status 2007-01-24

Instructions

This document contains basic product and configuration information that will enable you to configure your system via

PC-/System-Architect

Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete

PRIMERGY Rack system.

You can configure your individual PRIMERGY server in order to adjust your specific requirements.

The System configurator is divided into several chapters that are identical to the current price list and PC-/System-Architect.

Please follow the lines. If there is a junction, you can choose which way or component you would like to take. Go through

the configurator by following the lines from the top to the bottom.

Section III Memory, example

There are X memory slots which can be equipped with XXX MB

It is permissible to make up to X passes through the memory upgrade options

S26361-XXX-XXX S26361-XXX-XXX

Memory XXX MB Memory XXX MB

X times

max. X times per system max. X times per system

In one chapter you can only select as many components (here 4x) as the arrow indicates.

Please note that there are information symbols which indicate necessary information.

Further information in the internet see:

http://www.primergy.com

(internet)

http://extranet.fujitsu-siemens.com/primergy

(extranet)

Prices and availability see price list and PC-/System-Architect.

Subject to change and errors excepted.

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 2 of 17

System configurator and order-information guide

PRIMERGY RX600 S3 Status 2007-01-24

Configuration diagram PRIMERGY RX600 S3

TOP View

System unit ( I )

Extension slots

Memory ( III )

SCSI / RAID controller ( VIII )

Fiber Channel ( IX )

Communication/Network ( X )

Processors must be plugged

in order according the picture.

Processor ( II )

FRONT VIEW

Accessible drives

Tape drives ( VII )

Operating Panel

5.25"x 0.5" bay for CD/DVD

Local View LCD Display

Hard disk drives ( IV ) hot-plug

SCSI Version: 5x 3.5"SCSI

SAS Version: 8x 2.5" SAS

Channel A

Channel B

REAR VIEW

Hot Plug Redundant Power Supply

Key:

Included in basic unit

Option

2.5" SAS

Slot

PCI-Express x4 ( hot-plug )

Memory Board A

(2 Banks / 4 modules)

PCI-X 64-Bit / 100MHz, long

Memory Board B

(2 Banks / 4 modules)

Memory Board C

(2 Banks / 4 modules)

Memory Board D

(2 Banks / 4 modules)

PCI-Express x4 ( hot-plug )

occupied by PCIe RAID Controller in SAS Version

PCI-X 64-Bit / 100MHz, long

Xeon

MP 3

Xeon

MP 4

Xeon

MP 2

Xeon

MP 1

PCI-Express x4 ( hot-plug )

PCI-X 64-Bit / 133MHz, long ( hot-plug )

PCI-Express x8 ( hot-plug )

5.25"x1.6" Tape Drive USB Operating

Panel

USB

Video USB

3.5"x1" SCSI-ID 1

COM USB

Ethern

3.5"x1" SCSI-ID 0

3.5"x1" SCSI-ID 1

3.5"x1" SCSI-ID 2

3.5"x1" SCSI-ID 0

2. PSU

Video USB

Ethern

1. PSU

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 3 of 17

PRIMERGY-Software Configurators and Release Lists

Start "PRIMERGY RX600 S3"

PRIMERGY RX600 S3 Status 2007-01-24

SW - Configurator 32 bit

with OEM-Software without OEM-Software

for PRIMERGY Server Usage of OEM SW from MS is for PRIMERGY Server

not possible under VMware OEM-SW is bound to HW and

VMware-Software is not allowed to be ordered

- VCMS VirtualCenter Management Server separately.

- Virtual Infrastructure 3 Exception: VMware SW

For all SW products please refer to the corresponding software configurator accessible via

the Extranet under Configuration & Tools, -All configurations, -Software, URL see below.

MS - Software: W **) PRIMECLUSTER *)

- Windows Server 2003 R2, - Clustering

Standard Edition - Load Balancing

Enterprise Edition

- Additional loose

Client-Access-Licenses (CALs) Linux - Software: L **)

(not for Web Edition) - Open Enterprise Server ***)

- SuSE Linux ES (OEM): LO

- SuSE Linux ES (Support): LS

CITRIX-Software for - Red Hat EL (OEM): LO

Windows: W-MF - Red Hat EL (Support): LS

- Presentation Server

LoadBalancing

Additional User Licences

MultiPath, Duplex Data Manager (DDM)

W2K; W2K3 Linux (W-DDM)

Manageability Software: V Details eg. version numbers are published

- RemoteView Software in the separate SW-Configurator

- RemoteView Service Board

- vPMS 2006std

- Altiris Server Deployment *) Pay attention to the PRIMECLUSTER release and ordering information in the Extranet under

http://extranet.fujitsu-siemens.com/primecluster

Backup-Software /

Application-Software: U **) Pay attention to the release and ordering information in PRINCE -> Operating System

- ARCserve

http://vil.mch.fsc.net/vil/pc/vil/primergy/overview/prince/index_en.htm

- openSM2

Find detailed software configurators and release lists (OS-matrix / system management) under following addresses:

for internal users:

http://vil.mch.fsc.net/vil/oec/special/primergy/index_en.htm

for partners:

http://vilpart.fujitsu-siemens.de/vil/oec/special/primergy/index_en.htm

Continue with PRIMERGY

HW configurator

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 4 of 17

PRIMERGY-Software Configurators and Release Lists

Start "PRIMERGY RX600 S3"

PRIMERGY RX600 S3 Status 2007-01-24

SW Configurator EM64T

with OEM-Software without OEM-Software

for PRIMERGY Server Usage of OEM SW from MS is for PRIMERGY Server

not possible under VMware OEM-SW is bound to HW and

VMware-Software is not allowed to be ordered

- VCMS VirtualCenter Management Server separately.

- Virtual Infrastructure 3 Exception: VMware SW

For all SW products please refer to the corresponding

software configurator accessible via the Extranet under

"Configuration & Tools, -All configurations, -Software,

URL see below.

Microsoft - Software: W Linux - Software *) **)

only - Windows Server 2003 R2, only - SuSE Linux ES (OEM): LO

EM64T Standard x64 Edition x86_64 - SuSE Linux ES (Support): LS

Enterprise x64 Edition - Red Hat EL (OEM): LO

- Additional loose - Red Hat EL (Support): LS

Client-Access-Lizenzen (CALs)

CITRIX-Software for

only Windows: W-MF

EM64T

- Presentation Server

LoadBalancing

Additional User Licences

only MultiPath, Duplex Data Manager (DDM)

EM64T Windows, Linux (W-DDM)

Details eg. version numbers are published

Manageability Software: V**) in the separate SW-Configurator

only - RemoteView Software

EM64T - RemoteView Service Board

- RemoteView Diagnosis *) Pay attention to the PRIMECLUSTER release and ordering information in the Extranet under

- vPMS 2006std

http://extranet.fujitsu-siemens.com/primecluster

**) Pay attention to the release and ordering information in PRINCE -> Operating System

http://vil.mch.fsc.net/vil/pc/vil/primergy/overview/prince/index_en.htm

You'll find single software configurators and release lists (OS-matrix / system management / security) under following addresses:

for internal users:

http://vil.mch.fsc.net/vil/oec/special/primergy/index_en.htm

for partners:

http://vilpart.fujitsu-siemens.de/vil/oec/special/primergy/index_en.htm

Continue with PRIMERGY

HW configurator

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 5 of 17

System configurator and order-information guide

Start PRIMERGY RX600 S3

PRIMERGY RX600 S3 Status 2007-01-24

Section IBasic unit

PRIMERGY RX600 S3

SCSI

PRIMERGY RX600 S3

SAS

Rack unit 4U Rack unit 4U

SCSI

basic unit with:

SAS

basic unit with:

Basic Unit including:

- 2 hot-plug power supply (redundant)

- 3 + 2 bays for 1" HDD`s (two channels) - 8 bays for 2.5" SAS HDD`s - 2 hot-plug fan modules (redundant)

- LCD-Display for LocalView (Service Display)

PCI Slots

- 1 bay (0,5" height) for CD- or DVD-ROM

- 1x 64bit / 133MHz PCI-X slot (hot plug) - 1x 64bit / 133MHz PCI-X slot (hot plug) - 1x 5.25" bays FH (1,6" high) for accessible drives

- 2x 64bit / 100MHz PCI-X slot - 2x 64bit / 100MHz PCI-X slot - Rack- mounting kit

PCIe x4 slot (hot plug)

- 1x PCIe x8 slot (hot plug) - 1x PCIe x8 slot (hot plug) Systemboard with

- Intel E8501 chipset with 800MHz Frontside Bus

- onboard RAID 5 functionality - SAS RAID 5 Controller - 1x XEON MP dua core processor

with 256MB Cache (BBU optional) with 256MB Cache and BBU (2nd, 3rd and 4th as option)

- 1 memory board (2nd, 3rd and 4th as option)

- Ultra 320 SCSI-controller (LSI 53C1030)

- memory of basic units selectable via - memory of basic units selectable via - Dual LAN-Controller 1GBit on-board

base memory order codes base memory order codes WOL-capable (BroadCom 5704)

2.60GHz/4MB 7110M S26361-K988-V410 2.60GHz/4MB 7110M S26361-K988-V510 - VGA Controller on-board

3.00GHz/4MB 7120M S26361-K988-V420 3.00GHz/4MB 7120M S26361-K988-V520 (ATI Radeon 7000M, 16MB RAM)

3.20GHz/8MB 7130M S26361-K988-V430 3.20GHz/8MB 7130M S26361-K988-V530 - Server Management Controller on-board

3.40GHz/16MB 7140M S26361-K988-V440 3.40GHz/16MB 7140M S26361-K988-V540 (RSB 2 Board optional)

- ServerView Suite Software package

incl. ServerStart, ServerBooks,

Management Software and Updates

PRIMERGY PRIMECENTER- Rack - Interfaces:

Front side

3x USB 2.0

SNP:SY-F1647E301-P 1x VGA (15 pin)

Installation ex works for one "Rack-mounting ex factory"

server or subsystem. This service is to be ordered once Rear Side

Hereby the rack will be delivered per installable server/storage 2x USB 2.0

completely pre-mounted and subsystem, in order to get the 1x VGA (15 pin)

all wired connections are tested. server/storage subsystem 1x RS-232-C (serial, 9 pin)

With racks 12U, 24U, 38U: mounted into the PRIMERGY racks. 2x RJ45 (on board LAN)

Systems and components In case of the 46 U PRIMERGY rack, no PS/2 connection for KB / Mouse

will be delivered installed in the rack this service has to be ordered, (USB connectivity must be used instead)

With racks 46U: to get the mounting kits and the

Systems and components cables installed

will be delivered separately

To be ordered only together with

a PRIMERGY- Rack Mounting kit is part of the basic unit PRIMERGY RX600 S2

PRIMECENTER rack - 1 pair of telescopic rails (713 - 812mm)

e.g.: - 1 bracket DC-PC-Rack

S26361-K826-V10x - 1 cable management for DC-PC-racks

refer configurator DC-Rack This kit allows for mounting of TX/RX600 S3 in in FSC 19" DataCenter- and

max. 1x per System PRIMECENTER- racks and all server racks conforming to EIA standard EIA-310-D for 19" racks.

Therefore the mounting kit is variable in depth from 713 - 812mm

Installation in PRIMERGY 19" Classic rack is not possible.

Due to the heat dissipation of the system, sufficent cooling couldn´t be enabled in classic rack.

Connetion for KVM switch / Rack console

- RC23 can be directly connected (both USB and PS/2 connections)

- KVM S2 series needs the KVM S2 Adapter USB<->VGA

- For ES4/8+ KVM series with PS/2 connector as well as for standard PS/2 KB / Mouse

an additional USB to PS/2 adapter must be bought additionally and connected to the RX600 S3.

The adapter offers 2x PS/2 ports.

Adaper order number, to purchase via PRIMEPOWER, is:

D:GP70P-KA01 Adapter for PS/2<->USB

- Appropriate FSC USB keyboard is S26381-K340-V1*

This keyboard also needs USB cable T26139-Y3812-V1

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 6 of 17

System configurator and order-information guide

PRIMERGY RX600 S3 Status 2007-01-24

Section II Processor

A 4-way processor system requires a multi-processor operating system

Later upgrading to a four-way-processor system is also possible

VRM´s for 1st/2nd CPU are on the Motherboard, for the 3nd / 4th CPU addition VRM Modules are required.

Extension CPUs must have identical cache size and clock rate

2. CPU

S26361-F3124-E410 S26361-F3124-E420 S26361-F3124-E430 S26361-F3124-E440

Xeon MP 7110M

2.60GHz

Xeon MP 7120M

3.00GHz

Xeon MP 7130M

3.20GHz

Xeon MP 7140M

3.40GHz

800 MHz FSB 800 MHz FSB 800 MHz FSB 800 MHz FSB

with

4MB

TLC on Chip, with

4MB

TLC on Chip, with

8MB

TLC on Chip, with

16MB

TLC on Chip,

heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention"

occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU

max. 1x per system max. 1x per system max. 1x per system max. 1x per system

3./4. CPU

up to 3

upgrade

S26361-F3124-E800

CPU´s VRM module for 3rd/4th CPU

max. 1x per system

S26361-F3124-E410 S26361-F3124-E420 S26361-F3124-E430 S26361-F3124-E440

Xeon MP 7110M

2.60GHz

Xeon MP 7120M

3.00GHz

Xeon MP 7130M

3.20GHz

Xeon MP 7140M

3.40GHz

800 MHz FSB 800 MHz FSB 800 MHz FSB 800 MHz FSB

up to

with

4MB

TLC on Chip, with

4MB

TLC on Chip, with

8MB

TLC on Chip, with

16MB

TLC on Chip,

heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention" heat sink and "Easy retention"

occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU occupies socket for one CPU

max. 2x per VRM module max. 2x per VRM module max. 2x per VRM module max. 2x per VRM module

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 7 of 17

System configurator and order-information guide

PRIMERGY RX600 S3 Status 2007-01-24

Section III Memory

The system can be equipped with up 4 memory boards with 2 memory banks each.

One Memory Board is allready supplied in the base unit.

Each memory board can be equipped with up to 2x 8GB = 16GB memory.

The maximal extension is 64GB with 4GB modules!

No mix of modules within one memory bank is allowed.

For each basic unit, one pair of memory modules has to be ordered with the ordercode of "Base Memory"

(either 2GB = 2x1GB, 4GB = 2x2GB or 8GB = 2x4GB)

Note**: The price of the smallest Base Memory is already included in the basic unit,

The price of the other Base Memories is the Delta to the smallest Base Memory

Additional memory extensions (Upgrade Memory) can still be configured for the standard market price.

ECC with memory scrubbing function is standard for RX600 S3.

Optional hot-spare memory functionality can be configured in the BIOS (redundant memory bank n + 1)

RX600 S3 supports the memory protection through Memory Mirroring

Memory RAID.

Memory Mirroring requires 2 or 4 Memory boards, Memory RAID requires 4 Memory boards.

see Note** above

S26361-F3072-B622 S26361-F3072-B623 S26361-F3072-B624

Base memory 2 GB Base memory 4 GB Base memory 8 GB

DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC

with chipkill support with chipkill support with chipkill support

consisting of 2 modules consisting of 2 modules consisting of 2 modules

with 1 GB each with 2 GB each with 4 GB each

occupies one bank occupies one bank occupies one bank

1x per base system 1x per base system 1x per base system

S26361-F3072-E622 S26361-F3072-E623 S26361-F3072-E624

Upgrade memory 2 GB Upgrade memory 4 GB Upgrade memory 8 GB

DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC

with chipkill support with chipkill support with chipkill support

consisting of 2 modules consisting of 2 modules consisting of 2 modules

with 1 GB each with 2 GB each with 4 GB each

occupies one bank occupies one bank occupies one bank

max. 1x per base system max. 1x per base system max. 1x per base system

S26361-F3125-E130

Memory Board with 2 banks

for 2 modules each

max. 3x per system

up to 3x

memory

upgrade

S26361-F3072-E622 S26361-F3072-E623 S26361-F3072-E624

boards

Upgrade memory 2 GB Upgrade memory 4 GB Upgrade memory 8 GB

DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC DDR RAM PC2-3200 ECC

with chipkill support with chipkill support with chipkill support

consisting of 2 modules consisting of 2 modules consisting of 2 modules

with 1 GB each with 2 GB each with 4 GB each

occupies one bank occupies one bank occupies one bank

max. 2x per memory board max. 2x per memory board max. 2x per memory board

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 8 of 17

System configurator and order-information guide

PRIMERGY RX600 S3 SAS Status 2006-12-31

Section IV on-board SCSI / SAS Controller

SCSI Base Units

The system is equipped with a two channel Utra 320 onboard SCSI controller

including a full featured RAID controller with 256MB Cache (suporting the RAID level 0, 1, 5, 10, 50).

As option the on-board RAID Controller can be equipped with a Battery Backup Unit.

This on-board SCSI/RAID controller can be used for the connection of internal tapes and disks drives.

Also one channel can be used for the connection of external Tape devices in the SX10 subsystem.

The following rules apply for the cabling:

The cables for the connection of the on-board RAID controller to the disks in the system are includes in the base unit.

If an internal tape is configured, an additional SCSI cable is needed. (see section "IV Hard disk drives / Tapes" )

For the connection of external Tape devices to the on board SCSI controller, also an additional cable is needed in the system.

(plus cable to connect to the subsystem SX10, see configurator SX10)

S26361-F3128-E20

ROM Battery Backup Unit

for on-board RAID controller

max. 1x per system

Overview SCSI-cabling of a PRIMERGY RX600 S3 SCSI Base Unit

Picture 1: Picture 2: Picture 3:

Two channels for Disks Two ch. for Disks + int. Tape One ch. for Disks + ext. Tape

1x3

onboard

HDD

onboard

HDD

onboard

HDD

SCSI / RAID SCSI / RAID SCSI / RAID

1x2

internal external

HDD

Tape Devices

optional optional optional

internal

Tape Devices

29160 Contr. 29160 Contr. external 29160 Contr. external

Tape Devices Tape Devices

29160 Contr. external 29160 Contr. external 29160 Contr. external

Tape Devices Tape Devices Tape Devices

Configuration with 2 channels for Disk Drives Picture 1

Both channels of the on-board SCSI/RAID-controller are used for SCSI disk drives (pls see pictures above).

For the connetion of internal tape devices an additonal SCSI controller is required, pls see section V SCSI-RAID controller

Configuration with 2 channels for Disk Drives plus internal Tape device Picture 2

One channel of the on-board SCSI/RAID-controller is used for SCSI HDD (pls see pictures above).

The secound channel can be used to connect additional SCSI HDD and /or an internal tape device.

Configuration with 1 channels for Disk Drives plus external Tape device

Picture 3

One channel of the on-board SCSI/RAID-controller is used for SCSI disk drives (pls see pictures above).

The secound channel can be used to connect external Tape drives.

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 9 of 17

System configurator and order-information guide

PRIMERGY RX600 S3 Status 2007-01-24

SAS Base Units

AB. on-board SCSI-/ SAS RAID-Controller for accessible drives and SAS HDD´s -> SAS Version

The system will be delivered with a 8-port SAS RAID controller for the connection of SAS HDD´s

This SAS RAID Controller is equipped with 256MB Cache and BBU (suporting the RAID level 0, 1, 5, 10, 50),

and can be used only for the connection of internal disks drives.

Additonally the system is equipped with a two channel Utra 320 onboard SCSI controller

This on-board SCSI controller can be used for the connection of internal or external tape devices.

The following rules apply for the cabling:

The cables for the connection of the SAS RAID controller to the disks in the system are includes in the base unit.

If an internal tape is configured, an additional SCSI cable is needed. (see section "IV Hard disk drives / Tapes" )

For the connection of external Tape devices to the on board SCSI controller, also an additional cable is needed in the system.

(plus cable to connect to the subsystem SX10, see configurator SX10)

Overview SAS / SCSI-cabling of a PRIMERGY RX600 S3 SAS Base Unit

Eight SAS ports for Disks Two SCSI ports for int./ext. Tape

internal

integrated

8x internal

onboard

Tape Devices

SAS RAID

2.5" SAS HDD

SCSI contr.

controller external

Tape Devices

optional internal

29160 Contr. Tape Devices

29160 Contr. external

Tape Devices

external SCSI Interface

S26361-F3128-E102

external SCSI interface

plug:

1x VHDCI / UHD68(S)

max. 1x per system

Fujitsu Siemens Computers Enterprise Products PRIMERGY Server 10 of 17

Tabla de contenidos

Otros manuales de Servidor de Fujitsu Siemens Computers

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy BX620 S2 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY TX150 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENIC C Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy TX200 S3 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY R450 Guía del usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY TX120 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy Econel 100 Series Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy RX200 S2 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY Econel 200 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY ECONEL 10 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy RX220 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY RX100 S4 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SPARC Enterprise M5000 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY B120 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY TX150 S3 Manual del propietario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY Econel 50 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy TX200 S3 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY econel 20 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY TX200 S4 Manual del propietario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Primergy RX220 Manual del propietario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY RX300 S3 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SPARC Enterprise M8000 Manual de servicio

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY TX120 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers PRIMERGY TX120 Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
