Fujitsu Siemens Computers L22W-6SA Manual de usuario

edition 1 English

Contents

Introduction........................................................................................................................................... 1

Additional information................................................................................................................... 1

Important notes..................................................................................................................................... 2

Safety notes.................................................................................................................................. 2

Power cable.................................................................................................................................. 3

Transport...................................................................................................................................... 3

Cleaning ....................................................................................................................................... 4

CE marking................................................................................................................................... 4

Checking the contents of the consignment........................................................................................... 4

Connecting the monitor ........................................................................................................................5

Operation of the monitor....................................................................................................................... 6

Troubleshooting.................................................................................................................................... 7

Assembling the monitor base............................................................................................................... 9

Downloaded from ManualMonitor.com Manuals

edition 1 English - 1

Introduction

This manual contains important information for correct set-up of your LCD monitor.

A screen controller with VGA interface is required to control the LCD monitor. The monitor processes

the data supplied to it by the screen controller. The screen controller/the associated driver software is

responsible for setting the modes (resolution and refresh rate).

When putting the monitor into operation for the first time, the screen display should be optimally

adapted to the screen controller used and adjusted in accordance with your needs.

Target group

You don't need to be an "expert" to perform the operations described here. However, please observe

the safety information given in the operating instructions of the computer and in this manual!

In the event of any problems occurring, please contact your sales outlet or our help desk.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

Pay particular attention to text marked with this symbol. Failure to observe this warning

endangers your life, destroys the device, or may lead to loss of data.

Supplementary information, remarks, and tips follow this symbol.

►Text which follows this symbol describes activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters or terms.

This font indicates filenames and menu items.

This font indicates screen outputs.

Additional information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

Downloaded from ManualMonitor.com Manuals

LCD monitor

2 - English edition 1

Important notes

In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety notes

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our help desk.

●The display surface of the LCD monitor is sensitive to pressure and scratches. You should

therefore be careful with the display surface so as to avoid lasting damage (Newton rings,

scratches).

●If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

●To ensure sufficient ventilation, the intake and exhaust air openings of the monitor must never

be blocked.

●The monitor automatically sets itself to a mains voltage in the range of 100 V to 240 V. Ensure

that the local mains voltage lies within these limits.

●Ensure that the power socket on the device or the grounded mains outlet is freely accessible.

●The ON/OFF switch does not disconnect the device from the mains voltage. To completely

disconnect the mains voltage, remove the power plug from the socket.

●The monitor is equipped with a power cable that complies with safety standards.

●Lay all cables so that nobody can stand on them or trip over them. When attaching the device,

observe the relevant notes in the "Connecting the monitor" chapter.

●If you use a different data cable from the one supplied, ensure that it is adequately shielded.

CE conformance and optimum picture quality are guaranteed only if you use the data cable

supplied.

●No data transfer cables should be connected or disconnected during a thunderstorm.

●Make sure that no objects (e.g. jewellery chains, paper clips, etc.) or liquids get inside the

device (danger of electric shock, short circuit).

●The device is not waterproof! Never immerse the device in water and protect it from spray

water (rain, sea water).

●In emergencies (e.g. damaged casing, elements or cables, penetration of liquids or foreign

matter), switch off the unit, disconnect the power plug and contact your sales outlet or our help

desk.

Downloaded from ManualMonitor.com Manuals

LCD monitor

edition 1 English - 3

●The monitor must be disposed of in accordance with the local regulations for disposal of

special waste. The screen background lighting contains mercury. You must observe the

applicable handling and disposal safety regulations for fluorescent tubes.

●Only qualified technicians should repair the device. Unauthorised opening and incorrect repair

may greatly endanger the user (electric shock, fire risk).

●Use a screen saver with moving images and activate the power management for your monitor

to prevent still images from "burning in".

●The screen may only be operated in the wide format (0°landscape mode). Turning with a

swivel arm or wall bracket mounted is not permitted.

●Store this manual close to the device. If you pass the device on to third parties, you should

pass this manual on with it.

Power cable

To guarantee safe operation, use the cable supplied. Use the following guidelines if it is necessary to

replace the original cable set.

●The female/male receptacles of the cord set must meet IEC60320/CEE-22 requirements.

●The cable has to be HAR-certified or VDE-certified. The mark HAR or VDE will appear on the

outer sheath.

●For devices which are mounted on a desk or table, type SVT or SJT cable sets may be used.

●The cable set must be selected according to the rated current for your device.

●If necessary, replace the original power cable with a regular grounded 3-core mains lead.

Transport

●Transport the monitor with care and only in its original packaging or another corresponding

packaging fit to protect it against knocks and jolts.

●Never drop the LCD monitor (danger of glass breakage).

Downloaded from ManualMonitor.com Manuals

LCD monitor

4 - English edition 1

Cleaning

●Always pull out the power plug before you clean the monitor.

●Do not clean any interior parts yourself, leave this job to a service technician.

●Do not use any cleaning agents that contain abrasives or may corrode plastic.

●Ensure that no liquid will run into the system.

●Ensure that the ventilation areas of the monitor are free.

●The display surface of the LCD monitor is sensitive to pressure and scratches. Clean it only

using a soft, slightly moistened cloth.

Wipe the monitor casing with a dry cloth. If the monitor is particularly dirty, use a cloth which has

been moistened in mild domestic detergent and then carefully wrung out.

CE marking

The shipped version of this device complies with the requirements of the EEC directives

89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage directive".

Checking the contents of the consignment

The display surface of the LCD monitor is sensitive to pressure and scratches. Always hold

the device by the casing!

►Unpack all the individual parts.

►Check the delivery for damage incurred during transportation.

►Check whether the delivery agrees with the details in the delivery note.

The complete LCD monitor package includes:

– one monitor

– data cable

– one power cable

– one Warranty Booklet

– this "Getting Started" manual

Should you discover that the delivery does not correspond to the delivery note, notify your local sales

outlet immediately.

We recommend that you keep the original packaging material. You may need the

packaging in the future if you need to transport your device.

Downloaded from ManualMonitor.com Manuals

LCD monitor

edition 1 English - 5

Connecting the monitor

Please take note of the safety information in the "Important notes" chapter.

CE conformance and optimum picture quality are guaranteed only if you use the data cable

supplied.

Do not cover the ventilation openings of the monitor.

The computer power plug must be pulled out!

►Be sure that the monitor and the computer are switched off.

Connecting cables to the monitor

1 = Security slot for "Kensington Lock"

2 = Power connector

3 = DVI-D connector (option)

4 = D-SUB connector (ANALOG)

5 = LINE-IN connector

►If the data cable is not firmly connected to the monitor:

Connect one of the connectors of the data cable to the D-SUB connector on the monitor and

secure the plug-in connection by tightening the locking screws.

►Plug the power cable supplied into the power connector of the monitor.

Connecting cables to the computer

Information on the computer connections and interfaces is contained in the operating manual for your

computer.

If your computer has two monitor ports ("onboard" screen controller and separate

graphics card), the monitor port for the separate graphics card is usually active.

►Connect the data cable to the (active) monitor port on the computer and secure the plug-in

connection by tightening the safety screws.

►Connect the connector of the power cable supplied into a properly earthed mains outlet and

ensure a secure connection.

Downloaded from ManualMonitor.com Manuals

LCD monitor

6 - English edition 1

►Plug the power connector of the computer into a properly grounded mains outlet.

When you start working with your monitor for the first time you should install the

appropriate graphics drivers for your application software. Details of how to do this are

provided in the documentation on your screen controller/the associated driver software.

Operation of the monitor

Adjusting rake

The rake of the monitor can be adjusted forward and back from its vertical position.

►Grasp the monitor with both hands on the right and left edge of the casing and adjust it to the

desired rake.

Switching the monitor on/off

1 = Buttons for the OSD menu

(On-Screen-display)

2 = Power indicator

3 = ON/OFF switch

The ON/OFF switch is used for switching the monitor on and off.

The power indicator glows green or blue when the monitor and computer are switched on. The power

indicator lights up yellow when the monitor does not receive a video signal or is in the energy saving

mode. The power indicator goes off when the monitor is switched off.

When you switch the computer system on, you must proceed in the following order:

►First switch the LCD monitor on with the ON/OFF switch.

►Then switch on the computer.

Downloaded from ManualMonitor.com Manuals

LCD monitor

edition 1 English - 7

Troubleshooting

Should an error occur, first check the following points. If the distortion is still not eliminated, the

monitor should, if possible, be checked on another computer.

If you are unable to solve the problem, please inform our help desk.

Having this problem? Check the following points:

No screen display

(power indicator does not light) ►Check whether the monitor is switched on.

►Check whether the power cable on the monitor is

connected correctly.

►Check whether the computer is switched on.

No screen display

(power indicator lights) ►Check whether the computer is switched on.

►Check whether the data cable for the monitor is

correctly attached to the monitor port on the

computer.

►Press any key on the computer keyboard - the

computer may be in energy saving mode.

►Alter the brightness and/or contrast until you get a

picture.

Message:

No Video Input

►Check whether the data cable for the monitor is

correctly attached to the monitor port on the

computer.

►Check whether the computer is switched on.

Message:

This is 85 Hz overdrive.

Change computer display

input to 1024 x 768 at

60 Hz.

Change computer display

input to 1280 x 1024 at

60 Hz.

The input signal (horizontal frequency and refresh rate)

does not correspond to the technical monitor data.

►Adjust the video frequency range using the computer

software (see documentation for your computer or

your graphics card).

►Adjust a different screen resolution using the

computer software (see documentation for your

computer or your screen controller).

Picture position not correct The monitor recognises an undefined mode.

►Carry out the auto-adjustment of the monitor (with

the AUTO button - if present - or via the OSD menu).

►Set the picture position with the OSD menu.

Downloaded from ManualMonitor.com Manuals

LCD monitor

8 - English edition 1

Having this problem? Check the following points:

Picture is shaking ►Check whether the data cable for the monitor is

correctly attached to the monitor port on the

computer.

►Carry out the auto-adjustment of the monitor (with

the AUTO button - if present - or via the OSD menu).

Picture disturbances (vertical lines)

►Carry out the auto-adjustment of the monitor (with

the AUTO button - if present - or via the OSD menu).

Picture disturbances

(horizontal lines, picture noise)

►Carry out the auto-adjustment of the monitor (with

the AUTO button - if present - or via the OSD menu).

Picture too light or too dark ►Carry out the auto-adjustment of the monitor (with

the AUTO button - if present - or via the OSD menu).

►Correctly set the contrast and brightness with the

OSD menu if the auto-adjustment function does not

supply satisfactory results.

Permanently unlit or lit pixels

The standard of production techniques today cannot guarantee an absolutely fault-free screen

display. A few isolated constant lit or unlit pixels may be present. The maximum permitted number of

pixels faults is stipulated in the stringent international standard ISO 13406-2 (Class II).

Example: a 15" flat-screen monitor with a resolution of 1024 x 768 has 1024 x 768 = 786432 pixels.

Each pixel consists of three subpixels (red, green and blue), so there are almost 2.4 million dots in

total. According to ISO 13406-2 (Class II), a maximum of 4 pixels and 5 subpixels may be defective,

i. e. a total of 17 faulted dots.

A 17" flat-screen monitor with a resolution of 1280 x 1024 has 1280 x 1024 = 1310720 pixels. Each

pixel consists of three subpixels (red, green and blue), so there are almost 4 million dots in total.

According to ISO 13406-2 (Class II), a maximum of 6 pixels and 7 subpixels may be defective, i. e. a

total of 25 faulted dots.

Downloaded from ManualMonitor.com Manuals

Tabla de contenidos

Otros manuales de Monitor de Fujitsu Siemens Computers

Fujitsu Siemens Computers

Fujitsu Siemens Computers FSC B15-1A Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Fujitsu Siemens SCENICVIEW P17-2 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers B15-1 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW B17-5 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 172E Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 21P4 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 22" LCD Monitor Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 461V FA Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW S17-2 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 3220W Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 19T2 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW B17-3 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW L17-6 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SP716 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 4312 FA Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers FGSW-1602 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers x178 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW L19-1W Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers L19W-9 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers 5110 FA Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers Fujitsu Siemens SCENICVIEW P17-2 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers L 3220T Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW P20W-3 Manual de usuario

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW A17-3A Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
