Fuji Xerox DocuPrint CM305 df Manual de usuario

DocuPrint CM305 df

Service Manual 1st Edition

•

This service manual covers the following models

FUJI XEROX Co. Ltd. Color Laser Printer

DocuPrint CM305 df

•Related Materials

No other related materials issued other than this

service manual.

•Confidentiality

•

This service manual is issued intending use by

maintenance service personnel authorized by

FUJI XEROX Co. Ltd.

Copying, transferring or

leasing this manual without prior consent by

FUJI XEROX Co. Ltd. is prohibited.

• When a page becomes irrelavant (e.g.

superceded by a replacement page), destroy

the page by burning or shredding it.

• Handle with care to avoid loss or damage of

the manual.

•Revision and Modification Information

When design changes or revisions relating to

this service manual occur, the overseas

technical information or overseas service

bulletin may be issued as supplementary

information until such changes are

accomodated in the updated version of this

service manual.

CAUTION

Important changes including

revisions of spare part

numbers and adjustment

specifications must

immediately be reflected on

the respective pages of this

service manual upon

reception of such

information.

Edited by: Fuji Xerox Co., Ltd. CS/TS

MinatoMirai Center Bldg. 7F

3-6-1 Minatomirai Nishi-ku, Yokohama, Kanagawa 220-0012, JAPAN

TEL: 045-414-5725

[XEROX] [The Document Company] are registered trademarks.

PRINTED IN JAPAN

DocuPrint CM305 df

Service Manual 1st Edition Issued: January 2011

Company Name

Department Name

Telephone No.

Full Name Employee No.

Preface

Getting to know the Service Manual

How to use the Service Manual

Terms and Symbols

Abbreviations

Chapter 1 Service Call Procedure

Chapter 2 Troubleshooting

Chapter 3 Image Quality Troubleshooting

Chapter 4 Disassembly / Assembly and Adjustments

Chapter 5 Parts List

Chapter 6 General

Chapter 7 Wiring Data

Chapter 8 Accessories (Not yet issued)

Chapter 9 Installation

Chapter 10 Machine Overview

Preface

Table of Contents

1 Getting to know the Service Manual.............................................................. Preface-1

2 How to use the Service Manual..................................................................... Preface-1

2.1 Contents of Manual ......................................................................................................Preface-1

2.2 Information on Updating ...............................................................................................Preface-2

3 Terms and Symbols....................................................................................... Preface-3

4 Abbreviations................................................................................................. Preface-4
