FROZEN FCR-15 Manual de usuario
Car Refrigerator Manual
Car Refrigerator
FCR/FC-15 FCR/FC-30 FCR/FC-40 FCR/FC-50
Ver : 1.0.0.0
Contents
5. Cleaning and Maintenance 8
6. Other Settings 9
1. Manual Notifications 1
4. Use of refrigerators 5
2. Safety Instructions 1
3. Operation 3
7. Troubleshooting 9
8. Technical Data 12
9. Product Safety Certification 14
Thank you for choosing smart car refrigerator products.Please read this manual
carefully before using. Keep the manual in a safe place.
Please hand on this manual together if you deliver the refrigerator to another
person.
Manual Notifications
• Safety instructions: Improper operation may cause fatal or serious injury, and
damage to the refrigerator.
• Safety instructions related to current or voltage. Failure to follow this instruction
may lead to injury or damage to the refrigerator and impair the function of the
product.
• Safety instructions: failure to observe this instruction can lead to injury.
WARNING !
CAUTION !
The manufacturer hereby declares not responsible for damage
caused by the following actions.
1
• Overvoltage and mechanical breakage lead to refrigerator damage.
• Retrofitting the refrigerator without the permission of the manufacturer.
• Failure to follow the manual instructions.
• Never touch the damaged power cable directly with your hands, especially
when it is connected to AC mains supply. It's very dangerous!
• Disconnect the refrigerator and other power consuming devices from the
battery before connecting the quick charging device.
• Check that the voltage specification on the type plate corresponds to that of the
energy supply.
Warning - Fatal Hazard from Electric Shock
2
1
Safety Instructions
WARNING !
WARNING !
• If you are operating your refrigerator on board a boat from a mains connection of
100- 240 V～，you must install a residual current circuit breaker between the
100 - 240 V～mains and the refrigerator.
• Seek advice from a trained technician.
• Battery contains acid and corrosive substances. Careful with using.
• Do not store any corrosive substances.
• Do not place obstructions in or near the compressor refrigeration system of the
product.
• Do not use electrical devices inside the refrigerator.
• If this device's power cable is damaged, it must be replaced by the manufacturer
or a similarly qualified person in order to prevent safety hazards.
• Do not try to open the circuit part of the product.
Operating the device safely
3
• Product working voltage: DC 12V/24V
• The refrigerator is suitable for cooling and freezing food. The model FC/FCR
15/30/40/50 are all single zone refrigerators.
CAUTION !
• The temperature display is based on the temperature at the center of the
container.
• Compressor refrigerators can be used for home, car or boat, and can also be
used for camping.
WARNING !
2
CAUTION !
CAUTION !
• The temperature display is based on the temperature at the center of the
container.
• The refrigerator can work properly when the ambient temperature is between -
5°C to +45°C and the maximum humidity is 90%.
• The refrigerator works properly under the maximum inclination angle 30
degrees. (Note: If the inclination angle exceeds 15 degrees, the noise will
increase when the refrigerator is working, but no influence to the refrigeration
function).
• The raw materials used in the production process all meet the restrictions and
requirements of all kinds of laws and regulations.
WARNING !
Operation
Before initial use
1
CAUTION !
• Please check whether the accessories are available at the first when opening
the package.
• Please place the product in a dry place, and pay attention to prevent rainwater
from spilling.
• Please do not use the product with the main power supply device outdoors, and
be carefully not to wet the power supply device.
• There is a 12/24V DC power supply interface on the power supply device. Do
not place the device near naked flames or other heat sources (heaters, direct
sunlight, gas ovens etc.).
• Ensure that there is sufficient ventilation so that the heat that arises during
operation does not build up. Make sure that the device is sufficiently far away
from walls and other objects so that the air can circulate. Ensure that the
ventilation openings are not covered.
3
Power-on operation
Warning--danger of damaging the refrigerator
• The refrigerator can be directly plugged in 12V DC power supply or 24V DC
power supply.
• Before connecting the power, please check whether the output voltage of the
power supply meets the working voltage range of the product.
2
4
Warning--electric current danger
• Connect the DC power cable directly to the battery with a 10A fuse. Please
note that the positive power cable is connected to the positive pole of the
battery, and the negative power cable is connected to the negative pole of
the battery.
• In order to prevent the voltage loss from affecting the cooling effect of the
product, the power cable should be as short as possible.Always ensure that
the power cable is straight through. Therefore, avoid the use of additional
switch plugs or connecting box.
• If the power cable is too short, or it does not match the power cable of the
refrigerator model you are using, please purchase a power cable that meets
the corresponding regulations or extend the power cable from a designated
product dealer.
• When choosing the cross section of the power cord, please refer to the
following table:
16
14
12
10
8
6
4
2
0
24 volts
12 volts
Power cord cross section（mm2）
CAUTION !
• Disconnect the refrigerator and other power consuming devices from the battery
before connecting the quick charging device.
• The refrigerator consumes a certain amount of current during operation.
Therefore, when the refrigerator is not used for a short period of time, please
turn it off directly.
Battery protector
3
5
• For safety reasons, the refrigerator is equipped with an electronic system to
prevent polarity reversal. This protects the refrigerator against short-circuiting when
connecting to a battery.
• In order to protect the battery, when the battery voltage is insufficient, the circuit
control system on the refrigerator will automatically turn off, which can effectively
protect the battery. The relevant start voltage and disconnect voltage data as
below.
Hazard warnings
• In order to protect your battery from being completely depleted and affecting
other uses, it is recommended to set the voltage level to "Hi" or “Nd".
• Never handle plugs and switches with wet hands or if you are standing on a
wet surface.
screen
ON/OFF SETUP Temperature +
Temperature -
Use of refrigerators
Power On/Off
1
• Switch on the refrigerator, press the on/off button, then the LCD display lights
up and the compressor starts to work.
• Long press the on/off button for 3 seconds, the buzzer will beep for 1 second,
then the LCD display lights off and the compressor will stop working.
Setting temperature
2
6
• Press the setting button, the buzzer will beep for 500ms, and the temperature
display on the LCD screen will start to flash. At this time, you can start to set
the internal control temperature of the refrigerator. Press the "+" and "-"
button to set, the temperature range is -22°C ~+10°C(-7.6°F~50°F);
• Press the setting button again, or do not press any button for 10 seconds, the
temperature display stops flashing, the device temperature has been fixed,
and it starts to adjust to the selected temperature.
Running mode setting
3
• Long press the setting button for 3 seconds, the buzzer will beep for 1
second. The °C (°F), max (eco), H (M, L) of the LCD display start to flash,
and you can set the below functions.
• Press the setting button, the battery protection level [ H, M, L ]displayed
alternately, you can set the battery voltage protection level.
• Press the temperature[-], [°C, °F ] displayed alternately, you can set the
temperature scale.
• Press temperature [+], [ max and eco ] displayed alternately, and the control
mode can be set.
• No operation for 10 seconds, the display stop flashing, and the refrigerator
works according to the newly set parameters.
Bluetooth connection settings
4
• Switch on, press or long press the setting button, the Bluetooth of the
refrigerator starts broadcasting.
• The Bluetooth icon on the LCD screen lights up, and the mobile app can be
connected to Bluetooth.
• After connecting, you can set the refrigerator through the app.
• After turn off the mobile app, the Bluetooth connection display will be
automatically cancelled.
Battery protection voltage gear parameter table
7
Input power Voltage gear Compressor ON/OFF voltage (V)
12V
Low on 11.4±0.3
Mid on 12.2±0.3
Hi on 12.6±0.3
Low off 10.1±0.3
Mid off 11.2±0.3
Hi off 11.8±0.3
12<->24V 12V/24V Switching voltage 17±0.3
24V
Low on 23.5±0.3
Mid on 25.3±0.3
Hi on 26.0±0.3
Low off 22.0±0.3
Mid off 24.1±0.3
Hi off 24.6±0.3
Energy saving tips
5
• Choose a well ventilated installation location which is protected against direct
sunlight.
• Allow warm food to cool down first before placing it in the cooling device to
keep cool.
• Defrost the refrigerator regularly. Or defrost the refrigerator once a layer of ice
forms.
Cleaning and Maintenance
• The device can be used directly without cleaning.
• If necessary, clean it with a soft cloth dampened with warm water.
• Please clean the refrigerator regularly during use!
• Never handle plugs and switches with wet hands or if you are standing on a wet
surface.
• Please do not use corrosive or acidic cleansers to clean the inner container of
the refrigerator.
• Do not use hard cleaning tools such as brushes for cleaning.
• Please wipe the refrigerator with a dry cloth after cleaning.
CAUTION !
1Cleaning
2Maintenance
Warning! The effect of damaging the refrigerator
8
• Avoid unnecessarily low temperatures.
• Do not leave the lid of the refrigerator open longer than necessary.
• If you do not use the refrigerator for a long time, please keep the refrigerator as
follows:
• Unplug the DC power cord from the DC port or remove the power cable from the
battery.
• Clean the refrigerator.Keep the refrigerator lid open to against moisture and
mustiness.
