FrontRow ToGo Manual de usuario

1Table Stand

2Power Cord

3Charger for Transmitter

4Auxiliary Input Cord Kit

(DVD/Computer Sound)

5Antenna

6Receiver & Speaker Column

7Pass Microphone (optional)

8Behind the Neck Boom Mic

9Wall Bracket with Screws

10 Body Worn Transmitter

11 Carry Case (optional)

12 Volume Locks

821-7404-103/Rev. H 1020

FrontRow USA/Global

1690 Corporate Circle

Petaluma, CA 94954

tel: 800.227.0735

fax: 707.769.9624

gofrontrow.com

FrontRow Canada

6950 Creditview Rd, Unit 1

Mississauga, ON L5N 0A6

tel: 800.340.9894

fax: 905.677.7760

gofrontrow.com

FrontRow Australia

629 Nudgee Road

Nundah Qld 4012

tel: 1800 746 642

fax: 1300 737 983

gofrontrow.com

FrontRow Nordic

Phonic Ear A/S

Kongebakken 9

DK-2765 Smørum

tel: +45 3917 7101

phonicear.dk

FrontRow UK

Cadzow Industrial Estate

Low Waters Road

Hamilton

Lanarkshire ML37QE

tel: +44 (0) 1698 208268

ToGo

Quick Start Guide

or registered trademarks of FrontRow Calypso LLC in the U.S. and other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Step 1: Set up Receiver

• Connect antenna

• Open and screw in table stand

• Connect power cord

• Turn main power on

Step 2: Set up Transmitter and Charger

• Insert batteries into transmitter

• Connect power cord to charger

• Place transmitter in charger and charge overnight

• Note: red “charging” light on charger should be on

Step 3: Match Transmitter and Receiver Channel Numbers

You can use two transmitters simultaneously with

your ToGo system as the receiver has two

receiving channels, A and B.

• Match the channel number on the first

transmitter to the Channel A channel

number on the receiver (e.g., 41)

• Match the channel number on the second

transmitter to the Channel B channel

number on the receiver (e.g., 51)

Step 4: Turn on Transmitter

• Connect microphone to transmitter

• Turn on transmitter

Step 5: Turn on Receiver

• Turn receiver Channel A or B on

and adjust volume

Step 6:

• Low: use in low noise environments for

the most natural voice reproduction

• Mid: use in moderately noisy environments to

increase emphasis on mid and high speech frequencies

• High: use in noisy environments to optimize

mid and high speech frequencies for maximum

speech intelligibility

Step 7: Connect CMBT Bluetooth®Audio Receiver

• Attach the supplied rubber feet to the bottom of the CMBT

receiver and select a stable space near the 925RS

• Connect the supplied power source to the 5VDC jack of the CMBT

and plug the supply into an electrical outlet

• Plug one of the supplied 3.5mm audio cables into the Bluetooth Audio

Out jack on the CMBT and connect the other end to one of the available

audio inputs on the 925RS.

Step 6

Step 4

Step 3

Step 2

Step 1

Step 5

LOW

MID

HIGH

Ch. A

Ch. B

Microphone

input

Step 7

(optional)

Optional

1Table Stand

2Power Cord

3Charger for Transmitter

4Auxiliary Input Cord Kit

(DVD/Computer Sound)

5Antenna

6Receiver & Speaker Column

7Pass Microphone (optional)

8Behind the Neck Boom Mic

9Wall Bracket with Screws

10 Body Worn Transmitter

11 Carry Case (optional)

12 Volume Locks

821-7404-103/Rev. H 1020

FrontRow USA/Global

1690 Corporate Circle

Petaluma, CA 94954

tel: 800.227.0735

fax: 707.769.9624

gofrontrow.com

FrontRow Canada

6950 Creditview Rd, Unit 1

Mississauga, ON L5N 0A6

tel: 800.340.9894

fax: 905.677.7760

gofrontrow.com

FrontRow Australia

629 Nudgee Road

Nundah Qld 4012

tel: 1800 746 642

fax: 1300 737 983

gofrontrow.com

FrontRow Nordic

Phonic Ear A/S

Kongebakken 9

DK-2765 Smørum

tel: +45 3917 7101

phonicear.dk

FrontRow UK

Cadzow Industrial Estate

Low Waters Road

Hamilton

Lanarkshire ML37QE

tel: +44 (0) 1698 208268

ToGo

Quick Start Guide

or registered trademarks of FrontRow Calypso LLC in the U.S. and other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc.
