FrontLine RORS01 Manual de usuario

Instruction Manual

ROOF ANCHOR

RORS01

Meets or exceeds

applicable standards

Rev. Mar. 2023

USER MANUAL

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT

Frontline Fall Protection Inc.

INSTRUCTION MANUAL

This product meets applicable ANSI Z359.18, OSHA 1910

and OSHA 1926 fall protection standards.

Designed in accordance with ANSI Z359.18 Type A

These instructions apply to the following model(s):

RORS01

Applicable standards and regulations depend on the type of work

being done, and also might include state-specific regulations. Refer

to local, state, and federal (OSHA) requirements for additional

information concerning the governing body of occupational safety

regarding Personal Fall Arrest Systems (PFAS).

You are required to read and fully understand the user instruction

manual BEFORE using this product. Improper use and installation can

result in serious injury or death. User manuals occasionally may be

updated so for the latest user manual please visit

www.frontlinefall.com/uim.

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT

TABLE OF CONTENTS

Definitions __________________________________________________________ 4

General Statement and Warnings ___________________________________ 8

Training Requirements ______________________________________________ 9

Description _________________________________________________________ 10

Application _________________________________________________________ 10

System Requirements _____________________________________________ 12

Installation _________________________________________________________ 18

Maintenance, Service, and Storage _________________________________ 21

Labels ______________________________________________________________ 23

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

DEFINITIONS

Anchorage

A secure point of attachment for lifelines, lanyards, or deceleration devices.

Attachment Point

A loop or “D” ring connected (integrally) to the body support that provides a

means for attachment of other components of the fall protection system.

Body Harness

Means straps, which may be secured about the worker in a manner that will

distribute the fall arrest forces over at least the thighs, pelvis, waist, chest and

shoulders with means for attaching it to other components of a personal fall

arrest system.

Carabiner

A link with a gate that is normally closed or that automatically closes, and is

used to connect components of a personal fall protection system.

Competent Person

Is defined as “one who is capable of identifying existing and predictable hazards

in the surroundings or working conditions which are unsanitary, hazardous, or

dangerous to employees, and who has authorization to take prompt corrective

measures to eliminate them” [29 CFR 1926.32(f)]. By way of training and/or

experience, a competent person is knowledgeable of applicable standards, is

capable of identifying workplace hazards relating to the specific operation and

has the authority to correct them.

Connector

A device which is used to couple (connect) parts of the personal fall arrest

system and positioning device systems. It may be an independent component of

the system, such as a carabiner, or it may be an integral component of part of the

system (such as a buckle or D-ring sewn into a body belt or body harness, or a

snap-hook spliced or sewn to a lanyard or self-retracting lanyard).

D Ring

A form of attachment point on body belts and fully body harnesses meant for

attachment of other components of a fall protection and positioning system.

Deceleration Device

Means any mechanism that serves to dissipate energy during a fall.

Deceleration Distance

The vertical distance a falling employee travels from the point at which the

deceleration device begins to operate, excluding lifeline elongation and free fall

distance, until stopping. It is measured as the distance between the location of

an employee’s body harness attachment point at the moment of activation (at

the onset of fall arrest forces) of the deceleration device during a fall, and the

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

location of that attachment point after the employee comes to a full stop.

Fall Arrest System

A fall arrest system means a system used to arrest an employee in a fall from

a working level. It consists of an anchor point, connectors, a body belt or body

harness and may include a lanyard, deceleration device, lifeline, or suitable com-

binations of these.

Fall Prevention System

Those systems and techniques that eliminate the possibility of a fall.

Fall Protection System

Any of the following when used to protect a worker from a fall or minimize the

risk from falling: Guardrails, Safety belt or a full body harness with a lanyard

and/or lifeline and an anchor, and their related equipment, Safety net, Control

zone, Safety monitor with a control zone, and other acceptable procedures.

Fall Restraint System

A work positioning system to prevent a worker from falling from a work position,

or a travel restriction system such as guardrails or a personal fall protection

system to prevent a worker from traveling to an edge from which the worker

could fall.

Free Fall

The act of falling before the personal fall arrest system begins to apply force to

arrest the fall.

Free Fall Distance

Vertical displacement of the fall arrest attachment point on the employee’s body

belt or body harness between onset of the fall and just before the system begins

to apply force to arrest the fall. This distance excludes deceleration distance,

lifeline and lanyard elongation, but includes any deceleration device slide dis-

tance or self-retracting lifeline/lanyard extension before the devices operate

and fall arrest forces occur.

Full Body Harness

A body support device consisting of connected straps designed to distribute a

fall arresting force over at least the thigh, shoulders and pelvis, with provision

for attaching a lanyard, lifeline or other components.

Lanyard

A flexible line of webbing, synthetic rope or wire rope that is used to secure a

safety belt or full body harness to a lifeline or anchor.

Horizontal Lifeline System

A system composed of a synthetic or wire rope installed horizontally between

two anchors, to which a worker attaches a personal fall protection system.

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

Leading Edge

The edge of a floor, roof, or formwork for a floor or other walking or working

surface (such as the deck) which changes location as additional floor, roof,

decking, or formwork sections are placed, formed, or constructed. A leading

edge is considered to be an “unprotected side and edge” during periods when it

is not actively and continuously under construction.

Lifeline

A synthetic or wire rope, rigged from one or more anchors, to which a worker’s

lanyard or other part of a personal fall protection system is attached.

Low-Slope Roof

A roof having a slope less than or equal to 4 in 12 (vertical to horizontal).

Lower Levels

Those areas or surfaces to which a worker can fall. Such areas or surfaces

include, but are not limited to, ground levels, floors, platforms, ramps, runways,

excavations, pits, tanks, material, water, equipment, structures, or portions

thereof.

Passive Fall Prevention

Refers to a system that is non-dynamic, stationary, and does not move, adapt, or

change when in or out of use. Passive systems don’t require the use of personal

protective equipment or active participation from the worker. Typically, passive

systems include netting, handrails, and guardrails.

Personal Fall Arrest System

A system used to arrest an employee in a fall from a working level. It consists

of an anchorage, connectors, a body belt or body harness and may include a

lanyard, deceleration device, lifeline or suitable combinations of these. As of

January 1, 1998, the use of a body belt for fall arrest is prohibited.

Positioning System (work-positioning system)

A system of equipment and connectors that, when used with a body harness or

body belt, allows an employee to be supported on an elevated vertical surface,

such as a wall or window sill, and work with both hands free. Positioning systems

also are called “positioning system devices” and “work-positioning equipment”.

Qualified

A person who, by possession of a recognized degree, certificate, or professional

standing, or who by extensive knowledge, training, and experience has

successfully demonstrated the ability to solve or resolve problems relating to

the subject matter, the work, or the project.

Rope Grab

A deceleration device which travels on a lifeline and automatically, by friction,

engages the lifeline and locks so as to arrest the fall of an employee. A rope

grab usually employs the principle of inertial locking, cam/level locking or both

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

(also referred to as a fall arrester).

Self-Retracting Lifeline/Lanyard

A deceleration device containing a drum-wound line, which can be slowly

extracted from, or retracted onto, the drum under slight tension during normal

worker movement, and which, after onset of a fall, automatically locks the drum

and arrests the fall.

Shock Absorber

A device intended to limit the deceleration forces exerted on a worker during

fall arrest.

Snap Hooks

A connector consists of a hook-shaped member with a normally closed keeper,

or similar arrangement, which may be opened to permit the hook to receive an

object and, when released, automatically closes to retain the object.

Unprotected Sides and Edges

Any side or edge (except at entrances to points of access) of a walking or

working surface (for example, floor, roof, ramp, or runway) where there is no

wall or guardrail system at least 39 inches high.

Walking/Working Surface

Any surface (whether horizontal or vertical) on which a worker walks or works,

including but not limited to floors, roofs, ramps, bridges, runways, formwork

and concrete reinforcing steel; but not including ladders, vehicles, or trailers, on

which workers must be located in order to perform their job duties.

Warning Line System

A barrier erected on a roof to warn workers that they are approaching an

unprotected roof side or edge, and which designates an area in which roofing

work may take place without the use of guardrail, body harness, or safety net

systems to protect workers in the area.

Working load

Refers to aggregate simultaneous load of personnel, equipment, and/or material

to be supported by the equipment or system.

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

This Anchorage Connector is meant to be used ONLY by trained personnel in

fall protection. This anchorage connected is ONLY intended for use as part of a

complete personal fall protection system. This anchorage connector has been

designed to meet or exceed ANSI Z359.18, OSHA 1926 and OSHA 1910.

User MUST read, understand, and follow all safety information contained in

these instructions prior to the use of this Anchorage Connector. Use in any

other applications including, but not limited to, material handling, recreational or

sports related activities, or other activities not described in the User Instructions

is not approved by Frontline Fall Protection and could result in serious injury or

death. This device is only to be used by trained users in workplace applications.

These instructions must be provided to the user of this equipment. Retain these

instructions for future reference or you can find a copy of them at

www.frontlinefall.com. For more information regarding any portion of this user

instructions manual please contact us at info@frontlinefall.com.

• Do not use this equipment until proper training, fall protection and rescue

programs are in place.

• Do not use this equipment in combination with other components or

subsystems other than those described in this manual.

• Do not use this is equipment for other uses other than its original and

designed intended use.

• Do not use product that has been impacted to a fall, that does not pass

inspection or that the safety and integrity of it is questionable.

• Consult a doctor prior using this equipment to ensure user is in physical

conditions to use this equipment and if physical fit in the event there’s a fall.

• Pregnant women or minors must not be exposed to a workplace hazard and

must not use this equipment.

• Avoid sharp and/or abrasive surfaces and edges as this will compromise the

safety of the Personal Fall Arrest System.

• All user must refer to local, state or federals safety and health regulations

before using this equipment. Whichever is most stringent shall supersede and

apply.

• Avoid moving machinery, thermal, electrical, and/or chemical hazards as

contact may cause serious injury or death.

• Avoid swing falls at all times when using Personal Fall Arrest Systems.

• Follow the weight restrictions/limitations in this manual.

GENERAL STATEMENT AND WARNINGS

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

Before using Frontline Fall Protection product, user and employers must

ensure that the person using this equipment has been trained on the proper

use, care and maintenance of this product by a competent person qualified in

Fall Protection. It is the responsibility of the user of this product to ensure that

proper training has been done in addition to reading and fully understanding

these user instructions manual.

Additionally, the employer should establish a training program to employees that

are exposed to a fall hazard and trained by a competent person qualified in those

areas. The program shall enable each employee to recognize the hazards of

falling and shall train each employee in the procedures to be followed in order

to minimize these hazards.

Retraining is necessary when the employer has reason to believe that any

affected employee who has already been trained does not have the understanding

and skill to carry out those duties. Circumstances where retraining is required

include, but are not limited to, situations where:

• Changes in the workplace render previous training obsolete.

• Changes in the types of fall protection systems or equipment to be used

render previous training obsolete.

• Inadequacies in an affected employee’s knowledge or use of fall protection

systems or equipment indicate that the employee has not retained the

requisite understanding or skill.

• Changes in the OSHA regulations or ANSI Standard.

Training must be done in the language that the employee understands and shall,

• Never alter or intentionally misuse this equipment, always inspect before

each use to ensure its compliance and safe use.

• Never connect rebar hooks, large carabiners, large snaphooks or non-

approved hooks/connectors to the full body harnesses dorsal D-rings as this

may cause a roll-out and/or unintentional disengagement.

• Avoid contact with arc flash welding at all times. Arc flash from arc welding

operations, including accidental arcs from electrical equipment, can damage

the PFAS equipment resulting in injury or death.

• Always examine the work area and the surroundings to identify hazards that

may impact safety and proper functioning of the Personal Fall Arrest System

before commencing work.

TRAINING REQUIREMENTS

Instruction Manual

BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT 1

be documented and kept as outlined under OSHA recordkeeping regulations.

No user or employee shall perform work without the proper training and

understanding on how to properly and safely use this product.

The Frontline PitchFast Roof Anchors are designed for a number of applications

such as fall arrest, fall restraint and work positioning. The anchors can be

installed onto applicable structural wood trusses, metal or concrete structures.

The Frontline PitchFast Roof Anchor is an active fall protection system that

meets all of the design requirements or applicable standards set forth by OSHA

1926, 1910 and ANSIZ359.

DESCRIPTION

This Anchorage Connector has been tested for compliance with the requirements

of by OSHA 1926, 1910 and ANSIZ359. Testing covers only the Anchorage Connector

and does not extend to the connector, body harness, subsystem and/or substrate

to which the Anchorage Connector is attached to.

Prior to installation and use of this equipment, record the product identification

information from the label in the Inspection and Maintenance Log at the end of

this manual. Use a pen or fine point sharpie with blue or black ink when logging

inspections.

APPLICATION

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de seguridad de FrontLine

FrontLine

FrontLine COB01SW Manual de usuario

FrontLine

FrontLine COM345K Guía

FrontLine

FrontLine RPG10 Manual de usuario

FrontLine

FrontLine COB345K Manual de usuario

FrontLine

FrontLine WDJ50 Manual de usuario

FrontLine

FrontLine COB345K Manual de usuario

FrontLine

FrontLine STB01 Manual de usuario

FrontLine

FrontLine ROB01 Manual de usuario

FrontLine

FrontLine COM3410K Guía

FrontLine

FrontLine HLK1004 Manual del operador

FrontLine

FrontLine COP01 Manual de usuario

FrontLine

FrontLine DT602 Manual de usuario

FrontLine

FrontLine ST30H Manual de usuario

FrontLine

FrontLine FD9 Manual de usuario

FrontLine

FrontLine GPB200 Manual de usuario

FrontLine

FrontLine RAG503W-US Instrucciones de montaje

FrontLine

FrontLine ST18AV Manual de usuario

FrontLine

FrontLine ST14SH Manual de usuario

FrontLine

FrontLine ACTLC5 Manual del operador

FrontLine

FrontLine ST12AH Manual de usuario

FrontLine

FrontLine RPA061S Manual del operador

FrontLine

FrontLine RO4W Manual de usuario

FrontLine

FrontLine X27 Manual de usuario

FrontLine

FrontLine ST10HT Guía

Manuales populares de Equipo de seguridad de otras marcas

Innova

Innova Xtirpa Manual de instrucciones

bolle SAFETY

bolle SAFETY B810 Manual de usuario

SHENZHEN FANHAI SANJIANG ELECTRONICS

SHENZHEN FANHAI SANJIANG ELECTRONICS A9060T Manual de usuario

Hiltron security

Hiltron security POWER8E Guía

Hatco

Hatco B-950P Manual de usuario

Sitec

Sitec TX MATIC Manual de usuario

TEUFELBERGER

TEUFELBERGER GRIP 12 Manual de usuario

MSA

MSA PremAire System Manual de usuario

AMC

AMC 1022M Series Manual de usuario

Trinity

Trinity CASS S3 Manual de usuario

CMC

CMC Helitack HotSeat Manual de usuario

Force

Force P-35 Manual de usuario

ACM

ACM SAFETY D200 Manual del producto

Honeywell

Honeywell Miller H-Design DuraFlex Manual del operador

ROCK

ROCK P-451 AS Manual de usuario

Power first

Power first 2XYR7A Manual de servicio

SCHUBERTH

SCHUBERTH SHP 28-C Manual de usuario

Trango

Trango CINCH Manual de usuario
