Frigidaire FRS22ZRG Manual de usuario

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FRS20ZSGB0 FRS20ZSG R134a stainlessw/blk 115

FRS20ZSGB1 FRS20ZSG R134a stainlessw/blk 115

Publication No.

5995308599

980612

-EN/SERVICE /JLT

357

SIDE BY SIDE

REFRIGERATOR

Model No.

FRS20ZSGB0

FRS20ZSGB1

FACTORY PARTS CATALOG

SIDE BY SIDE

REFRIGERATOR

WIRING DIAGRAM - # 218682800

OWNER’S GUIDE - # 218854500

SERVICE DATA SHEET - # 218789700

101 Masters Blvd.

Anderson, SC 29624

06/98 2

Publication No. FRS20ZSGB0,FRS20ZSGB1

5995308599

FREEZER DOOR

# = Fast-moving Parts 3 06/98

* = Non-Illustrated Parts

FRS20ZSGB0,FRS20ZSGB1 Publication No.

5995308599

FREEZER DOOR

A = FRS20ZSG (FRS20ZSGB0)

B = FRS20ZSG (FRS20ZSGB1)

POS. NO PART NO DESCRIPTION

1 # 215734321 A B Gasket-frzr door,black ,magnetic

5 5303288950 A B Support-door rack,RH/LH

6 5303323484 A B Support-door rack,white ,LH

6A 5303323485 A B Support-door rack,white ,RH

8 5303320231 A B Rack-door

8A 215474047 A B Rack-door

9 218748601 A B Panel-inner door,frzr

11 218619097 A B Panel-frzr door,stainless steel ,w/foam insulatn

13 5303289522 A B Door Stop

18 218756501 A B Handle-door,stainless steel ,with insert

21 218709100 A B Screw-handle mtg,hex head ,10-32 x 1/2

21A 218578600 A B Screw-door stop mtg,phl truss hd ,10-16 x 3/4

22A 215615300 A B Bushing-door,bronze

* 215598900 A B Washer-flat,.691x1x.05,zinc ,I&W hinge brkt

23 5303001020 A B Screw,cr flat head ,8-32D x 1/2

47 218850101 A B Harness-wiring,frzr door

58 218781100 A B Screw,pan head ,#8-18 x 5/8

68 218020600 A B Chute-ice

140 218518700 A B Elbow-water tube

* 215361200 A B Foam Strip,handle mtg hole

* 218490900 A B Cleaner,stainless steel

* 5303917276 A B Insulation-door,fiberglass ,(bulk)

06/98 4

Publication No. FRS20ZSGB0,FRS20ZSGB1

5995308599

REFRIGERATOR DOOR

# = Fast-moving Parts 5 06/98

* = Non-Illustrated Parts

FRS20ZSGB0,FRS20ZSGB1 Publication No.

5995308599

A = FRS20ZSG (FRS20ZSGB0)

B = FRS20ZSG (FRS20ZSGB1)

POS. NO PART NO DESCRIPTION

2 # 215734322 A B Gasket-refr door,black ,magnetic

3 218749301 A B Panel-inner door,refr

4 5303320230 A B Rack-door

5 5303288950 A B Support-door rack,RH/LH

7 5303308347 A B Door-dairy

12 218395401 A B Nameplate,black

13 5303289522 A B Door Stop

15 218618962 A B Panel-refr door,stainless steel ,w/foam insulatn

18 218756501 A B Handle-door,stainless steel ,with insert

21 218709100 A B Screw-handle mtg,hex head ,10-32 x 1/2

21A 218578600 A B Screw-door stop mtg,phl truss hd ,10-16 x 3/4

22 5303289320 A B Bearing-hinge

26 3204522 A B Container-egg

27 218370101 A B Snugger-door bin,"paddle type" ,gallon door bin

27A 218714201 A B Retainer,tall bottle

49 218592305 A B Bin-door,gallon ,with trim

58 218781100 A B Screw,pan head ,#8-18 x 5/8

* 218490900 A B Cleaner,stainless steel

* 5303917276 A B Insulation-door,fiberglass ,(bulk)

* 215361200 A B Foam Strip,handle mtg hole

REFRIGERATOR DOOR

06/98 6

Publication No. FRS20ZSGB0,FRS20ZSGB1

5995308599

CABINET

# = Fast-moving Parts 7 06/98

* = Non-Illustrated Parts

FRS20ZSGB0,FRS20ZSGB1 Publication No.

5995308599

A = FRS20ZSG (FRS20ZSGB0)

B = FRS20ZSG (FRS20ZSGB1)

POS. NO PART NO DESCRIPTION

10 218748901 A B Cover-air duct

10* 5303209814 A B Nut,"U" type ,8-15(A) ,fan mtr mtg

10A 218751301 A B Cover-evap coil,lower

11 5303208309 A B Plug-hole,factory test

12 215230400 A B Plug-harness hole

18 5303289043 A B Support-air duct cvr,2.55" long

18* 5303289044 A B Support-air duct cvr,1.83" long

28 5303289062 A B Bolt-roller adj,hex head ,5/16-24 x 7/8

29 215003200 A B Washer,.40 x .63 x .16 ,nylon

29 215314301 A B Washer,.40 x .75 x .06 ,nylon

29* 215598900 A B Washer-flat,.691x1x.05,zinc ,I&W hinge brkt

30 5303289060 A B Bracket-lower hinge,w/hinge pin

30* 218730700 A B Tapping Plate,LH

30* 218730800 A B Tapping Plate,RH

30A 215009000 A B Bracket-lower hinge,LH ,w/hinge pin

37 5303321083 A B Trim-cabinet corner,black

38 218215214 A B Bracket-upper hinge,with closer ,black ,RH

38 218215216 A B Bracket-upper hinge,with closer ,black ,LH

40 218374409 A B Cover-upper hinge,black

41 5303001609 A B Grommet,shelf/rod mtg ,RH

41* 5308009759 A B Grommet,shelf mtg ,LH

43 218615300 A B Roller Assy,front ,(2)

43* 5308017044 A B Screw-roller mtg,spcl ind hex hd ,5/16-18(23)x7/8

4 218738300 A B Roller Assy,rear ,(2)

7 218659500 A B Channel-shelf mtg,side ,(2)

52 215454600 A B Tube-water inlet

58 5308002748 A B Screw,hex wshr hd ,8-15A x 0.500 ,special

66 215050201 A B Damper-meat keeper

66A 218171301 A B Cover-meat kpr dmpr

71 218515401 A B Clip-grille

72 218359615 A B Grille/Kickplate,black

77 5303001216 A B Washer-nylon,3/16 x 5/8 OD

78 5303274237 A B Screw-bracket,hex wshr hd ,8-32CA x 0.500

* 5308009617 A B Washer,ext tooth lock ,#10

80 218249802 A B Seal-coil cover,(2)

81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile

85 218359805 A B Cover-lower hinge,black

89 5303288947 A B Cover-machine compt

90 215022602 A B Seal-foam

90* 5303322647 A B Tape-foam

91 218836401 A B Deflector-air,ice maker

92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875

101 215305701 A B Seal-foam

* 5303001038 A B Washer,.28 x .62 x .19 ,nylon

* 5303305345 A B Paint,touch-up ,black

* 5308016571 A B Plug-button,cabinet liner

CABINET

06/98 8

Publication No. FRS20ZSGB0,FRS20ZSGB1

5995308599

SHELVES

# = Fast-moving Parts 9 06/98

* = Non-Illustrated Parts

FRS20ZSGB0,FRS20ZSGB1 Publication No.

5995308599

A = FRS20ZSG (FRS20ZSGB0)

B = FRS20ZSG (FRS20ZSGB1)

POS. NO PART NO DESCRIPTION

2 218747101 A B Handle-frzr basket

11 218298005 A B Shelf-freezer,sliding ,wire

11B 5303288963 A B Shelf-freezer,fixed wire

11B* 218159700 A B Spacer-shelf

24 218746001 A B Shelf-"Spill-Safe",sliding ,(3)

25A 218015301 A B Trim-storage pan cvr,snap-on ,front

25C 218015401 A B Trim-storage pan cvr,snap-on ,rear

26 5303306579 A B Pan-storage,upper

26A 5303288968 A B Pan-storage,lower

28 08013638 A B End Cap-shelf,protector ,

lower fzr shelf

39 215217562 A B Trim-frzr shelf

39A 215217563 A B Trim-frzr shelf

46 218278301 A B Front-storage pan,upper

46A 218278302 A B Front-storage pan,lower

47 218498118 A B Insert-pan cover,glass ,w/graphics

47A 215723551 A B Insert-pan cover,glass ,clear ,lower

49 218748301 A B Basket-sliding,(3)

51 5303288960 A B Hanger-basket,RH

52 215162501 A B Hanger-basket,LH,with/spring

57 5303271653 A B Ferrule-inner

66 5304402116 A B Rack-wine

81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,

low profile

96 215192600 A B Support-water tank

97 218759501 A - Water Tank Assy,includes tank ,grommets

97 218871301 - B Water Tank

98 5308015614 A - Connector-tube

99 5300186057 A - Grommet-tank

100A 218015501 A B Support-pan cover,LH

100B 218015601 A B Support-pan cover,RH

101 215005000 A B Screw,hex wshr hd ,8-18AB x 0.750 ,

gusset/hanger

* 215328300 A B Clip-shelf

SHELVES

06/98 10

Publication No. FRS20ZSGB0,FRS20ZSGB1

5995308599

CONTROLS
