Frigidaire FPHB2899LF Instrucciones de funcionamiento y seguridad

frigidaire.com

Signature Features

SpaceWise®

Organization System

Makes it easy to keep food organized

and easy to find when you need it

with a Store-More™ full-width drawer,

gallon-size door bins, and Effortless™

Glide freezer drawers.

Best-in-Class Ice &

Water Filtration1

PureSource Ultra® Water Filtration

offers best-in-class water filtration

so you get cleaner, fresher ice and

water for your family.

PowerPlus® Freeze

Quickly freeze whatever you store to

keep foods at their freshest.

Real Stainless Steel

Real stainless steel with a protective

coating that reduces fingerprints and

smudges so it’s easy to clean.

French Door Refrigerator

FPHB2899L F

28 Cu. Ft. Standard-Depth

Product Dimensions

Height 69-3/8"

(Including Hinges & Rollers)

Width (Doors) 36"

Depth (Including Door) 33-1/8"

More Easy-To-Use Features

Store-More™ Full-Width

Cool Zone™ Drawer

A large capacity full-width drawer

provides enough space to easily store

anything from sheet cakes and large

platters to snacks and juice boxes.

Eortless™ Glide Crisper Drawers

Keep your fruits and vegetables fresh in

our crisper drawers which easily glide out,

and are designed to effortlessly close.

Eortless™ Glide Freezer Drawers

Drawers glide out smoothly and fully

extend, giving you easy access to what’s

inside.

Store-More™ Bins

Our gallon-size bins are designed to store

more, so you can easily fit a gallon of milk

or 2-liter bottles.

SpillSafe® Glass Shelves

SpillSafe® glass shelves slide out for easy

access and are designed to keep spills

contained, making cleanup a breeze.

PureAir Ultra® Filters

Our PureAir Ultra® air filters effortlessly

keep the air in your refrigerator fresh.

Energy Saver Plus Technology

Pro-Select® Controls On Ice and

Water Dispenser

Easily select options with the touch of

a button.

Automatic Alerts

Refrigerator alerts you if the door is left

open or if temperature rises.

ENERGY STAR®

Sabbath Mode (Star-K® Certiﬁed)

Available in:

1As compared to other consumer refrigeration water

ﬁltration systems.

Stainless

(F)

Specifications

subject to change.

Product Dimensions

A - Height (Incl. hinges and rollers)

B - Cabinet Width / Door Width

C - Depth (Incl. Door)

Depth with Door Open 90˚

69-3/8"

35-5/8" / 36"

33-1/8"

47-1/2"

NOTE: For planning purposes only. Always consult local and national

electric and plumbing codes. Refer to Product Installation Guide for

detailed installation instructions on the web at frigidaire.com.

Accessories information available

on the web at frigidaire.com

1For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.

Features

Door Design

Door Handle Design

Cabinet Finish

Door Stops / Door Closers

Door Hinge Covers

Rollers – Front / Rear

Energy Saver Plus Technology

Water Filter Location

Sound Package

Dispenser

Controls

Dispenser Design

Number of Dispenser Buttons

Crushed Ice / Cube Ice / Chilled Water

Ice Option / Freeze Option

Display On / O Option

Lock / Light

Temp / Door Ajar / Power Failure Alerts

Water Filter Change Indicator Light

Air Filter Change Indicator Light

Refrigerator Features

Lighting

Water Filter Type

Air Filter Type

Fixed Shelves

Quarter-Width Sliding Shelves

Half-Width Sliding Shelves

Cantilever Shelves

Store-More™ Full-Width Drawer

Hanging Wine Rack

Hanging Can Dispenser

Crisper Drawer

Humidity Controls

Dairy Compartment

Store-More™ Fixed Door Bins

Fixed Door Bins

Adjustable Door Bins / Dispenser Bin

Non-Slip Bin Liner / Bottle Retainers

Freezer Features

Self-Closing Pull-Out Drawer

Sliding Full-Width Freezer Baskets

Basket Dividers

Lighting

Certiﬁcations

Sabbath Mode (Star-K® Certiﬁed)

ENERGY STAR®

Speciﬁcations

Total Capacity (Cu. Ft.)

Refrigerator Capacity (Cu. Ft.)

Freezer Capacity (Cu. Ft.)

Power Supply Connection Location

Water Inlet Connection Location

Voltage Rating

Connected Load (kW rating)

@ 120 Volts1

Amps @ 120 Volts

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Standard-Depth French Door Refrigerators

Frigidaire Professional

Soft-Arc Doors

Stainless Steel

Grey

Yes / Yes

Hidden

Adjustable / Yes

Yes

Top-Right Fresh

Food Section

Quiet Pack

Pro-Select®

Tall, Single-Paddle

Yes / Yes / Yes

No / PowerPlus®

Yes

Yes / Yes

Yes / Yes / Yes

Yes

Performance LED

PureSource Ultra®

PureAir Ultra®

1 SpillSafe®

3 SpillSafe®

Yes

1 Cool Zone™

1 Clear

1 White

2 Clear

1 Clear

2 White (1 per door)

1 Half-Gallon / 2-Liter Clear

2 Two-Gallon Clear / No

3 Grey / No

Yes

2 Eortless™ Glide

1 (Bottom Basket)

Yes

27.8

19.04

8.76

Right Bottom Rear

Left Bottom Rear

120V / 60Hz / 15 or 20A

1.02

8.5

365 Lbs.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

French Door Refrigerator

FPHB2899L F 28 Cu. Ft. Standard-Depth

Accessories information available

on the web at frigidaire.com
