Frigidaire EFR492-B Manual del propietario

use

care

REFRIGERATOR

USA/CANADA 1-800-968-9853 www.curtisint.com/frigidaire

Introduction.......................................................1

Safety Precautions .........................................2

Parts And Features........................................ 4

Food Storage Information 9

Installing Your Refrigerator..........................

........................

Refrigerator Care and Cleaning................10

Refrigerator Features....................................

Maintenance...................................................... Warranty.............................................................14

Technique Index .............................................13

..............................................12

Troubleshooting

.............11

Interior Light Bulb Refplacement

EFR492-B

INTRODUCTION

Doors

Handles are secure and tight

Door seals completely to cabinet on

all sides

Leveling

Refrigerator is level side-to-side and

slightly elevated in front to assist

with door and drawer closing (front

should be higher than back)

Cabinet is setting solid on all corners

Electrical Power

House power turned on

Refrigerator plugged in

Final Checks

Shipping material removed

Fresh food and freezer temperatures

set

Installation Checklist



Welcome to our family

Thank you for bringing Frigidaire into

your home! We see your purchase as the

beginning of a long relationship together.

This manual is your resource for the use

and care of your product. Please read

it before using your appliance. Keep it

handy for quick reference. If something

doesn’t seem right, the troubleshooting

section will help you with common issues.

FAQs, helpful tips and videos, cleaning

products, and kitchen and home accessories

are available at www.frigidaire.com.

We are here for you! Visit our website,

chat with an agent, or call us if you need

help. We may be able to help you avoid

a service visit. If you do need service, we

can get that started for you.

WARNING: Read all of the instructions before using this appliance.

When using this appliance, always exercise basic safety

precautions, including the following:

NOTE: If the refrigerator/freezer has been placed in a horizontal or

tilted position for any period of time wait 24 hours before

plugging the unit in.

1) Use this appliance only for its intended purpose as described in this use

and care guide.

2) This refrigerator/freezer must be properly installed in accordance with

the installation instructions before it is used. See grounding instructions

in the installation section.

3) This refrigerator/freezer should not be recessed or built-in an enclosed

cabinet. It is designed for freestanding installation only.

4) Never unplug your refrigerator/freezer by pulling on the power cord.

Always grasp the plug firmly and pull straight out from the outlet.

5) DANGER - Risk of Fire or Explosion. Flammable refrigerant used. Do

not use Mechanical devices to defrost refrigerator. Do not puncture

refrigerant tubing.

6) If your old refrigerator/freezer is not being used, we recommend that

you remove the doors. This will reduce the possibility of danger to

children.

WARNING:

After your refrigerator/freezer is in operation, do not

touch the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

8) Do not refreeze foods, which have been thawed completely. The United

States Department of Agriculture in Home and Garden Bulletin No. 69

reads: "…You may safely refreeze frozen foods that have thawed if

they still contain ice crystals or if they are still cold-below 40°F".

"…Thawed ground meats, poultry, or fish that have any off-odor or

offcolor should not be refrozen and should not be eaten. Thawed ice

cream should be discarded. If the odor or color of any food is poor or

questionable, discard it. The food may be dangerous to eat."

2SAFETY PRECAUTIONS

"…Even partial thawing and re-freezing reduce the eating quality of

foods, particularly fruits, vegetables, and prepared foods. The eating

quality of red meats is affected less than that of many other foods. Use

refrozen foods as soon as possible, to save as much of they’re

eating quality as you can."

9) Do not use any electrical device or any sharp instrument in defrosting

your refrigerator.

10) Unplug your refrigerator/freezer before cleaning or before making any

repairs.

Note: If for any reason this product requires service, we strongly

recommend that a certiﬁed technician perform service.

11) Do not operate your refrigerator in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS

CAUTION - Risk of Fire or

Explosion

Dispose of property in accordance with Federal or Local

Regulations. Flammable refrigerant used.

DANGER

Risk of child entrapment. Before you throw away your old

refrigerator or freezer, take off the doors. Leave the shelves

in place so that children may not easily climb inside.

Staple your receipt to your manual.

You will need it to obtain warranty service.

Thank you for purchasing our

product. This easy-to-use manual

will guide you in getting the best

use of your appliance.

Remember to record the model and

serial number. They are on a label

in back of the appliances.

Model number

Serial number

Date of purchase

SAFETY PRECAUTIONS

4Parts And Features

1. Built-in freezer

2. Drip tray

3. Removable shelf

4. Temperature control knob

(Turn to right to raise; turn to left to lower)

5. Defrost button

6. Door seal (gasket)

7. Can holders

8. Tall bottle storage

9. Lamp Switch

4 5 9 6

Installing Your Refrigerator

Unpacking Your Refrigerator

1. Remove all packaging material. This includes the foam base and all adhesive

tape holding the refrigerator accessories inside and outside.

2. Inspect and remove any remains of packing, tape or printed materials before

powering on the refrigerator.

CAUTION

Risk of Fire or Explosion due to puncture of refrigerant tubing. Flammable

refrigerant used. Handle with care when moving refrigerator to avoid either

damaging the refrigerant tubing or increasing the risk of a leak.

Leveling Your Refrigerator

• Your refrigerator has two leveling legs which are located in the front bottom

corners of your refrigerator. After properly placing your

refrigerator in its final position, you can level your refrigerator.

• Leveling legs can be adjusted by turning them counterclockwise to raise your

refrigerator or by turning them clockwise to lower your refrigerator. The

refrigerator door will close easier when the leveling legs are extended.

Proper Air Circulation

• To ensure your refrigerator works at the maximum efficiency it was designed for,

you should install it in a location where there is proper air circulation, plumbing

and electrical connections.

• The following are recommended clearances around the refrigerator:

Sides……………3/4" (19mm)

Top....................2" (50mm)

Back..................2" (50mm)

WARNING: ELECTRICAL REQUIREMENT - SHOCK HAZARD

Electrical Requirement

• Make sure there is a suitable power outlet (120 volts, 15 amps outlet) with proper

grounding to power the refrigerator.

• Avoid the use of three prong adapters or cutting off the third grounding prong

in order to accommodate a two prong outlet. This is a dangerous practice since

it provides no effective grounding for the refrigerator and may result in shock

hazard.

WARNING: USE OF EXTENSION CORDS- POTENTIAL SAFETY

HAZARD

Installing Your Refrigerator

6Installing Your Refrigerator

Use of Extension Cords

• Avoid the use of an extension cord because of potential safety hazards under

certain conditions. If it is necessary to use an extension cord, use only a 3-wire

extension cord that has a 3-blade grounding plug and a 3-slot outlet that will

accept the plug. The marked rating of the extension cord must be equal to or

greater than the electrical rating of the appliance. DO NOT USE

EXTENSION CORD LONGER THAN 12 FT.

Installation Limitations

• Do not install your refrigerator in any location not properly insulated or heated,

e.g. garage, etc. Your refrigerator was not designed to operate in temperature

settings below 55˚ Fahrenheit.

• Select a suitable location for the refrigerator on a hard even surface away

from direct sunlight or heat source, e.g. radiators, baseboard heaters, cooking

appliances, etc. Any floor unevenness should be corrected with the leveling legs

located on the front bottom corners of the refrigerator.

Door Alignment

Freezer Door: (see fig. #1)

1. Remove the top hinge cover.

2. Loosen the top hinge screws using a phillips head screwdriver.

3. Adjust the door or put a spacer in between and then tighten the screws.

4. Replace the top hinge cover.

fig. # 1

WARNING: USE OF EXTENSION CORDS- POTENTIAL SAFETY

HAZARD

Refrigerator Features And Use General Features

Adjustable temperature dial:

Your refrigerator will automatically maintain the temperature level you select.

The temperature control dial has 7 settings plus 0. 1 is the warmest. 7 is the

coldest. Turning the dial to 0 Stops cooling in both the refrigeration and freezer

sections. At ﬁrst, set the dial to 4 and allow 24 hours to pass before adjusting the

temperature to your needs.

(Note: If the refrigerator has been placed in a horizontal or tilted position for

any period of time wait 24 hours before plugging the unit in.)

Refrigerator Interior Shelves

To remove or replace a full-width

slide-out shelf:

(see ﬁg. # 2)

1. Gently tilt the shelf up and slide

forward until the shelf has been

completely removed.

2. To replace the shelf, gently slide the

shelf back.

Using the Dispense-A-Can

• Your refrigerator is equipped with the convenient “Dispense-

A-Can” compartment. Each compartment will hold up to six

cans. Simply load the cans from the top. To dispense a can,

simply draw one out from the bottom. It is that easy.

ﬁg. # 2

ﬁg. # 3

Refrigerator Features

Maintenance

Risk of Fire or Explosion. Flammable refrigerant used. Do not puncture of

refrigerant tubing. To be repaired only by trained authorized service personnel.

Consult Repair Manual before attempting to service this product. All Safety

Precautions Must be followed. Component parts shall be replaced with like

components to minimize the risk of possible ignition due to incorrect parts or

improper service.

Maintenance

- When being defrosted the appliance must be unplugged to avoid the risk of electrical shock.

- DO NOT use a sharp or metallic instrument to remove frost from the refrigerator interior, as

damage to refrigerant tubing may occur. Tubing damage may allow ﬂammable refrigerant gas

leakage, which can result in injury to persons.

Defrosting is needed when the frost layer on the evaporator reaches 3 - 4mm. Press the

defrost button in the middle of temperature control knob, the refrigerator will begin to

defrost. When the defrosting has ended, the thermostat will switch on automatically,

and the refrigerator will start working again.

CAUTION: DO NOT use boiling water to melt frost accumulation on freezer walls, as it

may damage plastic parts.

WARNING

Fresh Food:

• When storing fresh food that is not prepackaged, be sure to wrap or store food

in airtight and moisture proof material unless otherwise noted. This will ensure

proper shelf life and prevent the transfer of odors and tastes.

• Wipe containers before storing to avoid needless spills.

• Eggs should be stored in an upright position in their original carton to

maximize shelf life.

• Fruit should be washed and dried, then stored in sealed plastic bags before

storing in the refrigerator.

• Vegetables with skins should be stored in plastic bags or containers.

• Leafy vegetables should be washed and drained and then stored in plastic

bags or containers.

• Hot food should be allowed to cool before storing in the refrigeration. This will

prevent unnecessary energy use.

• Fresh seafood should be used the same day as purchased.

• When storing meats in the fresh food section, keep in the original

packaging or rewrap as necessary. Follow the suggestions below for safe

storage:

• Chicken 1-2 Days

• Ground Beef 1-2 Days

• Cold Cuts 3-5 Days

• Steaks/Roasts 3-5 Days

• Smoked/Cured Meats 7-10 Days

For detailed storage chart visit FDA website:

www.cfsan.fda.gov/~dms/fttstore.html

Food Storage Information

Tabla de contenidos

Idiomas:

Otros manuales de Refrigerador de Frigidaire

Frigidaire

Frigidaire FRS3LR5E Manual de usuario

Frigidaire

Frigidaire FGTC2349KS - Gallery 22.6 Cu. Ft.... Manual de servicio

Frigidaire

Frigidaire FRT17IB3A Manual de usuario

Frigidaire

Frigidaire FGTR1842TD1 Manual del propietario

Frigidaire

Frigidaire FRS23R4AW5 Manual de usuario

Frigidaire

Frigidaire FRT18PCG Manual de usuario

Frigidaire

Frigidaire Gallery GRMS2773AF Manual de usuario

Frigidaire

Frigidaire FRT21INGJ Manual de usuario

Frigidaire

Frigidaire FRS23R4AB0 Manual de usuario

Frigidaire

Frigidaire FRT18G5F Manual de usuario

Frigidaire

Frigidaire FRS23F4DB2 Manual de usuario

Frigidaire

Frigidaire Gallery FGUN2642L Manual de usuario

Frigidaire

Frigidaire FRS26DR7D Manual de usuario

Frigidaire

Frigidaire FGHS2369K Manual de instrucciones

Frigidaire

Frigidaire FGHT2144KF - 21 CF Lery SS Group Manual de usuario

Frigidaire

Frigidaire FRT15HB3J Manual de usuario

Frigidaire

Frigidaire FRS26F4D Manual de usuario

Frigidaire

Frigidaire FRFF185W1 Manual de usuario

Frigidaire

Frigidaire FFSC2323LE Instrucciones de instalación

Frigidaire

Frigidaire FRS6R5E Manual de usuario

Frigidaire

Frigidaire FRTB7B4EMB1 Manual de usuario

Frigidaire

Frigidaire FRS6HF55KW - 26 cu. Ft. Refrigerator Guía del usuario

Frigidaire

Frigidaire FRS26W2A Manual de usuario

Frigidaire

Frigidaire FRT18KC3B Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Beko

Beko LSP4579W Manual de usuario

Teledyne

Teledyne 6712FR and Instrucciones de funcionamiento
